Anmytek David H0034 Assembly And Care Manual

2 doors tall storage cabinet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Item No. : H0034
Contact Us : service@anmytek.com
David 2 Doors Tall
Storage Cabinet
ASSEMBLY AND CARE GUIDE
1 HOUR
2 PEOPLE
2 x 1 m
ASSEMBLY TIME
REQUIRED FOR ASSEMBLY
FLOOR SPACE REQUIRED
1
Contact Us : service@anmytek.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the David H0034 and is the answer not in the manual?

Questions and answers

Related Manuals for Anmytek David H0034

Summary of Contents for Anmytek David H0034

  • Page 1 Item No. : H0034 Contact Us : service@anmytek.com David 2 Doors Tall Storage Cabinet ASSEMBLY AND CARE GUIDE 1 HOUR 2 PEOPLE 2 x 1 m ASSEMBLY TIME REQUIRED FOR ASSEMBLY FLOOR SPACE REQUIRED Contact Us : service@anmytek.com...

  • Page 2: Safety Precautions

    Item No. : H0034 Contact Us : service@anmytek.com SAFETY PRECAUTIONS PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT. Please check that all parts are present beforeyou start the assembly of your furniture. A Philips head screwdriver (not included) is required for the assembled of this product.

  • Page 3: Parts List

    Item No. : H0034 Contact Us : service@anmytek.com PARTS LIST 3.5x12mm 3.5x35mm Ax24 3.5x10mm Fx12 Gx12 Hx12 3.5x30mm 6x10mm Kx10 Lx12 3x12mm 3.5x35mm Mx12 3.5x10mm Contact Us : service@anmytek.com...

  • Page 4: Assembly Diagram

    Item No. : H0034 Contact Us : service@anmytek.com ASSEMBLY DIAGRAM AFTER SALES SUPPORT If you have any general enquiries or require spare parts for this product, please feel free to contact us via the following email: Email: service@anmytek.com You can contact us for support at any time. We'll answer you in 24hrs.

  • Page 5: Assembly Steps

    Item No. : H0034 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 1. Attach panel (5) to panel (1) using 2 x cam bolts (F) and 2 x cam locks (G). Attach panel (4) to panel (1) using 2 x wooden dowels (H), 2 x cam bolts (F) and 2 x cam locks (G).
  • Page 6 Item No. : H0034 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 3. Slide back side panel (6) into position as shown. Attach top panel (8) to assembled unit using 4 x wooden dowels (H), 4 x cam bolts (F) and 4 x cam locks (G). Tighten with a screwdriver.
  • Page 7 Item No. : H0034 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 5. Attach metal frame to the bottom of cabinet using 4 x bolts (J) and 6 x screws (K). Tighten with a hex key (I). STEP 6. Attach 2 x door handles (D) to door panels (10), (11) using 4 x screws (E). Attach door panels (10), (11) to assembled unit using 4 x door hinges (B), 24 x screws (A).
  • Page 8 Item No. : H0034 Contact Us : service@anmytek.com Is your cabinet door looking crooked or unevenly spaced? Then you’ve come to the right place. Follow the illustrations below to get your cabinet door aligned and ready for action. If your door is too low or too high...
  • Page 9 Item No. : H0034 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 7. Attach 12 x plastic wedges (L) to back side panels using 12 x screws (M). Tighten with a screwdriver. STEP 8. Attach 2 x safety straps (N) to the back of the cabinet as shown. Secure with 2 x screws (P). Fasten assembled cabinet to the wall using 2 x wall anchors (Q), 2 x screws (O).
  • Page 10 Item No. : H0034 Contact Us : service@anmytek.com WALL FIXING GUIDE NOTE: Supplied wall plugs are only suitable for use in masonry walls. If you have any doubts about using the correct plug for your wall, please seek professional advice. Failure of the product due to using incorrect fixings is the responsibility of the installer.
