DYN-6106-01 / GDI-6106-01/ GDI-6109-01
OWNER'S MANUAL
CARBON MODEL SAUNAS
FOR INDOOR USE ONLY
120VAC 15 AMP Dedicated Circuit Required
Carefully and thoroughly read this Owner's Manual before using/operating
the sauna. We recommend keeping this Owner's Manual for regular review
and future reference.
1 – 2 Person Model Saunas
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DYN-6106-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dynamic Saunas DYN-6106-01

Summary of Contents for Dynamic Saunas DYN-6106-01

  • Page 1 DYN-6106-01 / GDI-6106-01/ GDI-6109-01 1 – 2 Person Model Saunas OWNER’S MANUAL CARBON MODEL SAUNAS FOR INDOOR USE ONLY 120VAC 15 AMP Dedicated Circuit Required Carefully and thoroughly read this Owner’s Manual before using/operating the sauna. We recommend keeping this Owner’s Manual for regular review...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Packing List Visual Assembly Diagrams Parts Description Assembly Instructions Operating the Sauna Tips for Using Your Sauna Safety Instructions Safeguards for Your Sauna Troubleshooting Guide Warranty Warranty Card WARNING: Visually inspect all heaters before assembly to make sure they are not damaged.
  • Page 3 What Are Infrared Rays? Infrared is the band of light we perceive as heat. We cannot see this band of light with the naked eye, but we can feel this type of light in the form of heat. Our sun produces most of its energy output in the infrared segment of the spectrum.
  • Page 4 EMF Levels from Common Homes Sources After many years and numerous studies on EMF exposure, no government body including the Occupational Safety and Health Administration (OSHA) have established permissible exposure limits (PEL). Currently, there is no consensus on the potential health hazard from any exposure to EMF.
  • Page 5 HOW IT WORKS Infrared Saunas differ from traditional saunas in that they use infrared radiant energy to directly penetrate into the body's tissue to produce perspiration. Traditional saunas use steam to heat the air inside the sauna, which then heats your body until you begin to perspire.

  • Page 6: Visual Assembly Diagrams

    *PLEASE READ INSTRUCTIONS BEFORE ASSEMBLY* Visual Assembly Diagram DYN-6106-01/GDI-6106-01 *The above assembly diagram i s for a quick reference visual guide only. All sauna models are not shown. Parts and accessories may vary and are subject to change. Backrests are sold separately. We have found that starting the assembly process with the floor and front wall panel first may be the easiest, but it is not mandatory.
  • Page 7 *PLEASE READ INSTRUCTIONS BEFORE ASSEMBLY* Visual Assembly Diagram GDI-6109-01 *The above assembly diagram i s for a quick reference visual guide only. All sauna models are not shown. Parts and accessories may vary and are subject to change. Backrests are sold separately. We have found that starting the assembly process with the floor and front wall panel first may be the easiest, but it is not mandatory.

  • Page 8: Parts Description

    PARTS DESCRIPTION DYN-6106-01/GDI-6106-01 NOTE: The pictures and diagrams shown within this owner’s manual are representations of this model. Actual model may vary. Design and Construction are subject to change. Backrests are sold separately.
  • Page 9 PARTS DESCRIPTION GDI-6109-01 NOTE: The pictures and diagrams shown within this owner’s manual are representations of this model. Actual model may vary. Design and Construction are subject to change. Backrests are sold separately.
  • Page 10 Highlights Power Supply (Control Box) The POWER SUPPLY is the control center of the sauna room. It is installed on the topside of the ROOF PANEL and has inputs/outputs connected to it. (see Figure 1) Figure 1 POWER IN - main power of the sauna room HT1, HT2, HT3, HT4, HT5, HT6 –...
  • Page 11 III. MP3 Auxiliary Port The MP3 Auxiliary Port allows you to connect a MP3 player or other device with the auxiliary function to the speakers in the sauna room for your listening pleasure. (see Figure 2) Figure 2 Buckles External Buckles The external buckles are used to connect the LEFT and RIGHT SIDE PANELS to the REAR PANEL.
  • Page 12 When the floor panel faces upward, you will find (2) raised moldings, one along what will be the front and one along what will be the rear of the sauna room. (see figure 5) FLOOR HEATER DYN-6106-01/GDI-6106-01 GDI-6109-01 FRONT OF SAUNA FRONT OF SAUNA Figure 5 B.

  • Page 13: Assembly Instructions

    HEATER CORDS MOLDING Figure 6 C. Rear Panel The rear panel is the panel with the buckles. The buckles are mounted on the outside of the rear panel. (see figure 7) Figure 7 D. Understanding The Difference Between The Inside And Outside Of The Rear Panel You will find the heat emitters on the inside of the rear panel.
  • Page 14 C. Installing the FRONT PANEL and SIDE PANELS 1. Place the FRONT PANEL onto the recessed area on the FLOOR PANEL. For model DYN-6106-01 and GDI-6106-01, align guides on the RIGHT SIDE PANEL with the guide inserts on the FRONT PANEL. The RIGHT SIDE PANEL will need to be lifted in order to lock the guide inserts on the FRONT PANEL into the guides on the RIGHT SIDE PANEL.
  • Page 15 Figure 8 Figure 9 D. Installing the REAR PANEL 1. Remove the protection paper from the buckles (tape). Place the REAR PANEL onto the recessed area on the FLOOR PANEL. Attach the REAR...
  • Page 16 PANEL to the SIDE PANELS and buckle together. (see figure 10) Figure 10 E. Installing the FLOOR EMITTER PANEL, BENCH EMITTER PANEL, and BENCH 1. Place the FLOOR EMITTER PANEL on the FLOOR PANEL and towards the front of the sauna. The cord will be toward the rear of the sauana. (see figure 11 &...
  • Page 17 down until it is touching the FLOOR PANEL and is secured in place. 3. Plug in the BENCH EMITTER connector to the inlet located on the REAR PANEL. 4. Install the BENCH by sliding it over the horizontal bench guides on the side panels.
  • Page 18 Figure 13 Figure 14 H. Installing the TEMPERATURE SENSOR 1. Enter the sauna and remove the protective covering from the TEMPERATURE SENSOR. Situate the TEMPERATURE SENSOR so that it is vertical, pointing downward. (see figure 15) Figure 15 Note: Some sauna models are shipped with a spare TEMPERATURE SENSOR in case the TEMPERATURE SENSOR is damaged in transit.
  • Page 19 I. Putting on the ROOF COVER 1. Place the ROOF COVER over the top of the sauna. Be cautious when pulling the power cord through the hole in the roof cover. Gently place the ROOF COVER onto the ROOF PANEL. When the edges are aligned, screw the ROOF COVER to the roof panel.

  • Page 20: Operating The Sauna

    Operating the Sauna NOTE: Before the sauna is turned on, remove plastic protective covering from the CONTROL PANELS. Please check and confirm that the connections to the POWER SUPPLY (including the power cord), HEAT EMITTERS, CD/RADIO, and TEMPERATURE SENSOR are connected properly and are snug and tight. The power supply voltage and frequency must match the requested voltage and frequency of the sauna (120VAC 15AMP Dedicated Circuit or 120VAC 20AMP Dedicated Circuit).
  • Page 21 the control panel will flash. 3. Press the up/down arrows under the TIME DISPLAY to adjust the amount of time you want the sauna to remain on. Press the C/F button to choose between Celsius and Fahrenheit. Press the up/down arrows under the TEMPERATURE DISPLAY to adjust the temperature setting.
  • Page 22 You can use the SHADE button on the remote to go through a sequence of colors. If you want to turn the light off during your sauna session, you can press the POWER button on the remote. Please note: You must be inside the sauna room for the remote to work.

  • Page 23: Tips For Using Your Sauna

    Please keep in mind that you can either preheat the sauna to the set temperature before entering or sit inside the sauna as the temperature rises. In addition, you will increase the time it takes for the sauna to reach the set temperature if you enter the sauna room before it has reached the set temperature.

  • Page 24: Safety Instructions

    5. This is a non-commercial sauna. For every three hours ON, the sauna must be turned OFF for one hour to cool down. 6. At the first sign of a cold or flu, increasing your sauna sessions may be beneficial in boosting your immune system and decreasing the reproductive rate of the virus.
  • Page 25 physical injuries. 8. Persons suffering from obesity or with a medical history of heart disease, low or high blood pressure, circulatory system problems, diabetes, or other medical conditions should consult with a medical physician prior to using the sauna. 9. Persons using medications should consult with a medical physician before using the sauna.

  • Page 26: Safeguards For Your Sauna

    pose a safety risk. 23. Do not make any modifications to the sauna, the sauna structure, or the sauna components. 24. Prior to each sauna session, the sauna room is to be inspected for correct operation. If for any reason your sauna does not seem to be operating properly, discontinue use and contact Customer Service.
  • Page 27 connected, including the cord to the heat emitter underneath the bench (if applicable). Go to the roof, and also check that the heat emitter cords are properly connected snug and tight to the cords on the roof and that those cords are properly plugged into the power supply (snug and tight).
  • Page 28 damaged, then unplug the sauna immediately and contact the Customer Service. Solution: The control panel will not turn off, the power/work/or heat lights do not come on, or the temperature and timer buttons do not work means the control panel may have been damaged and will need to be replaced. Before contacting Customer Service, remove the wood frame holding the control panel in place to gain access to the “CTRL”...
  • Page 29 3. Also and while up on the roof, please located the temperature sensor wire. The temperature sensor is the black probe that is sticking out of the interior ceiling above your head as you sit on the bench. Disconnect the connection and reconnect to make sure the connection is snug and tight.
  • Page 30 outlet. You will need to contact Customer Service if the power supply cord is damaged as the power supply will need to be replaced. 6. Bluetooth Solution: Please note that you can only have a single device connected to the Bluetooth at any given time. You must unpair your device before connecting with another device.
  • Page 31 receptacles when the sauna is in operation. Both of these options are acceptable. 10. Lower Heat Emitters Solution: With regards to the lower heat emitters under the bench and on the floor, these heat emitters operate a bit different than the wall heat emitters.
  • Page 32 a second person should be able to latch the buckles. Make sure that the wall is fitting together like a puzzle as one wall panel fits into the other. Work your way down from top to bottom. 12. Too Much Perspiration On The Floor Heater Solution: Use 2 towels during your sauna session.
  • Page 33 Limited Lifetime Warranty 5 Year Limited Warranty: Golden Designs, Inc. under the Dynamic brand name warranties the wood, structure, heating elements, and electronics against defects in material and workmanship for a period of 1 to 5 years from the original date of purchase. This sauna is for INDOOR use only.

  • Page 34: Warranty

     Outdoor applications  Normal wear and tear or weathering  Use of product not in accordance with instructions  Worn out receptacle Surface cracks are not considered defects in material or workmanship, as they are normal characteristics of all woods. This includes minor cracks due to wood expansion and contraction.

  • Page 35: Warranty Card

    WARRANTY CARD Congratulations on your purchase of an Infrared Sauna from Golden Designs, Inc. Please take the time to complete the following Warranty Card and mail it back to: Golden Designs, Inc. 3550 Jurupa Street, Unit B Ontario, CA 91761 Please include a copy of your sales receipt showing date of purchase as this will serve as proof of purchase.
