- Page 1 Instruction Manual ® Thermo Scientific Savant ISS 110 Speedvac ® Concentrator...
- Page 3 © 2008 Thermo Fisher Scientific. All rights reserved. ® “Suva ” is a registered trademark of DuPont. All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
-
Page 4: Table Of Contents
Contents Section Introduction Page Introduction-ISS110 Section Installation Page Installation Section Operation Page Operation Drying Rate Starting and Stopping a Run Chamber Cover Simple System Integrity Test Section Application Information Page Application Information Solvent Handling Accessories Devising Protocols Section Accessories Page Accessories Section TroubleShooting... -
Page 5: Installation
INTRODUCTION The ISS SpeedVac Concentrator is a complete system for solvent ® evaporation, sample concentration, and drying using a patented technique that combines centrifugal force, vacuum, and applied heat. It is intended for use with aqueous and non-aggressive solvents such as ethanol and methanol. It may also be used with small quantities of acetonitrile and ammonium hydroxide. -
Page 6: Drying Rate
2. Gently put a clean Glass Condensation Flask (GCF400) into the refrigerated chamber. As you lower the flask into the chamber, the CryoCool Fluid rises. Verify that the final CryoCool liquid level is 10 to 15 mm below the shoulder of the flask. -
Page 7: Chamber Cover
CHAMBER COVER The chamber cover must be closed before a run can begin. It is not possible to open the cover during a run because of the vacuum in the concentrator chamber. In addition, a cover lock is present on 220 and 230 volt models. -
Page 8: Solvent Handling
Concentrating large quantities of organic solvents, such as hexane, chloroform, dichloromethane, or acetonitrile from extraction or elution systems are best suit- ed to the AES1010 and AES2010 SpeedVac Systems. SOLVENT HANDLING When processing hazardous samples, install the SCT Chemical Trap on the exhaust port to capture evaporated solvent. -
Page 9: Accessories
The following drying rate table provides a guide, results will vary depending upon test sample make up. DRYING RATE SOLVENT MEDIUM HIGH Water 1.0-2.0 2.0-3.5 3.5-5.0 ADDITIONAL ACCESSORIES R Chemical Trap Kit Absorbs volatile radioactives and attaches to the exhaust port of the instrument. Ammonia Neutralizing Trap Assembly Use when concentrating samples in ammonium hydroxide. -
Page 10: To Return An Instrument For Repair
Operative Power: 115VAC, 60 Hz, 10 amps 220VAC, 60 Hz, 5 amps 230 VAC, 50 Hz, 5 amps Dependent upon ambient temperature, line voltage fluctuations, and load capaci- TO RETURN AN INSTRUMENT FOR REPAIR In order to receive proper attention to your repair, you must first contact the Service Department or your sales representative and receive: (1) an Return material Authorization (RMA) number and (2) sign the Health and Safety Clearance Form before shipping the equipment back. -
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE ® ISS110 SPEEDVAC TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSES SOLUTION/EXPLANATION GENERAL No current to the equipment. No Response. Power failure at source. Check line cord for proper connections. Short circuit to ground in one of the Check main circuit panel. System trips circuit breaker components. - Page 12 Compressor system has lost it charge. Call Thermo Scientifice for assistance. Noisy vibration and/or excessive heat Cabinet housing has become loose or Call Thermo Scientific for assistance. on top of cabinet. circulation fan is rubbing an internal component. Glass Condensation Flask breakage.
- Page 13 Ulteriori informazioni sulla conformità di Thermo Fisher Scientific con queste Direttive, l’elenco delle ditte di riciclaggio nel Vostro paese e informazioni sui prodotti Thermo Scientific che possono essere utili alla rilevazione di sostanze soggette alla Direttiva RoHS sono disponibili sul sito www.thermo.com/ Conformité...
- Page 14 Important For your future reference and when contacting the factory, please have the following information readily available: Model Number: Serial Number: Date Purchased: The above information can be found on the dataplate attached to the equipment. If available, please provide the date purchased, the source of purchase (manufacturer or specific agent/rep organization), and purchase order number.
- Page 16 Thermo Fisher Scientific Inc. 275 Aiken Road Asheville, NC 28804 United States www.thermofisher.com 134-3001-00 Rev C...
