Example 3 – Set Up the RouteFinder Going to
a VPN behind a NAT Device

Step 1 -- Network Setup

1. Log into your RouteFinder and go to the Networks & Services screen.
2. Create and enter in the Name, IP Address, and Subnet Mask of the Remote WAN.
3. Click the Add button to add the new network to the list.
4. Create and enter in the Name, IP Address, and Subnet Mask of the Remote LAN
5. Click Add to add the new network to the list
Multi-Tech Systems, Inc. RF825 Series IPSec VPN Setup Examples – A Reference Guide (S000440B)
Chapter 2 – Behind NAT Setup Examples
28
