Icom IC-9700 Service Manual Addendum page 27

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[PHONE UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R401 7030015130 S.RES RMC1/16-102JTP (1 k)
R403 7030015010 S.RES RMC1/16-101JTP (100)
R404 7030015010 S.RES RMC1/16-101JTP (100)
C401 4030023860 S.CER 0603B103K500CT
C404 4030023860 S.CER 0603B103K500CT
J1 6450001630 CON HSJ1406-01-050
EP401 6910018930 S.BEA MPZ2012S601A
EP402 6910018930 S.BEA MPZ2012S601A
EP403 6910018930 S.BEA MPZ2012S601A
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
H/V
M .
LOCATION
T 18.5/8.4
T 12.3/13.1
T 15.9/12.9
T 18.5/9.6
T 10.5/12.9
T 13.9/12.8
T 16.8/11.3
T 10.2/11.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-26a
