118
TFK 135 SLIM
COD. TFK-135-SLIM-B - PURE BRONZE
COD. TFK-135-SLIM-W - PEARL WHITE
COD. TFK-135-SLIM-R - ROSE GOLD
BREVETTATO
PATENTED
MOTORE
MOTOR
VELOCITÀ
SPEED
PIANO DI CORSA
RUNNING BOARD
SISTEMA AMMORTIZZANTE
SHOCK ABSORPTION SYSTEM
CONSOLE
copri motore
Informazioni: velocità, distanza, tempo,
consumo calorico, steps
CONSOLE
panel. Functions: speed, distance, time, calories, steps
DOTAZIONI
smartphone/tablet.Telecomando con tasti +/- e start/stop.
Casse acustiche Bluetooth
EQUIPMENT
smartphone/tablet holder. Remote control
with speed +/- and start/stop buttons.
SALVASPAZIO
SPACE SAVING
SISTEMA AUTOMATICO DI
LUBRIFICAZIONE NASTRO
AUTOMATIC BELT LUBRICATION SYSTEM
tapis roulant - salvaspazio
treadmills - space saving
1,50/2,50 (Peak) HP DC
1,50/2,50 (Peak) HP DC
0,8 - 8,0 Km/h con incremento di 0,1 km/h
0,8 - 8,0 Km/h with 0,1 km/h increasing
400 x 1120 mm - spessore nastro 1,6 mm
400 x 1120 mm - belt thickness 1,6 mm
4 elastomeri
4 cushions
4 display LED bianchi sul pannello
4 white LED displays on the motor
corrimani di sicurezza rimovibili. Supporto per
removable safety handlebars included.
735x145x1570 mm
735x145x1570 mm
NEW
Cod. TFK-135-SLIM-B
Cod. TFK-135-SLIM-W
Cod. TFK-135-SLIM-R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Everfit NEW TFK 135 SLIM
Summary of Contents for Everfit NEW TFK 135 SLIM
- Page 1 tapis roulant - salvaspazio treadmills - space saving TFK 135 SLIM COD. TFK-135-SLIM-B - PURE BRONZE COD. TFK-135-SLIM-W - PEARL WHITE COD. TFK-135-SLIM-R - ROSE GOLD BREVETTATO PATENTED Cod. TFK-135-SLIM-B MOTORE 1,50/2,50 (Peak) HP DC MOTOR 1,50/2,50 (Peak) HP DC VELOCITÀ...
- Page 2 INSTRUCTION Ed : 08/20 Rev : Cod: GRLDEVETFK135S...
-
Page 3: Product Brief
1. Product Brief Main technical parameters Parameters Names Description AC220-240V（50-60Hz） Input voltage Motor power 0.85CHP Speed 0.8-8 Km/h Running surface 405*1100 mm Max user weight 90KG Net weight 33kg Expand dimensions 1380*720*1030mm Packing list units Name Complete machine Storage box Rotation knob Accessory bag Accessory bag list... -
Page 4: Installation Instructions
3. Installation Instructions 1. Put the machine flat on the ground. Stand the upright columns according to the direction showing in the pictures bellow. 2. Find the rotation knobs in the accessory bag and use them to lock the two sides of the upright columns. -
Page 5: Using Instructions
4. Using Instructions Using walking pad 1. Insert the power plug properly and turn on the switch(in red color)(1). When the light is on, there will be a beep sound. (Note: The switch is on the right side of the machine.) 2. - Page 6 4. Display Function 4.1 LED window display Steps Display: Display the current steps. Calorie display:Display the current calorie. Time Display:Display the current time. Distance display:Display the current distance. Speed display: Display the current speed. 4.2 Control button function Start/Stop: In stop state, press this button to start the walking pad. In running state, press this button to stop the waling pad.
-
Page 7: Routine Maintenance
5. Routine maintenance Warning: Before cleaning or maintaining products, please be sure the power plug of the walking board is pulled out. Cleaning: Comprehensive cleaning will extend the using life of the electric walking board. Remove dust periodically in order to keep the parts clean. Be sure to clean walking belt with both sides of the exposed portion, which will reduce the accumulation of impurities. - Page 8 Applying silicone oil Step 1: Use scissors to cut the upper end of the oil bottle (Picture 1). Step 2: Uncover the oil tank cover located on the motor cover(Picture 2 and 3). Step 3: Squeeze the silicone oil into the oil tank(Picture 4). Step 4: Start the walking board, adjust the speed to 5-6 km/h, and run for 5 minutes to make the oil evenly distributed on the walking belt.
- Page 9 GARLANDO SPA Via Regione Piemonte, 32 - Zona Industriale D1 15068 - Pozzolo Formigaro (AL) - Italy www.everfit.it - info@everfit.it...
