Thank you for using Moxa's UC-8580 Series computer. The UC-8580 Series computer is a programmable
communication-centric gateway offering a rich variety of communication interfaces such as Ethernet, serial,
and digital inputs/outputs. This EN 50155-compliant computer is built for rail applications and comes with
multiple wireless WAN gateway interfaces making it an ideal choice for building wireless communication
infrastructure with 802.11 a/b/g/n/ac, and for LTE data collection and transmission.
This computer runs on the Debian Linux operating system, providing a powerful communication platform
without generating too much heat, even when loaded with heavy application tasks. In addition, the mSATA
socket helps you easily expand the storage capacity for large-scale data acquisition.
The UC-8580 comes in two front-panel models to support two types of antenna connectors (SMA and QMA)
for wireless modules.
This chapter describes the product package checklist, product features, and hardware specifications.

Model Descriptions and Package Checklist

The UC-8580 Series comprises the following models:
UC-8580-LX: Programmable multiple-wireless computing platform for rail onboard applications,
•
supporting up to 4 wireless modules with SMA connectors, and a -25 to 55°C operating temperature
range
UC-8580-T-LX: Programmable multiple-wireless computing platform for rail onboard applications,
•
supporting up to 4 wireless modules with SMA connectors, and a -40 to 70°C operating temperature
range
UC-8580-T-CT-LX: Programmable multiple-wireless computing platform for rail onboard applications,
•
supporting up to 4 wireless modules with SMA connectors, and a -40 to 70°C operating temperature
range, and conformal coating
UC-8580-Q-LX: Programmable multiple-wireless computing platform for rail onboard applications,
•
supporting up to 4 wireless modules with QMA connectors, -25 to 55°C operating temperature range
UC-8580-T-Q-LX: Programmable multiple-wireless computing platform for rail onboard applications,
•
supporting up to 4 wireless modules with QMA connectors, -40 to 70°C operating temperature range
UC-8580-T-CT-Q-LX: Programmable multiple-wireless computing platform for rail onboard
•
applications, supporting up to 4 wireless modules with QMA connectors, with -40 to 70°C operating
temperature range and conformal coating
The UC-8580 Series computer is shipped with the following items:
UC-8580 Series computer
•
CBL-4PINDB9F-100: 4-pin pin header to DB9 female console port cable, 100 cm
•
• Quick Installation Guide (printed)
Warranty card
•
UC-8580 Series Hardware User Manual
