B. Using the 35mm Filmstrip Template
To scan 35mm filmstrips, use the 35mm Filmstrip Template, which can simultaneously
hold two strips of 6 frames each, or a total of 12 frames.
1. Place the 35mm filmstrip to be scanned inside the frame of the 35mm Filmstrip
Orient template with
"Microtek" logo facing up
2. Place the 35mm Filmstrip Template containing the loaded filmstrip on the
Calibration strip
Microtek logo
Template. The shiny base of the 35mm filmstrip should be facing down, and the
emulsion side of the filmstrip should be facing up.
scanner glass surface. Make sure to orient the template with the "Microtek"
logo facing up.
Align the edge of the film frame
with the arrow mark of the template
The Grabber is used to remove the
template out of the scanner glass
surface.
Important: Align the template's
front corners firmly against the top
corners (left and right) of the
U-shaped ruler located at the front
of the scanner. During placement of
the template, make sure that the
calibration strip on the scanner
glass surface is kept clear and free
of obstruction at all times.
ScanMaker 1000XL Supplement 11
