Icom IC-9700 Service Manual Addendum page 10

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C2088 4030023010 S.CER 0402B104K160CT
C2089 4030023010 S.CER 0402B104K160CT
C2091 4030022690 S.CER 0402N151J500CT
C2092 4030023010 S.CER 0402B104K160CT
C2103 4030023010 S.CER 0402B104K160CT
C2104 4030019560 S.CER GRM21BB31C106KE15L
C2105 4030023010 S.CER 0402B104K160CT
C2106 4030023010 S.CER 0402B104K160CT
C2107 4030019560 S.CER GRM21BB31C106KE15L
C2108 4030019560 S.CER GRM21BB31C106KE15L
C2109 4030019560 S.CER GRM21BB31C106KE15L
C2111 4030021580 S.CER GRM188B31E225KA12D
C2112 4030022750 S.CER 0402N221J500CT
C2113 4030019560 S.CER GRM21BB31C106KE15L
C2121 4030021580 S.CER GRM188B31E225KA12D
C2122 4030022670 S.CER 0402N121J500CT
C2123 4030021580 S.CER GRM188B31E225KA12D
C2125 4510010570 S.ELE 16 CE 470 LX
C2126 4030019560 S.CER GRM21BB31C106KE15L
C2127 4030023010 S.CER 0402B104K160CT
C2128 4030019560 S.CER GRM21BB31C106KE15L
C2131 4030023010 S.CER 0402B104K160CT
C2136 4030019560 S.CER GRM21BB31C106KE15L
C2201 4510010570 S.ELE 16 CE 470 LX
C2202 4030021580 S.CER GRM188B31E225KA12D
C2203 4030022740 S.CER 0402N220J500CT
C2204 4030019560 S.CER GRM21BB31C106KE15L
C2205 4030019570 S.CER C1608 CH 1H 332J-T
C2206 4030021580 S.CER GRM188B31E225KA12D
C2207 4030023010 S.CER 0402B104K160CT
C2208 4030021580 S.CER GRM188B31E225KA12D
C2209 4030019120 S.CER GRM188B31E105KA75D
C2210 4030012610 S.CER C2012 JB 1C 474K-T
C2211 4030019330 S.CER C1608 X7R 1C 224K-T
C2212 4030019330 S.CER C1608 X7R 1C 224K-T
C2213 4030023010 S.CER 0402B104K160CT
C2214 4510010570 S.ELE 16 CE 470 LX
C2215 4510010570 S.ELE 16 CE 470 LX
C2222 4030021580 S.CER GRM188B31E225KA12D
C2223 4030022740 S.CER 0402N220J500CT
C2224 4030019560 S.CER GRM21BB31C106KE15L
C2225 4030019570 S.CER C1608 CH 1H 332J-T
C2226 4030021580 S.CER GRM188B31E225KA12D
C2228 4030021580 S.CER GRM188B31E225KA12D
C2229 4030019120 S.CER GRM188B31E105KA75D
C2230 4030012610 S.CER C2012 JB 1C 474K-T
C2231 4030019330 S.CER C1608 X7R 1C 224K-T
C2232 4030019330 S.CER C1608 X7R 1C 224K-T
C2233 4030023010 S.CER 0402B104K160CT
C2234 4510010570 S.ELE 16 CE 470 LX
C2235 4510010570 S.ELE 16 CE 470 LX
C2240 4030023090 S.CER 0402B102K500CT
C2241 4030023090 S.CER 0402B102K500CT
C2242 4030023090 S.CER 0402B102K500CT
C2243 4030023090 S.CER 0402B102K500CT
C2251 4030023090 S.CER 0402B102K500CT
C2252 4030023090 S.CER 0402B102K500CT
C2253 4030023090 S.CER 0402B102K500CT
C2503 4030022630 S.CER 0402N100C500CT
C2504 4030024500 S.CER C1005 JB 1C 224K-T
C2505 4030023010 S.CER 0402B104K160CT
C2509 4030019120 S.CER GRM188B31E105KA75D
C2510 4030023010 S.CER 0402B104K160CT
C2512 4030023030 S.CER 0402B103K250CT
C2513 4030024500 S.CER C1005 JB 1C 224K-T
C2515 4030017480 S.CER C1608 JB 1A 474K-T
C2518 4030022950 S.CER 0402B273K100CT
C2523 4030022590 S.CER 0402N8R0C500CT
C2524 4030024500 S.CER C1005 JB 1C 224K-T
C2525 4030023010 S.CER 0402B104K160CT
C2532 4030023030 S.CER 0402B103K250CT
C2533 4030024500 S.CER C1005 JB 1C 224K-T
C2535 4030017480 S.CER C1608 JB 1A 474K-T
C2543 4030022570 S.CER 0402N6R0C500CT
C2544 4030024500 S.CER C1005 JB 1C 224K-T
C2545 4030023010 S.CER 0402B104K160CT
C2549 4030019120 S.CER GRM188B31E105KA75D
C2550 4030023010 S.CER 0402B104K160CT
C2552 4030023030 S.CER 0402B103K250CT
C2553 4030024500 S.CER C1005 JB 1C 224K-T
C2555 4030017480 S.CER C1608 JB 1A 474K-T
C2558 4030023020 S.CER 0402B473K160CT
C2566 4030017480 S.CER C1608 JB 1A 474K-T
C2601 4030023010 S.CER 0402B104K160CT
C2602 4030023010 S.CER 0402B104K160CT
C2609 4030019120 S.CER GRM188B31E105KA75D
C2610 4030023010 S.CER 0402B104K160CT
C2611 4030023090 S.CER 0402B102K500CT
C2629 4030019120 S.CER GRM188B31E105KA75D
C2630 4030023010 S.CER 0402B104K160CT
C2651 4030023010 S.CER 0402B104K160CT
C2652 4030019120 S.CER GRM188B31E105KA75D
C2653 4030023010 S.CER 0402B104K160CT
C2654 4030023010 S.CER 0402B104K160CT
C2801 4030023010 S.CER 0402B104K160CT
C2811 4030023010 S.CER 0402B104K160CT
C2821 4030023010 S.CER 0402B104K160CT
C2851 4030023010 S.CER 0402B104K160CT
C2852 4030023010 S.CER 0402B104K160CT
C2853 4030021580 S.CER GRM188B31E225KA12D
C2854 4030021580 S.CER GRM188B31E225KA12D
C2870 4030023010 S.CER 0402B104K160CT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN UNIT]
H/V REF PARTS
M .
LOCATION NO. NO.
T 191.2/61.1 C2871 4030023030 S.CER 0402B103K250CT
T 192.4/60.6 C2872 4030023010 S.CER 0402B104K160CT
T 189.4/56.8 C2881 4030023030 S.CER 0402B103K250CT
T 188.8/60.5 C2882 4030023010 S.CER 0402B104K160CT
T 162.0/89.1 C2883 4510010570 S.ELE 16 CE 470 LX
T 161.5/87.7 C2884 4030023010 S.CER 0402B104K160CT
T 166.2/100.2 C2891 4030023030 S.CER 0402B103K250CT
T 162.8/99.5 C2892 4030023030 S.CER 0402B103K250CT
T 164.8/100.5 C2901 4030022740 S.CER 0402N220J500CT
T 162.3/100.9 C2902 4030022740 S.CER 0402N220J500CT
T 165.5/103.7 C2903 4030023010 S.CER 0402B104K160CT
T 160.0/102.9 C2904 4030023010 S.CER 0402B104K160CT
T 160.0/107.0 C2905 4030023010 S.CER 0402B104K160CT
T 162.2/109.3 C2906 4030023010 S.CER 0402B104K160CT
T 168.2/100.2 C2907 4030023010 S.CER 0402B104K160CT
T 168.4/103.1 C2911 4030023030 S.CER 0402B103K250CT
T 173.5/101.9 C2913 4030023030 S.CER 0402B103K250CT
T 175.5/93.2 C2914 4030023030 S.CER 0402B103K250CT
T 172.3/100.4 C2915 4030023090 S.CER 0402B102K500CT
T 173.5/99.0 C2916 4030023030 S.CER 0402B103K250CT
T 170.2/112.2 C2917 4030023030 S.CER 0402B103K250CT
T 163.7/111.0 C2918 4030023030 S.CER 0402B103K250CT
T 161.3/111.6 C2931 4030023030 S.CER 0402B103K250CT
T 201.7/62.7 C2941 4030021580 S.CER GRM188B31E225KA12D
T 186.3/83.2 C2942 4030021580 S.CER GRM188B31E225KA12D
T 185.3/94.3 C2961 4030023010 S.CER 0402B104K160CT
B 187.2/88.2 C2962 4030023010 S.CER 0402B104K160CT
T 186.4/86.2 C2963 4030023010 S.CER 0402B104K160CT
B 189.6/86.3 C3011 4030023030 S.CER 0402B103K250CT
T 188.9/87.0 C3012 4030023030 S.CER 0402B103K250CT
T 190.2/91.0 C3013 4030023030 S.CER 0402B103K250CT
T 187.2/92.8 C3014 4030023030 S.CER 0402B103K250CT
T 197.1/106.0 C3015 4030022520 S.CER 0402N1R0B500CT
T 197.3/107.6 C3016 4030023030 S.CER 0402B103K250CT
T 196.8/116.4 C3017 4030023030 S.CER 0402B103K250CT
T 197.1/122.8 C3021 4030023030 S.CER 0402B103K250CT
T 190.1/120.8 C3022 4030023030 S.CER 0402B103K250CT
T 194.2/86.6 C3023 4030023030 S.CER 0402B103K250CT
T 200.4/83.2 C3024 4030023030 S.CER 0402B103K250CT
T 199.4/94.3 C3025 4030022520 S.CER 0402N1R0B500CT
B 201.3/88.2 C3026 4030023030 S.CER 0402B103K250CT
T 200.5/86.2 C3027 4030023030 S.CER 0402B103K250CT
B 203.8/86.3 C3031 4030023010 S.CER 0402B104K160CT
T 204.3/91.0 C3032 4030023030 S.CER 0402B103K250CT
T 201.3/92.8 C3033 4030023030 S.CER 0402B103K250CT
T 211.2/106.0 C3041 4030023030 S.CER 0402B103K250CT
T 211.4/107.6 C3042 4030023030 S.CER 0402B103K250CT
T 210.9/116.4 C3043 4030023030 S.CER 0402B103K250CT
T 198.9/122.8 C3044 4030023030 S.CER 0402B103K250CT
T 205.8/120.8 C3045 4030022520 S.CER 0402N1R0B500CT
T 208.2/86.5 C3046 4030023030 S.CER 0402B103K250CT
T 181.9/125.4 C3047 4030023030 S.CER 0402B103K250CT
T 191.4/129.2 C3051 4030023030 S.CER 0402B103K250CT
T 207.0/140.2 C3052 4030017630 S.CER C1005 CH 1H 120J-T
T 207.1/146.6 C3053 4030022790 S.CER 0402N2R5B500CT
T 206.0/126.9 C3054 4030017390 S.CER C1005 CH 1H 180J-T
T 191.5/140.2 C3055 4030022720 S.CER 0402N1R5B500CT
T 191.4/146.5 C3056 4030017390 S.CER C1005 CH 1H 180J-T
T 129.7/22.2 C3057 4030022520 S.CER 0402N1R0B500CT
T 131.0/22.0 C3058 4030017630 S.CER C1005 CH 1H 120J-T
T 128.0/22.2 C3061 4030023090 S.CER 0402B102K500CT
T 122.9/20.3 C3062 4030023090 S.CER 0402B102K500CT
T 123.2/21.9 C3063 4030023090 S.CER 0402B102K500CT
T 129.7/24.0 C3064 4030023090 S.CER 0402B102K500CT
T 129.7/25.8 C3071 4030022770 S.CER 0402N270J500CT
T 127.3/31.8 C3072 4030022670 S.CER 0402N121J500CT
T 125.6/29.3 C3073 4030022770 S.CER 0402N270J500CT
T 116.1/22.2 C3074 4030022740 S.CER 0402N220J500CT
T 114.3/22.2 C3075 4030022630 S.CER 0402N100C500CT
T 117.9/22.2 C3076 4030022680 S.CER 0402N150J500CT
T 116.1/24.0 C3081 4030022590 S.CER 0402N8R0C500CT
T 116.1/25.8 C3082 4030022840 S.CER 0402N390J500CT
T 118.7/31.8 C3083 4030022590 S.CER 0402N8R0C500CT
T 106.8/22.6 C3084 4030022570 S.CER 0402N6R0C500CT
T 108.4/22.6 C3085 4030022530 S.CER 0402N2R0B500CT
T 105.0/22.6 C3086 4030022570 S.CER 0402N6R0C500CT
T 99.9/20.9 C3091 4030022660 S.CER 0402N120J500CT
T 100.2/22.4 C3092 4030022900 S.CER 0402N680J500CT
T 106.8/24.4 C3093 4030022590 S.CER 0402N8R0C500CT
T 106.8/26.2 C3094 4030022590 S.CER 0402N8R0C500CT
T 102.4/31.1 C3095 4030022530 S.CER 0402N2R0B500CT
T 101.4/30.5 C3096 4030022590 S.CER 0402N8R0C500CT
T 82.1/24.7 C3101 4030023030 S.CER 0402B103K250CT
T 87.7/28.7 C3102 4030023030 S.CER 0402B103K250CT
T 87.2/30.8 C3103 4030022640 S.CER 0402N101J500CT
T 81.1/26.6 C3104 4030022640 S.CER 0402N101J500CT
T 82.8/26.8 C3105 4030023030 S.CER 0402B103K250CT
T 77.6/32.1 C3111 4030023030 S.CER 0402B103K250CT
T 107.8/16.4 C3112 4030023030 S.CER 0402B103K250CT
T 107.7/15.4 C3113 4030022640 S.CER 0402N101J500CT
T 146.2/32.2 C3114 4030022640 S.CER 0402N101J500CT
T 145.7/27.7 C3115 4030023030 S.CER 0402B103K250CT
T 142.3/29.8 C3121 4030023030 S.CER 0402B103K250CT
T 148.8/29.2 C3122 4030022640 S.CER 0402N101J500CT
T 108.7/49.8 C3123 4030022640 S.CER 0402N101J500CT
T 115.3/48.6 C3131 4030023030 S.CER 0402B103K250CT
T 121.9/48.6 C3132 4030023030 S.CER 0402B103K250CT
T 135.8/43.1 C3133 4030023030 S.CER 0402B103K250CT
T 135.5/48.6 C3134 4030023030 S.CER 0402B103K250CT
T 138.4/49.3 C3141 4030023030 S.CER 0402B103K250CT
T 135.7/45.5 C3142 4030023030 S.CER 0402B103K250CT
T 134.8/28.9 C3143 4030023030 S.CER 0402B103K250CT
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-9a
DESCRIPTION M .
LOCATION
T 137.8/24.3
T 134.8/26.8
T 133.9/124.0
T 133.9/127.0
T 122.4/120.6
T 133.9/126.0
T 174.9/149.6
T 177.2/149.6
T 140.9/157.8
T 153.2/160.8
T 151.5/153.3
T 152.4/153.3
T 151.5/155.1
T 152.4/155.1
T 142.0/152.8
T 124.1/145.5
T 139.3/147.6
T 124.0/146.8
T 132.4/147.0
T 121.5/146.8
T 135.1/147.0
T 129.9/148.4
T 138.1/139.8
T 134.0/146.3
T 125.5/147.2
T 126.8/37.7
T 117.4/37.7
T 120.8/34.1
T 58.4/39.8
T 61.9/40.8
T 61.9/37.9
T 65.2/41.8
T 68.4/38.9
T 68.9/40.4
T 71.0/40.8
T 58.4/33.7
T 61.9/34.7
T 61.9/31.8
T 65.2/36.3
T 68.4/32.8
T 68.9/34.3
T 71.7/33.8
T 68.0/19.8
T 70.0/24.5
T 65.2/30.1
T 58.4/26.2
T 61.9/28.1
T 61.9/25.2
T 65.6/22.9
T 68.4/27.4
T 68.9/25.9
T 71.7/26.4
T 65.2/24.2
T 71.0/21.1
T 71.5/19.9
T 72.9/20.4
T 73.9/20.4
T 76.3/21.9
T 78.2/20.4
T 79.9/22.0
T 87.1/18.9
T 87.2/16.6
T 83.0/18.9
T 81.6/21.5
T 76.2/17.8
T 74.1/17.3
T 75.0/17.3
T 72.8/14.2
T 74.0/14.0
T 72.8/13.3
T 85.0/15.8
T 82.8/15.3
T 84.0/14.9
T 82.8/13.7
T 84.0/13.3
T 82.8/12.8
T 95.0/17.3
T 94.1/15.7
T 95.0/15.7
T 92.8/14.2
T 94.0/13.7
T 92.8/13.3
T 37.5/13.1
T 40.3/13.2
T 37.3/14.8
T 39.8/14.8
T 17.8/18.0
T 47.5/13.1
T 50.3/13.2
T 47.3/14.8
T 49.8/14.8
T 48.5/22.8
T 57.1/13.5
T 55.4/14.8
T 55.4/12.3
T 51.9/12.1
T 50.8/8.4
T 54.5/11.0
T 54.5/9.2
T 12.1/26.2
T 13.9/21.6
T 14.2/26.0
H/V
