Icom IC-9700 Service Manual Addendum page 23

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[DISPLAY UNIT]
REF PARTS
DESCRIPTION
NO. NO.
EP452 6910019900 S.BEA MPZ1608S601AT
EP453 6910017350 S.BEA MMZ1608S601A-T
EP454 6910016330 S.BEA MMZ1005S 601CT-S
EP455 6910018930 S.BEA MPZ2012S601A
EP456 6910016330 S.BEA MMZ1005S 601CT-S
EP457 6910016330 S.BEA MMZ1005S 601CT-S
EP601 6910019900 S.BEA MPZ1608S601AT
EP602 6910019900 S.BEA MPZ1608S601AT
EP603 6910019900 S.BEA MPZ1608S601AT
EP604 6910016330 S.BEA MMZ1005S 601CT-S
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
H/V
M .
LOCATION
B 13.3/52.7
B 13.3/51.5
B 13.3/50.5
B 13.3/49.1
B 5.3/55.3
B 3.3/55.3
B 64.7/67.8
B 67.3/59.9
B 68.3/67.8
B 82.6/67.7
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-22a
