VORON CopyMaster3D Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WWW.VORONDESIGN.COM
VORON
1.8 ASSEMBLY MANUAL
We build space shuttles with gardening tools
so anyone can have a space shuttle of their own.
VERSION 2020-10-25
1
www.copymaster3d.com
sales@copymaster3d.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CopyMaster3D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VORON CopyMaster3D

Summary of Contents for VORON CopyMaster3D

  • Page 1 WWW.VORONDESIGN.COM VORON 1.8 ASSEMBLY MANUAL We build space shuttles with gardening tools so anyone can have a space shuttle of their own. VERSION 2020-10-25 www.copymaster3d.com sales@copymaster3d.com...
  • Page 2 Please do not become the first VORON fatality. There is no special Reddit flair for that. Please, read the entire manual before you start assembly. As you begin wrenching, please check our Discord channels for any tips and questions that may halt your progress.

  • Page 3: Table Of Contents

    Introduction Afterburner Print Bed & Wire Path Hardware Frame Skirts & Bottom Compartment A/B Drive Electronics Compartment Front Idlers Electronics Gantry Rear Panel & Exhaust Panels Bed Frame Finishing Touches Z Axis X Axis Next Steps Belt Path www.copymaster3d.com sales@copymaster3d.com...

  • Page 4: Introduction

    PART PRINTING GUIDELINES The Voron Team has provided the following print guidelines for you to follow in order to have the best chance at success with your parts. There are often questions about substituting materials or changing printing standards, but we recommend you follow these.
  • Page 5 If you need assistance with your build, we’re here to help. Head on over to our Discord group and post your questions. This is our primary medium to help VORON Users and we have a great community that can help you out if you get stuck.

  • Page 6: Hardware

    SOCKET HEAD CAP SCREW (SHCS) Metric fastener with a cylindrical head PULLEY and hex drive. The most common GT2 pulley used on the motion system fastener used on the Voron. of the Voron. ISO 4762 HEX NUT SHIM Hex nuts couple with bolts to create a Not to be confused with stamped tight, secure joint.
  • Page 7 As the plastic cools, it solidifies around tramming and as a spacer. the knurls and ridges on the insert for excellent resistance to both torque and DIN 466-B pull-out. SELF TAPPING SCREW Fastener with a pronounced thread profile that is screwed directly into plastic. www.copymaster3d.com sales@copymaster3d.com...
  • Page 8 FRAME WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 9 WWW.VORONDESIGN.COM GETTING EXTRUSIONS TOGETHER Separate the extrusions you’re going to need for this section of the build. We’ve laid out all the parts you should have and highlighted the ones that will be used in the following sections. www.copymaster3d.com sales@copymaster3d.com...
  • Page 10 EXTRUSIONS WWW.VORONDESIGN.COM M5x16 BHCS PREPARE 10 EXTRUSIONS All 10 extrusions are going to be used in this section. Prepare them as shown to the left. www.copymaster3d.com sales@copymaster3d.com...
  • Page 11 UPSIDE DOWN ASSEMBLY For ease of assembly we recommend to assemble the frame upside down. Mind the position and orientation of the access hole on the vertical extrusions. www.copymaster3d.com sales@copymaster3d.com...
  • Page 12 We do our best to call out things that may bite you later in the assembly process but may skip things that seem obvious to us. If in doubt please refer to the CAD model, it might save you some considerable time down the road. www.copymaster3d.com sales@copymaster3d.com...
  • Page 13 The extrusions that will later hold the Y-Rails are spaced 90mm from the top extrusions (110mm from the work surface). Make sure that they sit flush with the vertical extrusions and aren’t twisted/rotated. A small machinist square will help with this task. www.copymaster3d.com sales@copymaster3d.com...
  • Page 14 Make sure that the extrusions sit at an 90° angle and are free of any rotation/twist. The outsides of the extrusions should be flush. The position of the front/back facing extrusion is not critical. www.copymaster3d.com sales@copymaster3d.com...
  • Page 15 FEET WWW.VORONDESIGN.COM M5x16 SHCS FLIP RIGHT-SIDE UP This concludes the first section of the assembly. Time to put the printer on it’s own feet. Don’t forget to take a photo of Rubber Foot your success. www.copymaster3d.com sales@copymaster3d.com...
  • Page 16 A/B DRIVE WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...

  • Page 17: A/B Drive

    Use thread locker on all grub screws. Loose grub screws account for the majority of issues that our users report. Save yourself hours of troubleshooting and apply thread locker to all grub screws during the build. See the products application notes for instructions. www.copymaster3d.com sales@copymaster3d.com...
  • Page 18 A DRIVE WWW.VORONDESIGN.COM UPSIDE DOWN ASSEMBLY For ease of assembly we recommend to assemble the A and B drives upside down. M5 Shim F695 Bearing M5x30 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 19 A DRIVE WWW.VORONDESIGN.COM M3x30 SHCS FLIPPED RIGHT SIDE UP Turn the part over www.copymaster3d.com sales@copymaster3d.com...
  • Page 20 B DRIVE WWW.VORONDESIGN.COM M3x30 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 21 B DRIVE WWW.VORONDESIGN.COM M3x30 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 22 A/B DRIVE WWW.VORONDESIGN.COM CHECK YOUR WORK Compare your assembled parts to the graphics shown here. Pay attention to the pulley orientation and alignment with the bearing stack ups. www.copymaster3d.com sales@copymaster3d.com...
  • Page 23 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 24 FRONT IDLERS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 25 TENSION ARMS WWW.VORONDESIGN.COM HEAT SET INSERTS M3 Heat Set Insert You will need to install heat set inserts into the tension arms. If you need help on the correct procedure, ask in Discord. M5 Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 26 A IDLER WWW.VORONDESIGN.COM M5 Shim F695 Bearing ASSEMBLY AID This screw is used to align components and will be removed in a later step. M5x40 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 27 A IDLER WWW.VORONDESIGN.COM M5x40 SHCS M3 Washer REMOVE ASSEMBLY AID Remove the screw and slide the tension arm into place. M3x40 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 28 B IDLER WWW.VORONDESIGN.COM F695 Bearing M5 Shim ASSEMBLY AID This screw is used to align components and will be removed in a later step. M5x40 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 29 WWW.VORONDESIGN.COM B IDLER M5x40 SHCS M3 Washer M3x40 SHCS REMOVE ASSEMBLY AID Remove the screw and slide the tension arm into place. www.copymaster3d.com sales@copymaster3d.com...
  • Page 30 FRONT IDLERS WWW.VORONDESIGN.COM CHECK YOUR WORK Compare your assembled parts to the graphics shown here. www.copymaster3d.com sales@copymaster3d.com...
  • Page 31 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 32 GRANTY WWW.VORONDESIGN.COM WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 33 B MOTOR MOUNTING WWW.VORONDESIGN.COM SLIDE INTO PLACE Loosen the screws and slide into place. www.copymaster3d.com sales@copymaster3d.com...
  • Page 34 A MOTOR MOUNTING WWW.VORONDESIGN.COM SLIDE INTO PLACE Slightly loosen the M5 screw and slide into place. www.copymaster3d.com sales@copymaster3d.com...
  • Page 35 REAR CROSSBAR WWW.VORONDESIGN.COM SLIDE INTO PLACE The rear crossbar can be slid into place. You may need to loosen the M5 screws. www.copymaster3d.com sales@copymaster3d.com...
  • Page 36 WWW.VORONDESIGN.COM PRELOAD T NUTS You won’t be able to access this spot after the rails are installed. Preinstall and align 1 M5 T Nut and 1 M3 T Nut now. M5 T-Nut M3 T-Nut M5x10 BHCS M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 37 FRONT IDLER MOUNTING WWW.VORONDESIGN.COM SLIDE INTO PLACE M5x10 BHCS Slightly loosen the M5 screw and slide into place. www.copymaster3d.com sales@copymaster3d.com...
  • Page 38 USE A BALL END DRIVER The top extrusion will block access for a regular straight driver. CENTERED RAIL INSTALLATION GUIDE Use the guides to position the rail in the center of the extrusion prior to fastening the screws. www.copymaster3d.com sales@copymaster3d.com...
  • Page 39 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 40 BED FRAME WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 41 BED FRAME WWW.VORONDESIGN.COM M5x16 BHCS www.copymaster3d.com sales@copymaster3d.com...

  • Page 42: Bed Frame

    Bearings are usually shipped in a rust prevention oil . Clean LM8LUU Bearing and properly lubricate prior to installation. FLUSH WITH BOTTOM Insert the bearing all the way until it sits flush with the bottom of the part. www.copymaster3d.com sales@copymaster3d.com...
  • Page 43 BED FRAME WWW.VORONDESIGN.COM M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 44 BED FRAME WWW.VORONDESIGN.COM M5x16 BHCS CHECK YOUR WORK Compare your assembled parts to the graphics shown here. www.copymaster3d.com sales@copymaster3d.com...
  • Page 45 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 46 Z AXIS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 47 Z AXIS RODS WWW.VORONDESIGN.COM APPLY LUBRICATION A thin layer of lubrication will prevent rust. 8mm Shaft IMPROVISED STOPS Push the brackets onto the rods, they will prevent the rods from slipping out. www.copymaster3d.com sales@copymaster3d.com...

  • Page 48: Z Axis

    Insert the Z stage at an angle you’re having trouble installing to position all rods close to the Z stage installed their final place. If required loosen the bottom extrusion. Do not loosen the middle or top extrusions. www.copymaster3d.com sales@copymaster3d.com...
  • Page 49 Z AXIS WWW.VORONDESIGN.COM DON’T TIGHTEN M5x10 BHCS Leave the screws slightly loose for the next step. FLIP PRINTER UPRIGHT www.copymaster3d.com sales@copymaster3d.com...
  • Page 50 Move the bed carrier up and down to bring the other rods into position. Fasten their screws. Tweak the position of the rods 44mm distance to front extrusion until the axis moves freely without any binding. 44mm distance to front extrusion www.copymaster3d.com sales@copymaster3d.com...
  • Page 51 Z AXIS STEPPER MOTOR WWW.VORONDESIGN.COM M3x12 SHCS M3x12 SHCS Lead-screw Nut Lead-screw Nut M3 Nut APPLY LUBRICATION Apply a thin layer of grease to the lead-screw to prevent rust and ensure a smooth operation. M3x12 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 52 ALIGNMENT Position the lead-screw block in the LEAD-SCREW BLOCK center of the extrusion. Lift the bed carrier and Adjust the position of the motor fasten the lead-screw mount until the lead-screw is block to it. perpendicular. M5x16 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 53 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 54 X AXIS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 55 RIGHT XY JOINT WWW.VORONDESIGN.COM Heat Set Inserts HEAT SET INSERTS You will need to install heat set inserts into the XY joint. If you need help on the correct procedure, ask in Discord. www.copymaster3d.com sales@copymaster3d.com...
  • Page 56 RIGHT XY JOINT WWW.VORONDESIGN.COM F695 Bearing M5x1 Shim M5x40 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 57 RIGHT XY JOINT WWW.VORONDESIGN.COM M5x30 BHCS GT2 20T Idler DON’T OVER TIGHTEN The screw is used to position the idler and is screwed directly into plastic. The idler must spin freely. www.copymaster3d.com sales@copymaster3d.com...
  • Page 58 RIGHT XY JOINT WWW.VORONDESIGN.COM M5 Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 59 LEFT XY JOINT WWW.VORONDESIGN.COM F695 Bearing M5x1 Shim M5x40 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 60 LEFT XY JOINT WWW.VORONDESIGN.COM M5x30 BHCS DON’T OVER TIGHTEN The screw is used to position the idler and is screwed directly into plastic. The idler must spin freely. GT 20T Idler www.copymaster3d.com sales@copymaster3d.com...
  • Page 61 LEFT XY JOINT WWW.VORONDESIGN.COM M5 Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 62 This rail will become the forward facing rail. Linear Rails Loosely position the other rail and lightly fasten the screws. Rails will be aligned in a later step. www.copymaster3d.com sales@copymaster3d.com...
  • Page 63 X BEAM WWW.VORONDESIGN.COM LEAVE LOOSE Lightly tighten the screws. M5x16 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 64 X CARRIAGE WWW.VORONDESIGN.COM Microswitch M2x10 Self Tapping SOLDER WIRES NOW Heat Set Inserts Solder approx. 300mm of wire to the mircoswitch before installing it. See setup guide for details. www.copymaster3d.com sales@copymaster3d.com...
  • Page 65 X CARRIAGE WWW.VORONDESIGN.COM M3 Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 66 X CARRIAGE WWW.VORONDESIGN.COM M3x30 SHCS M3x30 SHCS LEAVE LOOSE Lightly tighten the screw. www.copymaster3d.com sales@copymaster3d.com...
  • Page 67 X CARRIAGE WWW.VORONDESIGN.COM M3x16 SHCS 3MM DISTANCE Fasten the screw until there is 3mm space between the screw head and the printed part. www.copymaster3d.com sales@copymaster3d.com...
  • Page 68 X CARRIAGE WWW.VORONDESIGN.COM PROBE WIRES Cut the probes wires to about 15cm. Heat Set Insert ENDSTOP WIRES Place the endstop wires into the same channel. Inductive Probe M3x20 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 69 X CARRIAGE MOUNTING WWW.VORONDESIGN.COM M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...

  • Page 70: Axis

    Move the X Carriage to check for any binding. Repeat until all screws are fully tight. If you get binding at any point slightly loosen the screws and retry. Refer to Discord if you are having issues with the alignment. www.copymaster3d.com sales@copymaster3d.com...
  • Page 71 BELT CLAMPS WWW.VORONDESIGN.COM Heat Set Insert M3x12 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 72 X AXIS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 73 X AXIS WWW.VORONDESIGN.COM M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 74 BELT PATH WWW.VORONDESIGN.COM WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...

  • Page 75: Belt Path

    BELT PATH WWW.VORONDESIGN.COM THE VORON BELT PATH Voron printers use a belt path based on the popular CoreXY pattern. The individual belt paths are stacked on top of each and the crossing often found in CoreXY designs is omitted. Compared the many other...
  • Page 76 BELT ROUTING WWW.VORONDESIGN.COM SOME EXTRUSIONS MISSING? We’ve hid some extrusions for better visibility. No need to disassemble anything. www.copymaster3d.com sales@copymaster3d.com...
  • Page 77 BELT ROUTING WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 78 BELT ROUTING WWW.VORONDESIGN.COM MIND THE BELT PATH Make sure that the belts are sitting on the bearing stacks. This may seem obvious but is easy to miss. www.copymaster3d.com sales@copymaster3d.com...
  • Page 79 Loosen the X Beam screws. Move the axis all the way forward until both XY Move the axis all the way back. Both XY Joints Joints touch the idlers. must touch the motor mounts. Tighten the screws on the xy joints. www.copymaster3d.com sales@copymaster3d.com...
  • Page 80 AFTERBURNER WWW.VORONDESIGN.COM WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 81 TOOL CARTRIDGE WWW.VORONDESIGN.COM AVAILABLE MOUNTS We also provide mounts for the Slice Engineering Mosquito and TriangleLab/Phaetus Dragon Hotend. They are assembled in a similar manner. Heat Set Insert E3D V6 Style Hotend M3x16 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 82 TOOL CARTRIDGE WWW.VORONDESIGN.COM PTFE Tube M3x40 SHCS PTFE STICKOUT The PTFE tube should end 10mm above the surface of the printed part. www.copymaster3d.com sales@copymaster3d.com...
  • Page 83 TOOL CARTRIDGE WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 84 CLOCKWORK WWW.VORONDESIGN.COM Heat Set Insert www.copymaster3d.com sales@copymaster3d.com...
  • Page 85 CLOCKWORK WWW.VORONDESIGN.COM BMG Drive Pinion Stepper Motor STEPPER WIRES If the steppers has wires cut them to approximately 150mm. Wires/connector to the right hand side. M3x8 SHCS M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 86 CLOCKWORK WWW.VORONDESIGN.COM BMG Thumb Screw Heat Set Insert BMG Idler Assembly LUBRICATE BEARINGS A light lubrication film will help with smooth operation and longevity. www.copymaster3d.com sales@copymaster3d.com...
  • Page 87 CLOCKWORK WWW.VORONDESIGN.COM BMG Drive Assembly CHECK BEARING FIT The bearings must slip on and off the shaft easily. Pressing the bearings on the shaft will damage them. Lightly sand the shaft if required. www.copymaster3d.com sales@copymaster3d.com...
  • Page 88 CLOCKWORK WWW.VORONDESIGN.COM M3x30 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 89 CLOCKWORK WWW.VORONDESIGN.COM M3x20 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 90 CLOCKWORK WWW.VORONDESIGN.COM PTFE Tube M3x6 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 91 CLOCKWORK WWW.VORONDESIGN.COM M3x30 SHCS M3x20 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 92 FAN ASSEMBLY WWW.VORONDESIGN.COM REMOVE TOP COVER Split the fan open by DON’T OVER TIGHTEN bending the taps on the The screws are screwd side. directly into plastic. M3x16 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 93 FAN ASSEMBLY WWW.VORONDESIGN.COM Piece of Filament www.copymaster3d.com sales@copymaster3d.com...
  • Page 94 FAN ASSEMBLY WWW.VORONDESIGN.COM M3x30 SHCS M3x12 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 95 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 96 PRINT BED & WIRE PATH WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 97 Y ENDSTOP WWW.VORONDESIGN.COM SOLDER WIRES Solder 500mm of wire to the microswitch before inserting it flush into the housing. M3x16 SHCS M5x16 BHCS Microswitch PRELOADED NUTS The nuts have been installed several chapters before. www.copymaster3d.com sales@copymaster3d.com...
  • Page 98 M2x10 Self Tapping Apply the required force to fully seat the pulley in the printed part. REMOVE FLANGE & GRUB SCREWS Use a bottle opener or some pliers to remove the top flange. Remove the grub screws from the pulley. www.copymaster3d.com sales@copymaster3d.com...
  • Page 99 Z ENDSTOP WWW.VORONDESIGN.COM 5mm Shaft M3x20 SHCS www.copymaster3d.com sales@copymaster3d.com...

  • Page 100: Afterburner

    CABLE CHAIN WWW.VORONDESIGN.COM FIXED END VS. FREE END Some cable chains only have one end that is able to swing freely. Use this end on the back of the Afterburner. M3x6 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 101 CABLE CHAIN WWW.VORONDESIGN.COM M3x6 BHCS FIXED END VS. FREE END If you cable chain as a fixed and use this end on the XY joint. www.copymaster3d.com sales@copymaster3d.com...
  • Page 102 A removable surface is recommended. Preinstalling the screws is possible but not recommended as those will interfere with the heater application. Read/watch a guide about the proper application if you are unsure. www.copymaster3d.com sales@copymaster3d.com...
  • Page 103 PRINT BED WWW.VORONDESIGN.COM HEATER APPLICATION Attach the heater to the bottom of the plate with wires facing away from the center hole. Read/watch a guide on heater installation if you are unsure about the procedure. Heater Pad Thermal Fuse www.copymaster3d.com sales@copymaster3d.com...
  • Page 104 PRINT BED WWW.VORONDESIGN.COM SCREW ACCESS HOLES Cut holes for the screws. M3x16 SHCS REPEAT FOR SECOND MOUNT M3 Shim M3 Thumb Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 105 PRINT BED WWW.VORONDESIGN.COM M3x40 SHCS Die Spring M3 Thumb Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 106 Z ENDSTOP WWW.VORONDESIGN.COM ADJUST Z ENDSTOP POSITION The shaft of the Z Endstop must not touch the print bed. Adjust the position if required. www.copymaster3d.com sales@copymaster3d.com...
  • Page 107 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 108 SKIRTS & BOTTOM COMPARTMENT WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 109 POWER INLET WWW.VORONDESIGN.COM Heat Set Insert Keystone Blank RJ45 Keystone Adapter RJ45 Keystone Adapter Power Inlet www.copymaster3d.com sales@copymaster3d.com...
  • Page 110 SKIRTS & DISPLAY WWW.VORONDESIGN.COM Heat Set Insert M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 111 DISPLAY WWW.VORONDESIGN.COM Mini12864 Display M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 112 SKIRTS WWW.VORONDESIGN.COM M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 113 SKIRTS WWW.VORONDESIGN.COM M3x8 SHCS M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 114 SKIRTS & DISPLAY WWW.VORONDESIGN.COM M3x8 SHCS M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 115 DECK PANEL WWW.VORONDESIGN.COM DIN Rail DECK PLATE DIMENSIONS Refer to Github for drawings and dimensions. M5x16 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 116 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 117 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 118 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 119 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM CUTOUT TOWARDS THE BACK The wires will be routed through the cutouts. Make sure they are pointing towards the back of the printer. www.copymaster3d.com sales@copymaster3d.com...
  • Page 120 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 121 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM DIN Rail M3x16 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 122 ELECTRONICS COMPARTMENT WWW.VORONDESIGN.COM M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 123 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 124 ELECTRONICS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 125 ELECTRONICS WWW.VORONDESIGN.COM SSR Din Mount M4x6 BHCS M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 126 ELECTRONICS WWW.VORONDESIGN.COM M2x10 Self Tapping M2x10 Self Tapping www.copymaster3d.com sales@copymaster3d.com...
  • Page 127 ELECTRONICS WWW.VORONDESIGN.COM M2x10 Self Tapping M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 128 ELECTRONICS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 129 ELECTRONICS WWW.VORONDESIGN.COM M4x6 BHCS M4x6 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 130 ELECTRONICS WWW.VORONDESIGN.COM M5x10 BHCS www.copymaster3d.com sales@copymaster3d.com...

  • Page 131: Electronics

    ELECTRONICS WWW.VORONDESIGN.COM SPRING LOADED Use a flat head screw driver to pull the latch open. It will lock open. Be careful when releasing the latch, it will snap back into place. Mind your fingers. www.copymaster3d.com sales@copymaster3d.com...
  • Page 132 ELECTRONICS WWW.VORONDESIGN.COM APPLY VHB TAPE 3M VHB tape is a double sided adhesive tape. Other vendors have similar products that you can use as a substitute. www.copymaster3d.com sales@copymaster3d.com...
  • Page 133 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 134 REAR PANEL & EXHAUST WWW.VORONDESIGN.COM WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 135 EXHAUST WWW.VORONDESIGN.COM Heat Set Insert www.copymaster3d.com sales@copymaster3d.com...
  • Page 136 EXHAUST WWW.VORONDESIGN.COM BSPP ADAPTER Some adapters have a small lip that prevents the PTFE tube from passing through. Inspect the adapter and if necessary use a drill to carefully remove the lip. www.copymaster3d.com sales@copymaster3d.com...
  • Page 137 EXHAUST WWW.VORONDESIGN.COM M3x8 SHCS M3x30 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 138 EXHAUST WWW.VORONDESIGN.COM APPLY VHB TAPE Filter Material VHB Tape is a double sided adhesive tape. www.copymaster3d.com sales@copymaster3d.com...

  • Page 139: Rear Panel & Exhaust

    HAMMERHEAD NUTS? A drop of thread locker will turn the M3x8 SHCS hammerhead nuts into a 1/4 turn quick release for the panels. Best done once the M3x8 SHCS assembly is finished. M3 Hammerhead Nut M3 Hammerhead Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 140 REAR PANEL WWW.VORONDESIGN.COM APPLY FOAM TAPE Use foam tape on the contact areas between the panels and the frame to mitigate noise from vibrations. www.copymaster3d.com sales@copymaster3d.com...
  • Page 141 WWW.VORONDESIGN.COM M3x12 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 142 REAR PANEL WWW.VORONDESIGN.COM M5x10 BHCS REMOVE TAPE BACKING www.copymaster3d.com sales@copymaster3d.com...
  • Page 143 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 144 PANELS WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 145 PANEL MOUNTS WWW.VORONDESIGN.COM APPLY FOAM TAPE Use foam tape on the M3x8 SHCS M3 Hammerhead Nut highlighted areas to mitigate noise from vibrations. www.copymaster3d.com sales@copymaster3d.com...
  • Page 146 TOP PANEL WWW.VORONDESIGN.COM APPLY FOAM TAPE Use foam tape on the contact areas between the panels and the frame to mitigate noise from vibrations. www.copymaster3d.com sales@copymaster3d.com...
  • Page 147 SIDE PANEL WWW.VORONDESIGN.COM WWW.VORONDESIGN.COM APPLY FOAM TAPE Use foam tape on the contact areas between the panels and the frame to mitigate noise from vibrations. www.copymaster3d.com sales@copymaster3d.com...

  • Page 148: Panels

    Magnets APPLY VHB TAPE MIND THE MAGNET POLARITY The parts will be bonded to the panels Ensure that the magnets are facing in the right using double-sided adhesive tape. direction prior to glueing them into place. M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 149 MIND THE MAGNET POLARITY Ensure that the magnets are facing in the right direction prior to glueing them into place. APPLY VHB TAPE The parts will be bonded to the panels using double-sided adhesive tape. M3x8 SHCS M3 Hammerhead Nut www.copymaster3d.com sales@copymaster3d.com...
  • Page 150 FRONT PANEL WWW.VORONDESIGN.COM M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 151 ELECTRONICS PANEL WWW.VORONDESIGN.COM ROTATE LEVERS TO LOCK Use the levers to lock and unlock the panel for the electronics M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 152 BOTTOM PANEL WWW.VORONDESIGN.COM M3x6 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 153 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...
  • Page 154 WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 155 SPOOL HOLDER WWW.VORONDESIGN.COM PTFE Tube M5x16 BHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 156 BOWDEN HOLDER & XY CAPS WWW.VORONDESIGN.COM M3x8 SHCS www.copymaster3d.com sales@copymaster3d.com...
  • Page 157 WWW.VORONDESIGN.COM This page intentionally left blank. www.copymaster3d.com sales@copymaster3d.com...

  • Page 158: Next Steps

    If you need assistance with your build, we’re here to help. Head on over to our Discord group and post your questions. This is our primary medium to help VORON Users and we have a great community that can help you out if you get stuck.
  • Page 159 WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...
  • Page 160 WWW.VORONDESIGN.COM VORON Website Github Discord vorondesign www.vorondesign.com https://github.com/ https://discord.gg/voron www.copymaster3d.com sales@copymaster3d.com...
  • Page 161 WWW.VORONDESIGN.COM www.copymaster3d.com sales@copymaster3d.com...

Table of Contents
