5. Select the DNS tab, and set up the Gatekeeper for Internet
communications.
6. Click OK to save your settings and exit the Microsoft TCP/
IP Properties dialog box.
7. Click OK to exit the Network dialog box.

Gatekeeper Software Setup

The Gatekeeper software is installed with a default 20-user
license file. For additional user licenses, contact Multi-Tech
Sales at 888-288-5470 (U.S./Canada) or +763-785-3500. When
ordering, you will need the Gatekeeper software Product ID
code, which you can obtain by clicking About MultiVOIP
Gatekeeper in the Help menu. When you receive the new li-
cense file, simply copy it to the Gatekeeper installation folder
to install it. The default installation folder is C:\Program
Files\Multi-Tech Systems\MultiVOIP Gatekeeper.
If the license is not installed in the Gatekeeper installation
folder, an Expired License File Error message appears when
the Gatekeeper software is started. The error message includes
the Product ID needed to order a license file.
When the Gatekeeper software starts, it automatically searches
for all endpoints (MultiVOIPs) that point to the Gatekeeper's
IP address, and displays them in the Endpoints window. By
default, the registration policy is set for All endpoints. To re-
strict which endpoints can be registered, select Predefined
endpoints in the Main window. The quickest way to create
predefined properties is to select an endpoint in the Endpoints
window that has the properties you want, open the Online
Properties dialog box, and then click the Predefined Data but-
ton to change the online endpoint to a predefined endpoint.
For more information on how to use the Gatekeeper software,
see the online help or the MultiVOIP Gatekeeper Software User
Guide.
