Icom IC-9700 Service Manual Addendum page 9

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C502 4030019120 S.CER GRM188B31E105KA75D
C505 4030021580 S.CER GRM188B31E225KA12D
C508 4030023010 S.CER 0402B104K160CT
C510 4030019120 S.CER GRM188B31E105KA75D
C512 4030023010 S.CER 0402B104K160CT
C513 4030023010 S.CER 0402B104K160CT
C514 4030019120 S.CER GRM188B31E105KA75D
C515 4030023010 S.CER 0402B104K160CT
C516 4030023010 S.CER 0402B104K160CT
C517 4030023010 S.CER 0402B104K160CT
C518 4030019120 S.CER GRM188B31E105KA75D
C531 4030019560 S.CER GRM21BB31C106KE15L
C532 4030019560 S.CER GRM21BB31C106KE15L
C533 4030019560 S.CER GRM21BB31C106KE15L
C534 4030019560 S.CER GRM21BB31C106KE15L
C535 4030023010 S.CER 0402B104K160CT
C536 4030023010 S.CER 0402B104K160CT
C537 4030023010 S.CER 0402B104K160CT
C538 4030023010 S.CER 0402B104K160CT
C539 4030023010 S.CER 0402B104K160CT
C540 4030023010 S.CER 0402B104K160CT
C541 4030023010 S.CER 0402B104K160CT
C542 4030023010 S.CER 0402B104K160CT
C543 4030023010 S.CER 0402B104K160CT
C544 4030023820 S.CER 0603B104K250CT
C545 4030023010 S.CER 0402B104K160CT
C546 4030023010 S.CER 0402B104K160CT
C547 4030023010 S.CER 0402B104K160CT
C548 4030019560 S.CER GRM21BB31C106KE15L
C549 4030019560 S.CER GRM21BB31C106KE15L
C550 4030019560 S.CER GRM21BB31C106KE15L
C551 4030019560 S.CER GRM21BB31C106KE15L
C552 4030023010 S.CER 0402B104K160CT
C553 4030023010 S.CER 0402B104K160CT
C554 4030023010 S.CER 0402B104K160CT
C555 4030023010 S.CER 0402B104K160CT
C556 4030023010 S.CER 0402B104K160CT
C557 4030023010 S.CER 0402B104K160CT
C558 4030023010 S.CER 0402B104K160CT
C559 4030023010 S.CER 0402B104K160CT
C560 4030023010 S.CER 0402B104K160CT
C561 4030023010 S.CER 0402B104K160CT
C1001 4030020190 S.CER GRM32EB31C476KE15L
C1002 4030023010 S.CER 0402B104K160CT
C1003 4030023010 S.CER 0402B104K160CT
C1004 4030020190 S.CER GRM32EB31C476KE15L
C1005 4030020190 S.CER GRM32EB31C476KE15L
C1007 4030023010 S.CER 0402B104K160CT
C1008 4030021580 S.CER GRM188B31E225KA12D
C1012 4030019560 S.CER GRM21BB31C106KE15L
C1013 4030019560 S.CER GRM21BB31C106KE15L
C1021 4030023030 S.CER 0402B103K250CT
C1022 4030019120 S.CER GRM188B31E105KA75D
C1023 4030019560 S.CER GRM21BB31C106KE15L
C1031 4030023030 S.CER 0402B103K250CT
C1032 4030019120 S.CER GRM188B31E105KA75D
C1033 4030019560 S.CER GRM21BB31C106KE15L
C1041 4030022050 S.CER GRM21BR61C226ME44L
C1042 4030023010 S.CER 0402B104K160CT
C1043 4030023010 S.CER 0402B104K160CT
C1044 4030023030 S.CER 0402B103K250CT
C1045 4030023210 S.CER 0402B472K500CT
C1046 4030022050 S.CER GRM21BR61C226ME44L
C1047 4030022050 S.CER GRM21BR61C226ME44L
C1049 4030023010 S.CER 0402B104K160CT
C1050 4510010570 S.ELE 16 CE 470 LX
C1071 4030019120 S.CER GRM188B31E105KA75D
C1072 4030019560 S.CER GRM21BB31C106KE15L
C1091 4510010460 ELE DXN-5R5H334U
C1092 4030019120 S.CER GRM188B31E105KA75D
C1093 4030019560 S.CER GRM21BB31C106KE15L
C1101 4030020190 S.CER GRM32EB31C476KE15L
C1102 4030023010 S.CER 0402B104K160CT
C1103 4030023010 S.CER 0402B104K160CT
C1104 4030023010 S.CER 0402B104K160CT
C1106 4030020190 S.CER GRM32EB31C476KE15L
C1107 4030020190 S.CER GRM32EB31C476KE15L
C1108 4030022810 S.CER 0402N330J500CT
C1109 4030023010 S.CER 0402B104K160CT
C1111 4030020190 S.CER GRM32EB31C476KE15L
C1112 4030023010 S.CER 0402B104K160CT
C1113 4030023010 S.CER 0402B104K160CT
C1114 4030023030 S.CER 0402B103K250CT
C1115 4030023030 S.CER 0402B103K250CT
C1116 4030022050 S.CER GRM21BR61C226ME44L
C1117 4030022050 S.CER GRM21BR61C226ME44L
C1119 4030019120 S.CER GRM188B31E105KA75D
C1120 4030023010 S.CER 0402B104K160CT
C1121 4030019120 S.CER GRM188B31E105KA75D
C1122 4030019120 S.CER GRM188B31E105KA75D
C1131 4030019120 S.CER GRM188B31E105KA75D
C1132 4030019120 S.CER GRM188B31E105KA75D
C1141 4030019120 S.CER GRM188B31E105KA75D
C1142 4030019560 S.CER GRM21BB31C106KE15L
C1201 4030020190 S.CER GRM32EB31C476KE15L
C1202 4030023010 S.CER 0402B104K160CT
C1203 4030023010 S.CER 0402B104K160CT
C1204 4030023010 S.CER 0402B104K160CT
C1206 4030020190 S.CER GRM32EB31C476KE15L
C1207 4030020190 S.CER GRM32EB31C476KE15L
C1208 4030022810 S.CER 0402N330J500CT
C1209 4030020190 S.CER GRM32EB31C476KE15L
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 129.8/120.2 C1211 4030020190 S.CER GRM32EB31C476KE15L
T 130.8/115.5 C1212 4030023010 S.CER 0402B104K160CT
T 142.0/101.3 C1214 4030019120 S.CER GRM188B31E105KA75D
T 143.5/105.7 C1216 4030022050 S.CER GRM21BR61C226ME44L
T 142.0/100.4 C1217 4030022050 S.CER GRM21BR61C226ME44L
T 142.0/103.8 C1218 4030022810 S.CER 0402N330J500CT
T 143.5/101.1 C1221 4030019560 S.CER GRM21BB31C106KE15L
T 144.6/101.1 C1223 4550007520 S.TAN F931A106MAABMA
T 140.8/112.5 C1231 4030021580 S.CER GRM188B31E225KA12D
T 132.7/112.5 C1232 4030021580 S.CER GRM188B31E225KA12D
T 136.7/96.9 C1241 4030019120 S.CER GRM188B31E105KA75D
B 135.5/100.8 C1242 4030019560 S.CER GRM21BB31C106KE15L
B 142.5/101.3 C1246 4030019120 S.CER GRM188B31E105KA75D
B 129.0/101.6 C1247 4030019560 S.CER GRM21BB31C106KE15L
T 125.0/113.7 C1251 4030019120 S.CER GRM188B31E105KA75D
T 127.0/103.5 C1252 4030019560 S.CER GRM21BB31C106KE15L
T 127.3/112.5 C1261 4030023010 S.CER 0402B104K160CT
T 128.2/112.5 C1262 4030023090 S.CER 0402B102K500CT
T 142.0/109.7 C1331 4030023030 S.CER 0402B103K250CT
T 142.0/108.8 C1332 4030019120 S.CER GRM188B31E105KA75D
T 142.0/102.2 C1333 4030019560 S.CER GRM21BB31C106KE15L
T 142.0/107.0 C1501 4030023010 S.CER 0402B104K160CT
T 137.2/112.5 C1502 4030022630 S.CER 0402N100C500CT
T 134.5/112.5 C1521 4030023010 S.CER 0402B104K160CT
B 136.4/105.2 C1531 4030019560 S.CER GRM21BB31C106KE15L
T 130.0/112.5 C1532 4030019560 S.CER GRM21BB31C106KE15L
T 134.5/97.5 C1533 4030019560 S.CER GRM21BB31C106KE15L
T 135.5/97.5 C1534 4030019560 S.CER GRM21BB31C106KE15L
B 136.3/113.5 C1535 4030019560 S.CER GRM21BB31C106KE15L
B 138.8/105.4 C1536 4030023010 S.CER 0402B104K160CT
B 144.0/103.3 C1537 4030019560 S.CER GRM21BB31C106KE15L
B 128.8/109.8 C1538 4030019560 S.CER GRM21BB31C106KE15L
T 127.0/107.5 C1539 4030023010 S.CER 0402B104K160CT
T 133.2/97.5 C1540 4030022770 S.CER 0402N270J500CT
T 132.1/97.5 C1541 4030022770 S.CER 0402N270J500CT
T 127.0/104.5 C1542 4030019560 S.CER GRM21BB31C106KE15L
T 127.0/105.5 C1543 4030023010 S.CER 0402B104K160CT
T 127.0/109.5 C1544 4030019560 S.CER GRM21BB31C106KE15L
T 127.0/106.5 C1545 4030023010 S.CER 0402B104K160CT
T 127.0/110.5 C1546 4030019120 S.CER GRM188B31E105KA75D
T 127.0/108.5 C1551 4030023010 S.CER 0402B104K160CT
T 131.1/97.5 C1552 4030019120 S.CER GRM188B31E105KA75D
T 69.9/134.0 C1553 4030019120 S.CER GRM188B31E105KA75D
T 74.2/132.1 C1571 4030023010 S.CER 0402B104K160CT
T 71.4/136.5 C1572 4030019120 S.CER GRM188B31E105KA75D
T 73.8/143.1 C1573 4030019120 S.CER GRM188B31E105KA75D
T 69.7/144.0 C1601 4030022740 S.CER 0402N220J500CT
T 77.9/136.3 C1602 4030022740 S.CER 0402N220J500CT
T 74.9/141.0 C1603 4030022740 S.CER 0402N220J500CT
T 98.5/139.0 C1604 4030022740 S.CER 0402N220J500CT
T 104.2/136.1 C1605 4030022740 S.CER 0402N220J500CT
T 142.8/125.0 C1606 4030022740 S.CER 0402N220J500CT
T 140.6/122.4 C1611 4030023010 S.CER 0402B104K160CT
T 140.5/127.5 C1612 4030022770 S.CER 0402N270J500CT
T 95.8/129.7 C1613 4030022770 S.CER 0402N270J500CT
T 98.3/133.1 C1614 4030023010 S.CER 0402B104K160CT
T 98.1/127.8 C1615 4030023010 S.CER 0402B104K160CT
T 85.5/132.3 C1618 4030019560 S.CER GRM21BB31C106KE15L
T 85.5/133.7 C1623 4030023090 S.CER 0402B102K500CT
T 83.0/139.3 C1901 4030023820 S.CER 0603B104K250CT
T 86.7/139.3 C1903 4030022770 S.CER 0402N270J500CT
T 89.7/133.9 C1904 4030022770 S.CER 0402N270J500CT
T 89.5/140.7 C1905 4030019120 S.CER GRM188B31E105KA75D
T 89.5/142.5 C1906 4030023010 S.CER 0402B104K160CT
T 89.0/138.4 C1907 4030019560 S.CER GRM21BB31C106KE15L
T 111.6/120.1 C1908 4030023010 S.CER 0402B104K160CT
T 99.1/122.1 C1909 4030023010 S.CER 0402B104K160CT
T 98.9/117.1 C1914 4030023010 S.CER 0402B104K160CT
C1915 4030022170 S.CER GR442QR73D102KW01L
T 36.5/121.6 C2001 4030019120 S.CER GRM188B31E105KA75D
T 35.6/116.5 C2002 4030019560 S.CER GRM21BB31C106KE15L
T 59.7/143.3 C2003 4030019560 S.CER GRM21BB31C106KE15L
T 60.2/141.3 C2004 4030019120 S.CER GRM188B31E105KA75D
T 58.2/136.9 C2005 4030019120 S.CER GRM188B31E105KA75D
T 62.6/139.2 C2006 4030019560 S.CER GRM21BB31C106KE15L
T 52.6/142.2 C2011 4030019560 S.CER GRM21BB31C106KE15L
T 55.6/142.2 C2012 4030023010 S.CER 0402B104K160CT
T 63.0/135.9 C2021 4030019570 S.CER C1608 CH 1H 332J-T
T 59.5/133.2 C2022 4030023010 S.CER 0402B104K160CT
T 66.3/130.7 C2023 4030022930 S.CER 0402N821J500CT
T 69.7/129.9 C2029 4030019560 S.CER GRM21BB31C106KE15L
T 71.8/124.3 C2031 4030019570 S.CER C1608 CH 1H 332J-T
T 69.2/124.3 C2032 4030023010 S.CER 0402B104K160CT
T 65.6/126.9 C2033 4030022930 S.CER 0402N821J500CT
T 66.2/119.2 C2041 4030018600 S.CER C1608 CH 1H 152J-T
T 66.2/121.0 C2042 4030023010 S.CER 0402B104K160CT
T 68.2/115.1 C2043 4030022710 S.CER 0402N181J500CT
T 67.7/123.2 C2044 4030019560 S.CER GRM21BB31C106KE15L
T 42.8/125.1 C2049 4030019560 S.CER GRM21BB31C106KE15L
T 42.8/120.1 C2051 4030019570 S.CER C1608 CH 1H 332J-T
T 8.4/94.7 C2052 4030023010 S.CER 0402B104K160CT
T 13.0/94.7 C2053 4030022670 S.CER 0402N121J500CT
T 53.3/63.1 C2054 4030019560 S.CER GRM21BB31C106KE15L
T 58.1/63.3 C2061 4030019570 S.CER C1608 CH 1H 332J-T
T 87.0/128.1 C2062 4030023010 S.CER 0402B104K160CT
T 87.1/125.9 C2063 4030022670 S.CER 0402N121J500CT
T 85.0/121.6 C2069 4030019560 S.CER GRM21BB31C106KE15L
T 89.4/123.8 C2071 4030019570 S.CER C1608 CH 1H 332J-T
T 82.8/127.1 C2072 4030023010 S.CER 0402B104K160CT
T 79.8/127.1 C2073 4030022670 S.CER 0402N121J500CT
T 88.1/120.1 C2081 4030022690 S.CER 0402N151J500CT
T 78.8/130.9 C2082 4030023010 S.CER 0402B104K160CT
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-8a
DESCRIPTION M .
LOCATION
T 57.1/120.8
T 57.7/118.8
T 61.9/125.5
T 50.5/121.9
T 52.3/121.9
T 59.7/128.5
T 11.9/118.5
T 9.4/127.5
T 155.5/115.0
T 160.5/114.5
T 6.8/89.3
T 13.4/89.5
T 8.0/99.2
T 14.9/99.2
T 12.3/104.6
T 15.3/106.8
T 9.2/21.1
T 8.7/18.1
T 72.8/62.6
T 72.3/64.8
T 75.6/61.3
T 178.9/149.6
T 188.4/146.0
T 178.2/143.1
T 172.5/125.9
T 162.6/124.0
T 164.4/124.0
T 160.4/128.2
B 170.8/132.0
T 161.8/129.1
B 170.8/128.7
T 166.1/124.0
T 171.9/128.7
T 176.8/129.1
T 174.6/131.7
T 174.2/133.5
T 171.9/134.1
T 173.0/135.8
T 158.8/132.2
T 158.1/129.2
T 149.2/145.5
T 150.3/145.8
T 147.2/149.4
T 147.0/133.3
T 146.7/134.3
T 142.1/133.7
T 154.0/140.1
T 154.0/141.9
T 160.0/137.7
T 158.4/137.7
T 163.3/137.7
T 161.6/137.7
T 165.8/141.1
T 172.3/141.4
T 168.7/147.9
T 159.6/150.4
T 159.1/149.5
T 158.0/151.8
T 155.2/152.8
B 147.3/42.1
T 144.3/33.3
T 146.9/35.5
T 148.3/36.8
T 146.8/37.9
T 139.2/36.8
T 141.2/36.9
T 140.5/44.5
T 8.7/139.8
T 9.2/150.9
T 183.4/67.0
T 183.4/63.7
T 184.0/78.9
T 180.7/77.3
T 183.7/77.3
T 177.6/77.3
T 172.0/77.9
T 173.7/75.9
T 194.4/76.2
T 190.3/76.1
T 191.9/76.1
T 188.4/71.8
T 191.0/65.6
T 189.7/67.6
T 191.3/67.6
T 145.9/121.1
T 147.8/120.8
T 147.3/118.5
T 148.8/124.2
T 151.8/115.2
T 157.6/121.0
T 155.8/120.8
T 156.5/118.5
T 154.5/122.7
T 160.3/121.0
T 162.2/120.7
T 161.8/118.5
T 168.6/115.2
T 172.3/121.0
T 170.4/120.7
T 171.0/118.5
T 194.3/55.9
T 199.7/56.4
H/V
