Prerequisite Step 2 – Client Phase 1 Advanced
Setup (Behind NAT)
This screen displays after clicking the P1 Advanced button on the previous screen.
1.
Select the IP Address from the drop down list box for the Local ID.
2.
Then enter the IP address of the VPN Client in the text box labeled Set the value for the ID
field. Example: 192.168.2.8
3.
Select IP Address for the Remote ID.
4.
Then enter the IP address of the RouteFinder in the Set the value for the ID field. Example:
65.126.90.248
5.
Click OK.
