F-SM-MM-04

CABLE SPECIFICATIONS

The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Bit Error Rate:
Multimode - 1000Base-SX
Multimode fiber (recommended):
Multimode fiber (optional):
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Minimum cable distance*
Typical maximum cable distance*
Singlemode - 1000Base-LX
Singlemode fiber (recommended):
F-SM-MM-04
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Minimum cable distance*
Typical maximum cable distance*
F-SM-MM-04(LH)
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Spectral Width:
Minimum Attenuation
Typical maximum cable distance*
F-SM-MM-04(LW)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Spectral Width:
Minimum Attenuation
Typical maximum cable distance*
* Actual distance is dependent upon the physical characteristics of the network
installation.
4 Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST (GMT-6:00)
<10 -12
850 nm
62.5/125 µm
50/125 µm
min: -10.0 dBm max: -4.0 dBm
min: -17.0 dBm max: 0.0 dBm
7.0 dB
2 meters (6.6 ft)
•Km
220 meters for 160/500 MHz
270 meters for 200/500 MHz •Km
9 µm
1300 nm
min: -13.0 dBm max: -3.0 dBm
min: -20.0 dBm max: -3.0 dBm
7.0 dB
2 meters (6.6 ft)
m (6.2 miles)
10 k
1310 nm
min: -5.0 dBm max: 0.0 dBm
min: -20.0 dBm max: -3.0 dBm
15.0 dB
5.9 nm FWHM
3.0 dB
25 km (15.5 miles)
1550 nm
min: -3.0 dBm max: +2.0 dBm
min: -23.0 dBm max: -3.0 dBm
20.0 dB
2.3 nm FWHM
5.0 dB
65 km (40.4 miles)

TECHNICAL SPECIFICATIONS

For use with Transition Networks Model F-SM-MM-04 or equivalent
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR, Subchapter J
applicable at the date of manufacture.
Standards: IEEE 802.3™
Data Rate: 1000 Mb/s
Case Dimensions: 4.7" x 3.0" x 1.0" (119 mm x 76 mm x 25 mm)
Weight: 1 pounds (0.45 kilograms) (approximate)
Power Consumption: 3.3 W
Power Supply DC Output: 12VDC, 500 mA (minimum)
minimum output regulation: 5%
Connector: 2.1mm barrel, center pin positive
MTBF 51,185 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
124,339 hours (Bellcore7 V5.0)
Environment: Tmra*:
Storage Temp:
Humidity:
Altitude:
Warranty: Lifetime
*Manufacturer's rated ambient temperature.
CAUTION: Visible and Invisible Laser Radiation When Open. Do Not Stare Into Beam
Or View Directly With Optical Instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other than
those specified herein may result in hazardous radiation exposure.
techsupport@transition.com -- Select the "Transition Now" Link for a Live Web Chat
0 to 50°C (32 to 12°F)
-20 to 85°C (-4 to 185°F)
10-90%, non condensing
0-10,000 feet
