- Page 1 INJ-24A Series Quick Installation Guide Moxa High-power PoE+ Injector Version 4.4, March 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802000240027 *1802000240027*...
-
Page 2: Package Checklist
Overview The Moxa INJ-24A Series high-power PoE+injector is a 1-port PoE+ injector that delivers both data and electrical power to Ethernet- enabled devices using a single Ethernet cable. The INJ-24A can supply up to 36 watts of power in 2-pair mode or 60 watts in 4-pair mode through the Ethernet port, and can power IEEE 802.3af/at compliant powered devices (PD), such as wireless access points or IP cameras, eliminating the need for additional wiring. -
Page 3: Panel Layout
Rugged Design • Active PoE short-circuit and current-overloading protections • Auto PoE device detection and classification • 3 KV PoE surge resistance • Redundant dual power inputs • Operating temperature range from 0 to 60°C, or extended operating temperature from -40 to 75°C for “T” models •... -
Page 4: Mounting Dimensions (Unit = Mm)
Mounting Dimensions (unit = mm) - 4 -... -
Page 5: Din Rail Mounting
DIN-rail Mounting The DIN rail attachment plate should already be fixed to the back panel of INJ-24A when you take it out of the box. If you need to reattach the DIN Rail attachment plate, make sure the stiff metal spring is situated towards the top, as shown in the figures below. -
Page 6: Wiring Requirements
STEP 3: Once the screws are fixed on the wall, insert the four screw heads through the large parts of the keyhole-shaped apertures, and then slide the EDS downwards, as indicated. Tighten the four screws for added stability. Grounding the INJ-24A Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). - Page 7 WARNING Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa PoE injector. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size.
-
Page 8: Dip Switch Settings
DIP Switch Settings The default setting for each DIP switch is OFF. The following table explains the effect of setting the DIP switches to the ON positions. Setting Description Max Output Switch Power The INJ-24A is forced to 802.3af 802.3af mode and only 15.4 watts (ON) accepts IEEE 802.3af standard... -
Page 9: Specifications
Smart PoE LED Indicators Two Smart PoE LEDs indicate the current status between PSE and PD and the power output mode of the INJ-24A. The following table shows the details about these Smart PoE LEDs. Color State Description Power is being supplied to power input P1 /P2 P1, P2 Amber... - Page 10 Power Input Voltage 24/48 VDC (22 to 57 VDC), redundant dual inputs Input Current 2.71 A @ 24 VDC (with full 60 W PoE loading) 1.37 A @ 48 VDC (with full 60 W PoE loading) Power Consumption Max. 5.29 W (with full loading excluding PD’s consumption) Inrush Current 15.64 A @ 48 VDC (0.1-1ms)
