Icom IC-9700 Service Manual Addendum page 117

[MIC UNIT]
REF PARTS
NO. NO.
C1 4030023860 S.CER 0603B103K500CT
C2 4030023860 S.CER 0603B103K500CT
C3 4030023860 S.CER 0603B103K500CT
C4 4030023460 S.CER 0603N101J500CT
C5 4030023860 S.CER 0603B103K500CT
C6 4030023860 S.CER 0603B103K500CT
C7 4030023860 S.CER 0603B103K500CT
C8 4030023720 S.CER 0603N470J500CT
J1 6510000191 CON FM214-8SS (P)-1
J2 6510019971 S.CON 52808-1071
EP2 6910012350 S.BEA MMZ1608Y 102BT
EP3 6910012350 S.BEA MMZ1608Y 102BT
EP4 6910012350 S.BEA MMZ1608Y 102BT
EP5 6910012350 S.BEA MMZ1608Y 102BT
EP7 6910018930 S.BEA MPZ2012S601A
EP9 6910015130 S.BEA MMZ1608D 301BT
EP10 6910015130 S.BEA MMZ1608D 301BT
EP11 6910012350 S.BEA MMZ1608Y 102BT
EP12 6910018930 S.BEA MPZ2012S601A
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M .
LOCATION
T 10.3/17.4
T 22.8/14.8
T
T
T 23.6/10.6
T
T
T 10.8/15.5
T 10.4/15.8
T 22.8/13.5
T
T
T 21.3/16.1
T
T
T
T
T
H/V
8.1/15.3
5.5/3.8
22.8/7.1
7.4/9.2
22.8/8.7
7.4/13.4
7.6/6.2
10.1/2.5
10.1/3.7
11.6/17.4
7.9/16.8
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-26
