Microtek ArtixScan 6000XY Operation Manual page 21

• To remove the lamp, first push the lamp to the back of the scanner.
• Then pull the lamp out.
• Insert a new lamp. Make sure the lamp window faces upwards and inwards.
Note: Always replace both scanning lamps, even if only one is faulty.
7. Using the handles to lift the glass, then place it back in its original scan bed.
8. Thread the 4 screws that secure the glass to the scanner. To tighten the screws,
rotate the screws 90° clockwise.
Top view of screw caps is shown below.
Open
9. To verify if the new scanning lamps work, scan a photograph in the reflective mode.
Closed
ArtixScan 6000XY Installation and Operation Manual
Push the lamp to the
back of the scanner.
21
