4.1 Battery Clips

Pin Function
1 GND
2 VBAT

4.2 Grove Connectors

4.2.1 A0
Pin
1
2
3
4
4.2.2 A6
Pin
1
2
3
4

4.2.3 I2C

Pin
1
2
3
4
12 / 18
Type
Power
Power
Function
AN0
NC
+5V
GND
Function
AN6
NC
+5V
GND
Function
SCL
SDA
+5V
GND
Arduino® MKR IoT Carrier Rev2
Arduino® MKR IoT Carrier
Description
Ground
Positive 18650 Battery Terminal
Type Description
Analog Analog Input 0
NC Not Connected
Power +5.0V power rail
Power Ground
Type Description
Analog Analog Input 6
NC Not Connected
Power +5.0V power rail
Power Ground
Type Description
Digital I2C Clock Signal
Digital I2C Data Signal
Power +5.0V power rail
Power Ground
