- Page 1 Item No. : H0032 Contact Us : service@anmytek.com Charlotte Wide Media Console Cabinet or TV Stand ASSEMBLY AND CARE GUIDE 1 HOUR 2 PEOPLE 2 x 1 m ASSEMBLY TIME REQUIRED FOR ASSEMBLY FLOOR SPACE REQUIRED Contact Us : service@anmytek.com...
- Page 2 Item No. : H0032 Contact Us : service@anmytek.com SAFETY PRECAUTIONS PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT. Please check that all parts are present beforeyou start the assembly of your furniture. A Philips head screwdriver (not included) is required for the assembled of this product.
- Page 3 Item No. : H0032 Contact Us : service@anmytek.com PARTS LIST Contact Us : service@anmytek.com...
- Page 4 Item No. : H0032 Contact Us : service@anmytek.com ASSEMBLY DIAGRAM AFTER SALES SUPPORT If you have any general enquiries or require spare parts for this product, please feel free to contact us via the following email: Email: service@anmytek.com You can contact us for support at any time. We'll answer you in 24hrs.
- Page 5 Item No. : H0032 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 1. Attach 4 x foot pads (L) to 4 x legs (2). Insert legs to part (1) using 4 x double head screws (A). Turn the screws and legs clockwise to secure. Insert 4 x cam screws into holes as shown.
- Page 6 Item No. : H0032 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 3. Attach part (4) to assembled unit using 4 x screws (E). Tighten with a screwdriver. STEP 4. Insert 4 x barrel nuts (G) and secure 4 x bolts (H) to lock it as shown.
- Page 7 Item No. : H0032 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 5. Attach 2 x parts (J) to assembled unit using 8 x screws (F) as shown. Tighten with a screwdriver. STEP 6. Final assembly. Contact Us : service@anmytek.com...
