MultiModem Wireless Modem with Ethernet Interface
∗
Check Obtain IP Address Automatically and Obtain
DNS Server Address Automatically. If you check
these, then the DHCP function obtains the IP Address
automatically from the Ethernet wireless modem, or
∗
Check Use the Following IP Address and Use the
Following DNS Server Address. If you check these,
then enter the following addresses:
IP Address: 192.168.2.2
Subnet Mask: 255.255.255.0
Gateway: 192.168.2.1
Specify a DNS Server. For example, 205.171.3.65

Using AT Commands

Prerequisite Steps
In order to communicate directly with the internal cellular
module with AT commands, you first must disable PPP by
logging into the Web Management software:
1. From the workstation, open a Web browser.
Type the default Gateway Address: http://192.168.2.1
2. Login
After entering the Address, the Login screen displays.
•
Type the default User name: admin (all lower-case).
•
Type the default password: admin (all lower-case).
Note: User name and Password are case-sensitive
(both must be typed in lower-case). A password can
be up to 12 characters. If Windows displays the
AutoComplete screen, you may want to click No to
tell the Windows OS not to remember the password;
this helps maintain PC security.
•
Click the Login button. The Web Management Home
screen displays.
3. Go to the Wizard Setup Screen
•
On the Wizard Setup screen under PPP
Configuration, disable PPP.
•
Click the Submit button and then Save & Restart.
8 Multi-Tech Systems, Inc. Quick Start Guide
