Icom IC-9700 Service Manual Addendum page 24

June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[VR-A UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R1 7210003910 VAR R09430GMFB30.5C7B103-0020
J1 6510029480 S.CON 06FH-SM1-TB (LF) (SN)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
H/V
M .
LOCATION
T 19.8/8.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
