36 ScanMaker 1000XL Supplement

Specifications

Scanning Modes
Scanning Area
Resolution
Dynamic Range
Interface
Dimensions (L x W x H)
Weight
Voltage
Power Consumption
Environment
System Requirements
General Requirements
• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 128MB RAM (256MB or more to use DIGITAL ICE Photo Print Technology)
PC and compatibles
• Pentium III PC or higher with USB, Hi-Speed USB (USB 2.0), or FireWire port
• Microsoft Windows 98SE, Me, 2000 or XP
Macintosh
• iMac or Mac G3/G4/G5 with built-in USB port or FireWire port
• Mac OS X 10.2 or later
Important
Specifications, bundles, and accessories are subject to change without notice.
Color, grayscale, and black-and-white in a single
scanning pass
True 48-bit color (approx. 281 billion colors)
16-bit grayscale (approx. 65,536 shades of gray)
Reflective: 12" x 17" (305 mm x 432 mm)
Transparent: 12" x 16" (305 mm x 405 mm)
Optical: 6400 dpi x 3200 dpi
Interpolated: 25,600 dpi x 25,600 dpi
4.0 Dmax
Hi-Speed USB (USB 2.0) and FireWire (IEEE 1394
standard)
24.7" x 14.8" x 5.1" / 627.5 x 375.9 x 129.5 mm;
24.7" x 14.8" x 7.1" / 627.5 x 375.9 x 180.5 mm
(with TMA 1000XL)
26.4 lbs / 12 kg; 35.4 lbs / 16.1 kg (with TMA 1000XL)
AC 100V to 240V,
1A max; 47-63 Hz
44W max.
Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
