Summary of Contents for Anmytek H0037
- Page 1 Contact Us: service@anmytek.com H0037 3 Drawers Storage Dresser Chest 2 x 1 m 1 HOUR 2 PEOPLE...
-
Page 2: Safety Precautions
Item No. : H0037 Contact Us : service@anmytek.com SAFETY PRECAUTIONS PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT. Please check that all parts are present beforeyou start the assembly of your furniture. A Philips head screwdriver (not included) is required for the assembled of this product. -
Page 3: Parts List
Item No. : H0037 Contact Us : service@anmytek.com PARTS LIST 3.5x30mm Ax25 Bx27 Cx27 3.5x10mm Dx32 3.5x45mm 6x35mm Kx12 3x10mm 3.5x35mm 3.5x10mm 3x12mm Tx12 Contact Us : service@anmytek.com... -
Page 4: Assembly Diagram
Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY DIAGRAM ⑪ ⑫ ⑦ ⑨ ⑩ ⑫ ⑨ ⑧ ⑬ ⑮ ⑭ ⑭ ⑮ ⑥ ② ⑤ ④ ① ③ AFTER SALES SUPPORT If you have any general enquiries or require spare parts for this product, please... -
Page 5: What You Need
For more help, you can send a message to our customer support email service@anmytek.com in any time. Ready? Ok, let’s get rolling! This should be very easy, just follow our simple instructions... - Page 6 Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 1. ④ ③ ② ① Attach part (2), (3), (4) to part (1) using 5 x cam bolts (C) and 5 x cam locks (B). Tighten with a screwdriver.
- Page 7 Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 3. ① Attach 2 x handles (E) to the drawer using 4 x screws (T). Tighten with a screwdriver. STEP 4. Attach rail (F) to the left side of drawer as shown and secure with 2 x screws (D).
- Page 8 Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY STEPS ⑧ ⑦ STEP 5. Find out the correct runners (I) and (J). Fix (I) on panel (7), (J) on panel (8) using 12 x screws (D). Don't mix (I) and (J). For the 6 x runners (I & J), the protruding edge at the silver button screw end is upward.
- Page 9 Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 7. ⑧ Attach the right side panel (8) to the assembled unit using 2 x wooden dowels (K), 4 x cam bolts (C) and 4 x cam locks (B) as shown. Tighten with a screwdriver.
- Page 10 Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 9. ⑬ ⑫ Turn the furniture upside down. Attach the bottom panel (13) to assembled unit using 4 x wooden dowels (K) and 4 x screws (H). Tighten with a screwdriver.
-
Page 11: Assembly Steps
Item No. : H0037 Contact Us : service@anmytek.com ASSEMBLY STEPS STEP 11. Attach 8 x plastic wedges (N) to the back panels using 8 x screws (O). Tighten with a screwdriver. STEP 12. Attach 2 x safety straps (Q) to the back panel of furniture using 2 x screws (S) as shown. - Page 12 Item No. : H0037 Contact Us : service@anmytek.com WALL FIXING GUIDE NOTE: Supplied wall plugs are only suitable for use in masonry walls. If you have any doubts about using the correct plug for your wall, please seek professional advice. Failure of the product due to using incorrect fixings is the responsibility of the installer.
