M
252 & 552
ODELS
S
M
O
UPER
ASTER
PERATIONS
The following instructions cover Model 252 & 552 Super Master Operations. The lock is
shipped with a default factory Super Master User PIN that can be set to a different value
when the lock is in factory mode. Once the Super Master User PIN is set, the Super
Master User combination can only be used to shelve and unlock the lock in the event that
the Manager User combination is lost. Once set, the Super Master User PIN can be
changed any time the lock is in shelved mode.
WARNING: The setting of the Super Master User PIN is optional, however, if you
do not set the Super Master User PIN before setting the Master User PIN, the
Super Master shelving capability will be permanently lost.
Important Note: The lock must be manually powered before each operation by
briskly turning the dial back and forth
SET SUPER MASTER USER PIN
The lock must be in factory mode.
Note: The default factory PIN assigned to the Super Master User is "120943". This
default PIN must be changed before the Super Master User combination can be used to
shelve the lock.
1.
Press # and then 0.
G
R
2.
Enter the two-digit Super Master ID 00 followed by the default factory Super Master
User PIN "120943."
G
R
3.
Enter the two-digit Super Master ID 00 followed by any six-digit PIN other than
"120943".
G
R
4.
Enter the two-digit Super Master ID 00 followed by the new six-digit PIN entered in
Step 5 again for verification. The new Super Master User combination is now set.
5.
Record the combination and store it in a secure place.
CHANGE SUPER MASTER USER PIN
A Super Master User PIN can only be changed while the lock is shelved.
Warning:
Do not change the Super Master User PIN to the factory default of
"120943" as this will permanently disable the Super Master User capabilities.
1.
Press # and then 0.
G
R
2.
Enter 00 followed by the current Super Master User PIN.
3.
Enter 00 followed by the new Super Master User PIN.
4.
Enter 00 followed by the new Super Master User PIN again for verification.
Document Number 3057.025 Rev. C - 09/10
®
AUDITCON
2 SERIES
.
G
R
G
R
G
M
252 & 552
ODELS
S
M
UPER
The following instructions cover Model 252 & 552 Super Master Operations. The lock is
shipped with a default factory Super Master User PIN that can be set to a different value
when the lock is in factory mode. Once the Super Master User PIN is set, the Super
Master User combination can only be used to shelve and unlock the lock in the event that
the Manager User combination is lost. Once set, the Super Master User PIN can be
changed any time the lock is in shelved mode.
WARNING: The setting of the Super Master User PIN is optional, however, if you
do not set the Super Master User PIN before setting the Master User PIN, the
Super Master shelving capability will be permanently lost.
Important Note: The lock must be manually powered before each operation by
briskly turning the dial back and forth
SET SUPER MASTER USER PIN
The lock must be in factory mode.
Note: The default factory PIN assigned to the Super Master User is "120943". This
default PIN must be changed before the Super Master User combination can be used to
shelve the lock.
1.
Press # and then 0.
2.
Enter the two-digit Super Master ID 00 followed by the default factory Super Master
User PIN "120943."
3.
Enter the two-digit Super Master ID 00 followed by any six-digit PIN other than
"120943".
4.
Enter the two-digit Super Master ID 00 followed by the new six-digit PIN entered in
Step 5 again for verification. The new Super Master User combination is now set.
5.
Record the combination and store it in a secure place.
CHANGE SUPER MASTER USER PIN
A Super Master User PIN can only be changed while the lock is shelved.
Warning:
Do not change the Super Master User PIN to the factory default of
"120943" as this will permanently disable the Super Master User capabilities.
1.
Press # and then 0.
2.
Enter 00 followed by the current Super Master User PIN.
3.
Enter 00 followed by the new Super Master User PIN.
4.
Enter 00 followed by the new Super Master User PIN again for verification.
R
Document Number 3057.025 Rev. C - 09/10
AUDITCON
O
ASTER
PERATIONS
.
G
R
G
R
G
R
G
R
®
2 SERIES
G
R
G
R
G
R
