Icom IC-9700 Service Manual Addendum page 15

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[PA-A UNIT]
REF PARTS
DESCRIPTION
NO. NO.
IC101 1110009820 S.IC MMG3H21NT1
IC211 1110008550 S.IC NJM2904CRB1-TE1-#HMZR
IC691 1110008550 S.IC NJM2904CRB1-TE1-#HMZR
IC1161 1110009890 S.IC NJG1152KA1-TE1
IC1162 1180004760 S.REG S-1200B33-M5T1U
Q111 1550000500 S.FET RZF020P01TL
Q112 1590004060 S.TRA LDTC114EET1G
Q201 1560002490 S.FET PD85004-HF
Q301 1560002470 S.FET AFT05MP075NR1
Q401 1560002230 S.FET FK3503010L
Q701 1520000651 S.TRA 2SB1201S-TL-E
Q702 1510001200 S.TRA L2SA1576ART1G
Q703 1590004060 S.TRA LDTC114EET1G
Q1221 1590004060 S.TRA LDTC114EET1G
Q1222 1590004310 S.TRA LDTA114EET1G
Q1231 1590004060 S.TRA LDTC114EET1G
Q1232 1590004310 S.TRA LDTA114EET1G
Q1241 1590004060 S.TRA LDTC114EET1G
Q1242 1590004310 S.TRA LDTA114EET1G
Q1243 1560002230 S.FET FK3503010L
Q1244 1590004310 S.TRA LDTA114EET1G
D311 1750001810 S.DIO L1SS400T1G
D401 1750001810 S.DIO L1SS400T1G
D601 1750002230 S.DIO LRB751S-40T1G
D602 1750002230 S.DIO LRB751S-40T1G
D611 1750001810 S.DIO L1SS400T1G
D651 1750002230 S.DIO LRB751S-40T1G
D652 1750002230 S.DIO LRB751S-40T1G
D661 1750001810 S.DIO L1SS400T1G
D1121 1790001622 S.DIO 1SV308L3F
D1122 1790001622 S.DIO 1SV308L3F
D1123 1790001622 S.DIO 1SV308L3F
D1124 1790001622 S.DIO 1SV308L3F
D1161 1790002170 S.VAR LXES15AAA1-133
L101 6200009861 S.COI NLV25T-1R5J-PF
L201 6200012990 S.COI 0.25-1.9-9TL 84.0N
L202 6200010060 S.COI AS080647-56N
L301 6110001360 COI LA-179
L302 6170000340 COI LW-33
L401 6200010780 S.COI C2520C-1R0G-A
L402 6200010780 S.COI C2520C-1R0G-A
L403 6200010780 S.COI C2520C-1R0G-A
L501 6110001330 COI LA-176
L502 6110001360 COI LA-179
L503 6110001330 COI LA-176
L601 6200009861 S.COI NLV25T-1R5J-PF
L651 6200009861 S.COI NLV25T-1R5J-PF
L701 6200010780 S.COI C2520C-1R0G-A
L1101 6200013680 S.COI 0.40-2.00-9TL 69N
L1102 6200013680 S.COI 0.40-2.00-9TL 69N
L1103 6200010680 S.COI C2520C-R22G-A (0.22U)
L1121 6200003281 S.COI NLV25T-2R2J-PF
L1122 6200003281 S.COI NLV25T-2R2J-PF
L1151 6200012910 S.COI 0.35-1.6-8TL 45.5N
L1152 6200012580 S.COI 0.35-1.6-5TL 23.8N
L1161 6200013840 S.COI MLK1005S18NJT
L1162 6200011860 S.COI LQW18ANR47G00D
L1171 6200012700 S.COI 0.50-2.0-6TL 35.0N
L1172 6200012700 S.COI 0.50-2.0-6TL 35.0N
L1191 6200010910 S.COI LQW18AN56NG00D
R6 7030015910 S.RES RMC1/16S-101JTH (100)
R7 7030015910 S.RES RMC1/16S-101JTH (100)
R8 7030015910 S.RES RMC1/16S-101JTH (100)
R9 7030015910 S.RES RMC1/16S-101JTH (100)
R10 7030015910 S.RES RMC1/16S-101JTH (100)
R101 7030016370 S.RES RMC1/16S-271JTH (270)
R102 7030016570 S.RES RMC1/16S-180JTH (18)
R103 7030016370 S.RES RMC1/16S-271JTH (270)
R105 7030016560 S.RES RMC1/16SJPTH
R111 7030016050 S.RES RMC1/16S-102JTH (1 k)
R112 7030016110 S.RES RMC1/16S-473JTH (47 k)
R113 7030016110 S.RES RMC1/16S-473JTH (47 k)
R201 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R202 7030019460 S.RES RMC1/8-561JTP (560)
R211 7030016560 S.RES RMC1/16SJPTH
R212 7030016020 S.RES RMC1/16S-104JTH (100 k)
R213 7030016020 S.RES RMC1/16S-104JTH (100 k)
R214 7030016110 S.RES RMC1/16S-473JTH (47 k)
R215 7030015910 S.RES RMC1/16S-101JTH (100)
R216 7030016050 S.RES RMC1/16S-102JTH (1 k)
R219 7030015910 S.RES RMC1/16S-101JTH (100)
R301 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R311 7030016330 S.RES RMC1/16S-153JTH (15 k)
R312 7030016020 S.RES RMC1/16S-104JTH (100 k)
R314 7030016560 S.RES RMC1/16SJPTH
R315 7030015910 S.RES RMC1/16S-101JTH (100)
R316 7030019390 S.RES RMC1/8-470JTP (47)
R317 7030019460 S.RES RMC1/8-561JTP (560)
R401 7030009891 S.RES ERA3YED 151V (150)
R402 7030009891 S.RES ERA3YED 151V (150)
R403 7030009661 S.RES ERA3YED 121V (120)
R404 7030009661 S.RES ERA3YED 121V (120)
R405 7030019090 S.RES RMC1/8-104JTP (100 k)
R451 7510001551 S.THE NTCG16 4LH 333JT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[PA-A UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
B 60.8/52.0 R452 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
T 35.9/33.1 R601 7030009781 S.RES ERA3YHD 680V (68)
T 142.2/46.2 R602 7030007230 S.RES ERA3YED 102V (1 k)
T 80.6/13.1 R611 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
T 74.9/16.2 R612 7030016020 S.RES RMC1/16S-104JTH (100 k)
R613 7030016020 S.RES RMC1/16S-104JTH (100 k)
R615 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 27.0/32.9 R616 7030016280 S.RES RMC1/16S-331JTH (330)
T 21.7/34.3 R617 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 38.9/27.3 R651 7030009781 S.RES ERA3YHD 680V (68)
T 66.0/30.0 R652 7030007230 S.RES ERA3YED 102V (1 k)
T 116.6/4.5 R661 7030015980 S.RES RMC1/16S-333JTH (33 k)
T 126.9/56.6 R662 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 133.0/58.5 R663 7030016020 S.RES RMC1/16S-104JTH (100 k)
T 132.8/56.1 R665 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 20.2/10.3 R666 7030016280 S.RES RMC1/16S-331JTH (330)
T 22.5/10.3 R667 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 20.2/12.6 R691 7030015910 S.RES RMC1/16S-101JTH (100)
T 22.5/12.6 R701 7030010580 S.RES ERJ1TYJ 1R5U (1.5)
T 27.8/10.3 R702 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
T 30.1/10.3 R703 7030016070 S.RES RMC1/16S-474JTH (470 k)
T 27.5/12.6 R704 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
T 30.1/12.6 R705 7030016380 S.RES RMC1/16S-183JTH (18 k)
R706 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R1121 7030016460 S.RES RMC1/16S-181JTH (180)
T 55.2/39.6 R1122 7030016520 S.RES RMC1/16S-270JTH (27)
T 117.7/9.5 R1123 7030016470 S.RES RMC1/16S-390JTH (39)
T 145.1/8.0 R1124 7030016520 S.RES RMC1/16S-270JTH (27)
T 146.3/8.0 R1125 7030016160 S.RES RMC1/16S-820JTH (82)
T 141.4/41.7 R1126 7030016460 S.RES RMC1/16S-181JTH (180)
T 156.9/14.1 R1127 7030016460 S.RES RMC1/16S-181JTH (180)
T 155.7/14.1 R1161 7030015970 S.RES RMC1/16S-103JTH (10 k)
T 141.4/50.9 R1162 7030016330 S.RES RMC1/16S-153JTH (15 k)
T 89.8/7.2 R1163 7030016390 S.RES RMC1/16S-184JTH (180 k)
T 89.6/12.0 R1164 7030015940 S.RES RMC1/16S-681JTH (680)
T 89.6/10.8 R1165 7030016560 S.RES RMC1/16SJPTH
T 87.6/11.2 R1166 7030016300 S.RES RMC1/16S-332JTH (3.3 k)
T 81.1/10.3 R1231 7030016110 S.RES RMC1/16S-473JTH (47 k)
R1241 7030016110 S.RES RMC1/16S-473JTH (47 k)
R1242 7030016110 S.RES RMC1/16S-473JTH (47 k)
T 29.1/26.6
T 32.0/25.5
T 46.1/28.1 C1 4030023030 S.CER 0402B103K250CT
C2 4030023030 S.CER 0402B103K250CT
C3 4030023030 S.CER 0402B103K250CT
T 120.0/12.7 C4 4030023090 S.CER 0402B102K500CT
T 115.0/7.8 C5 4030023090 S.CER 0402B102K500CT
T 121.5/6.9 C6 4030023030 S.CER 0402B103K250CT
C7 4030023030 S.CER 0402B103K250CT
C8 4030023030 S.CER 0402B103K250CT
C9 4030023030 S.CER 0402B103K250CT
T 144.7/5.0 C10 4030023030 S.CER 0402B103K250CT
T 154.1/17.2 C11 4030023030 S.CER 0402B103K250CT
T 142.8/19.3 C12 4030023030 S.CER 0402B103K250CT
T 98.9/7.9 C13 4030023090 S.CER 0402B102K500CT
T 93.2/7.9 C14 4030023090 S.CER 0402B102K500CT
T 106.5/12.4 C101 4030023090 S.CER 0402B102K500CT
T 89.6/14.7 C102 4030023090 S.CER 0402B102K500CT
T 86.6/15.3 C112 4030022640 S.CER 0402N101J500CT
T 86.1/8.3 C113 4030023090 S.CER 0402B102K500CT
T 82.1/7.9 C114 4030023010 S.CER 0402B104K160CT
T 78.6/14.2 C202 4030023090 S.CER 0402B102K500CT
T 78.1/16.8 C204 4030023030 S.CER 0402B103K250CT
T 74.0/9.1 C205 4030020750 S.CER GRM31A5C2J220JW01D
T 67.2/6.6 C206 4030020820 S.CER GRM31A5C2J121JW01D
T 60.1/7.5 C211 4030023030 S.CER 0402B103K250CT
C212 4030022640 S.CER 0402N101J500CT
C213 4030023090 S.CER 0402B102K500CT
T 11.5/20.3 C214 4030023010 S.CER 0402B104K160CT
T 11.5/19.3 C215 4030023030 S.CER 0402B103K250CT
T 11.5/18.3 C216 4030023010 S.CER 0402B104K160CT
T 11.5/17.3 C217 4030023090 S.CER 0402B102K500CT
T 11.5/16.3 C218 4030022640 S.CER 0402N101J500CT
T 19.3/27.0 C219 4030019560 S.CER GRM21BB31C106KE15L
T 19.3/25.5 C301 4030021020 S.CER GRM31A5C2J101JW01D
T 20.6/26.0 C302 4030020770 S.CER GRM31A5C2J330JW01D
T 28.6/23.6 C303 4030021300 S.CER GQM22M5C2H330JB01L
T 23.2/33.8 C305 4030021280 S.CER GQM22M5C2H180JB01L
T 24.1/32.9 C306 4030022400 S.CER GQM22M5C2H8R0CB01L
T 29.1/34.3 C307 4030021280 S.CER GQM22M5C2H180JB01L
T 34.1/23.5 C308 4030025210 S.CER GQM22M5C2H101JB01L
T 38.9/23.5 C309 4030021280 S.CER GQM22M5C2H180JB01L
T 32.0/34.6 C310 4030025210 S.CER GQM22M5C2H101JB01L
T 32.9/34.6 C311 4030020750 S.CER GRM31A5C2J220JW01D
T 32.0/32.9 C312 4030022640 S.CER 0402N101J500CT
T 32.9/32.9 C313 4030023090 S.CER 0402B102K500CT
T 32.9/31.3 C314 4030023010 S.CER 0402B104K160CT
T 35.5/25.8 C315 4510011410 S.ELE 25 CE 470 LX
T 35.1/35.8 C316 4030023010 S.CER 0402B104K160CT
T 57.3/23.7 C317 4030023090 S.CER 0402B102K500CT
T 39.9/33.9 C318 4030022640 S.CER 0402N101J500CT
T 39.0/33.9 C319 4510011410 S.ELE 25 CE 470 LX
T 39.4/32.3 C320 4510011410 S.ELE 25 CE 470 LX
T 40.7/31.8 C321 4030022640 S.CER 0402N101J500CT
T 55.7/35.8 C322 4030023090 S.CER 0402B102K500CT
T 56.9/40.7 C323 4030023010 S.CER 0402B104K160CT
T 120.1/9.7 C401 4030023030 S.CER 0402B103K250CT
T 121.3/9.7 C402 4030023030 S.CER 0402B103K250CT
T 118.0/7.6 C403 4030023030 S.CER 0402B103K250CT
T 118.0/6.4 C404 4030023010 S.CER 0402B104K160CT
T 115.6/20.7 C405 4030023090 S.CER 0402B102K500CT
T 60.0/19.6 C406 4030022640 S.CER 0402N101J500CT
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-14a
DESCRIPTION M .
LOCATION
T 58.7/20.4
T 155.6/7.8
T 156.8/7.8
T 143.2/41.3
T 143.2/42.2
T 143.0/40.4
T 140.4/42.2
T 140.4/43.8
T 139.5/43.8
T 146.4/14.1
T 145.2/14.1
T 143.7/51.1
T 143.7/50.2
T 142.5/50.1
T 140.3/50.5
T 140.4/49.3
T 139.2/49.7
T 139.6/48.3
T 127.4/62.1
T 133.2/62.1
T 134.1/61.2
T 131.2/56.6
T 136.1/56.8
T 137.0/58.4
T 91.3/13.2
T 92.5/11.1
T 91.1/9.3
T 91.6/10.2
T 88.6/5.6
T 89.5/9.7
T 87.6/13.3
T 84.0/14.5
T 83.1/14.5
T 82.2/10.8
T 78.6/15.1
T 77.4/11.5
T 73.9/19.0
T 24.1/12.1
T 31.6/9.8
T 31.6/13.0
T 9.3/26.7
T 9.3/25.3
T 9.3/23.8
T 8.8/22.3
T 8.8/21.3
T 8.8/20.3
T 8.8/19.3
T 8.8/18.3
T 8.8/17.3
T 8.8/16.3
T 8.8/15.3
T 8.8/14.3
T 8.8/13.3
T 8.8/12.3
T 21.9/25.5
T 28.6/24.5
T 28.6/28.7
T 28.6/29.6
T 28.6/30.5
T 30.4/23.6
T 35.9/24.6
T 42.5/27.1
T 44.0/22.3
T 36.3/35.3
T 35.5/26.7
T 35.5/27.6
T 35.5/28.5
T 49.8/33.8
T 43.9/33.2
T 44.8/33.2
T 45.7/33.2
T 47.1/33.5
T 54.1/30.0
T 55.7/24.3
T 72.7/37.5
T 82.3/24.3
T 92.7/41.8
T 92.6/18.3
T 96.4/16.1
T 99.3/22.7
T 100.3/18.3
T 54.1/27.9
T 53.7/39.5
T 53.7/40.4
T 55.2/41.6
T 63.6/54.2
T 71.9/55.7
T 71.9/54.8
T 71.9/53.9
T 105.1/57.3
T 90.9/50.0
T 100.7/51.1
T 101.6/51.1
T 102.5/51.1
T 120.9/14.8
T 112.9/6.9
T 118.8/9.0
T 122.7/10.8
T 122.7/9.9
T 122.7/9.0
H/V
