Polaris ALPHA iQ+ Owner's Manual page 17

Polaris Robotic Pool Cleaner | Owner's Manual
®
To replace a worn brush:
1. Lift the cleaner to a vertical position so that the
handle is up.
1
Figure 17. Cleaner in Upright Position
2. Separate the edges of the brush and undo the
tabs. Remove the worn brushes.
2
Figure 18. Undo the Tabs of the Brush
3. To install the new brush, position the new
brush on the roller with the cleaning blades
facing away from the roller.
3
Figure 19. Install the New Brush
4. Thread each tab into the slot provided and
gently feed it through until the heel comes out
at the other side of the slot.
4
Figure 20. Pull Tabs Through Each Slot
5. Use a pair of scissors to cut the tabs 3/4 inch
from the heel so that they are no higher than
the cleaning blade.
6. Repeat the procedure to install the second
brush.
Figure 21. Cut Tabs
ENGLISH
Page 17
