Table of Contents

Advertisement

Quick Links

Download this manual
Part 1
Galaxy SC Controller
J85501F-1
Product Manual
Select Code 167-790-060
Comcode 107330946
Issue 13
February 2001

Advertisement

Table of Contents
loading

Related Manuals for Tyco Galaxy SC Controller

Summary of Contents for Tyco Galaxy SC Controller

  • Page 1 Part 1 Galaxy SC Controller J85501F-1 Product Manual Select Code 167-790-060 Comcode 107330946 Issue 13 February 2001...
  • Page 3 Every effort was made to ensure that the information in this document was complete and accurate at the time of printing. However, information is subject to change. © 2001 Tyco Electronics Corporation, Harrisburg, PA. All Rights Reserved Printed in U.S.A.
  • Page 5 2 - 2 Intelligent Controller 2 - 2 Backplane 2 - 3 Circuit Packs Used in the Galaxy SC Controller 2 - 4 BJA1 or BJA2 (Basic Controller Power Board) 2 - 4 BJB1 (Basic Controller Digital Board) 2 - 4...
  • Page 6 Tyco Electronics Galaxy SC Controller J85501F-1 Display Software Version 2 - 8 Display Language 2 - 8 Display Conventions 2 - 9 Default Display 2 - 9 Menu Organization 2 - 10 Menu Operations 2 - 12 3 Installation Overview...
  • Page 7 Tyco Electronics Galaxy SC Controller J85501F-1 Place Plant Rectifiers Under Galaxy Control 3 - 35 Galaxy SC Configuration 3 - 35 Rectifier VI Circuit Adjustment 3 - 35 Galaxy Option Features 3 - 36 Intelligent Controller (J85501F1 L- AB or AC)
  • Page 8 Tyco Electronics Galaxy SC Controller J85501F-1 Slope Thermal Compensation Menu 4 - 35 Battery Control Menu 4 - 36 Battery Discharge Test Menu 4 - 37 Communication Ports (PORT) Menu 4 - 39 Low Voltage Disconnect Menu 4 - 40...
  • Page 9 Tyco Electronics Galaxy SC Controller J85501F-1 System Software 4 - 63 System Time 4 - 63 Timer Events 4 - 64 Configuration From a Remote Terminal 4 - 64 T1.317 Command Language 4 - 64 Connecting a Terminal to Galaxy SC...
  • Page 10 Tyco Electronics Galaxy SC Controller J85501F-1 Change Plant Mode 6 - 2 Change Plant Voltage (Serial Bus Rectifiers Only) 6 - 2 Clear Latched Events 6 - 2 Display Alarm Data 6 - 2 Display Warning Data 6 - 2...
  • Page 11 Tyco Electronics Galaxy SC Controller J85501F-1 Rectifier Control 6 - 13 Rectifier Removal (Serial Bus Rectifiers Only) 6 - 13 Rectifier Restart 6 - 13 Statistics 6 - 13 T1.317 Interface Common Access and Control Functions 6 - 14 AC Distribution Management...
  • Page 12 Tyco Electronics Galaxy SC Controller J85501F-1 Upgrading the Intelligent Controller Software 6 - 37 Statistics Usage 6 - 38 Timer Events Management 6 - 38 User-Defined Event Management 6 - 39 7 Feature Descriptions AC Distribution 7 - 2 Alarm Cut-Off (ACO)
  • Page 13 Tyco Electronics Galaxy SC Controller J85501F-1 Low Voltage Disconnect (LVD) 7 - 28 Low Voltage Load Disconnect (LVLD) 7 - 28 Low Voltage Battery Disconnect (LVBD) 7 - 29 Maintenance Reminder 7 - 31 Notepad 7 - 31 Periodic Status Call-Out...

  • Page 14: Table Of Contents

    Tyco Electronics Galaxy SC Controller J85501F-1 Effect of Changing Date and Time 7 - 56 Effect of Changing Scale Factor, Range or Channel Type 7 - 56 Terminal Menu Interface 7 - 56 Timer Events 7 - 56 User Defined Events...
  • Page 15 Tyco Electronics Galaxy SC Controller J85501F-1 Operation Commands A - 5 Reporting Commands A - 10 System Defined Aliases A - 14 Error Reporting A - 15 Appendix B T1.317 Objects and Attributes Appendix C T1.317 Error Messages Error Messages and Causes...
  • Page 16 Tyco Electronics Galaxy SC Controller J85501F-1 TL1 Commands Supported by Galaxy D - 18 Commands from OSs D - 19 Autonomous Commands From Galaxy (NE) to OS D - 25 Bellcore Reference Documents D - 26 Appendix E Terminal Menu Interface...
  • Page 17 Tyco Electronics Galaxy SC Controller J85501F-1 List of Figures Figure 1-1: Galaxy SC Controller 1 - 1 Figure 2-1: Galaxy SC Controller With Door Open (Basic Circuit Packs At Right of Cabinet, Intelligent Circuit Packs At Left) 2 - 2...
  • Page 18 Tyco Electronics Galaxy SC Controller J85501F-1 Figure 3-13: Connections from Galaxy Local Port to PC/Printer (top) and PAD/DSU (bottom) 3 - 45 Figure 3-14: Connecting Remote Peripheral Interface Bus Wiring to Galaxy SC Controller 3 - 47 Figure 3-15: Wiring for Rectifier Sequencing (TFLT=Tell to Float;...
  • Page 19 Tyco Electronics Galaxy SC Controller J85501F-1 List of Tables Table 3-A: Standard Galaxy SC Controller Circuit Packs 3 - 6 Table 3-B: Galaxy SC High Voltage Shutdown Setting -48V 3 - 8 Table 3-C: BJA High Voltage Shutdown Setting +/-24V...
  • Page 20 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-7: Rectifiers Objects and Attributes B - 9 Table B-8: Converter Management Objects and Attributes B - 10 Table B-9: Battery Management Objects and Attributes B - 11 Table B-10: Alarm And Events Objects and Attribute...

  • Page 21: Figure 1-1: Galaxy Sc Controller

    Tyco Electronics Galaxy SC Controller J85501F-1 Introduction The Product This product manual (Select Code 167-790-060) describes the Tyco Electronics Galaxy SC Controller, J85501F-1. Although the J85501F-1 is available in both rear-access (SC) and front-access (SCF) models, this manual is a user’s guide for the rear access controller (SC) only.
  • Page 22 A tutorial section teaches you how to operate the Galaxy SC Controller from its front panel, from a remote terminal, or from a personal computer that emulates a terminal.
  • Page 23 8:00 a.m. until 4:30 p.m., Central Time Zone (Zone 6), Monday through Friday. Customer Training Tyco Electronics offers customer training on many Power Systems products. For information call 1-972-284-2163. This number is answered from 8:00 a.m. until 4:30 p.m., Central Time Zone (Zone 6), Monday through Friday.
  • Page 25 Tyco Electronics Galaxy SC Controller J85501F-1 Product Description Overview The Galaxy SC Controller represents a major advance in the ability to monitor and control telecommunications power equipment. It can control large battery plants containing up to 64 rectifiers of virtually any type, old or new, made by Tyco Electronics or other manufacturers.

  • Page 26: Figure 2-1: Galaxy Sc Controller With Door Open

    Tyco Electronics Galaxy SC Controller J85501F-1 ESD Wrist Strap Jack Local PC Port RS232 Figure 2-1: Galaxy SC Controller With Door Open (Basic Circuit Packs At Right of Cabinet, Intelligent Circuit Packs At Left) Basic Controller The basic controller (sometimes referred to as “independent”...
  • Page 27 Tyco Electronics Galaxy SC Controller J85501F-1 Battery prediction, an option that predicts reserve time for batteries made by Tyco Electronics Data Switch, an optional interface with RS-232 devices such as XCS, ECS, RAS, and OMNIpulse units. Data Switch permits a single phone line to access four separate units in addition to the Galaxy SC.
  • Page 28 BJC1 provides the circuitry to interface with Interface Board) Tyco Electronics rectifiers with VI signals for monitoring the rectifier load). BJC2 provides the same functions for Tyco Electronics switch mode rectifiers and non-Tyco rectifiers with mV shunt signals. The Galaxy SC can control a total of up to 64 rectifiers.
  • Page 29 Tyco Electronics Galaxy SC Controller J85501F-1 BJF1 or BJF2 This board is always present in the controller. It contains the input power (Termination Fuse terminal blocks and fuses for the controller. BJF1 is for negative voltage Board) plants, BJF2 is for positive voltage plants.

  • Page 30: Figure 2-2: Galaxy Sc Controller Rectifier Interface Modules

    OPTION AUX PORT MODEM Figure 2-2: Galaxy SC Controller Rectifier Interface Modules User Interface The Galaxy SC’s primary user interface is a panel that includes a backlit LCD front panel display, two rows of LEDs, two sets of test jacks, and and Display an array of simple pushbutton controls.

  • Page 31: Figure 2-3: Galaxy Sc Controller Front Panel

    ESCAPE TEST CRIT NORM Figure 2-3: Galaxy SC Controller Front Panel LEDs Two rows of LEDs at the left side of the interface board show the source and severity of various alarms. An alarm will light two LEDs: one alarm LED and one status LED.
  • Page 32 Tyco Electronics Galaxy SC Controller J85501F-1 well as in many other controller features. There may be plant configurations, especially those in a distributed power architecture, that do not contain a single main battery or load shunt. In these cases, remote peripheral shunt modules are typically used to measure the many different battery string shunts.
  • Page 33 Tyco Electronics Galaxy SC Controller J85501F-1 phrases. The third option is reserved for another language. To change the display language, first make sure that the default screen is on (one quick way to get the default screen is press MENU key to display the MAIN menu, then press the ESCAPE key).

  • Page 34: Figure 2-4: Hierarchical Overview Of Basic Controller Menu (Version 7.3.0)

    Tyco Electronics Galaxy SC Controller J85501F-1 as battieries discharge or load changes. The information on the screen is updated automatically approximately every two seconds. Menu The front panel display offers you a series of menus. Figure 2-4 is the Organization hierachical overview of Galaxy SC’s Basic Controller menu.

  • Page 35: Figure 2-5: Hierarchical Overview Of Intelligent Controller (Version 7.3.0)

    Tyco Electronics Galaxy SC Controller J85501F-1 Plant Date Unmap BIC Rectifier Definition Alarms Rectifier Control Shunt V/I, Type Rectifier Rectifier Operation Adjust Plant V/I Manager Time Slope Thermal Battery Manager Compensation Reset Plant V/I Converter Main Menu Battery Control Manager...
  • Page 36 Tyco Electronics Galaxy SC Controller J85501F-1 Menu This section provides the information on how to move from one screen to the others. From any screen, press the MENU key to bring the MAIN Operations MENU which is the first menu in the series. In any menu screen, use the UP, DOWN, LEFT, and RIGHT ARROW keys to move among the menu items.
  • Page 37 Tyco Electronics Galaxy SC Controller J85501F-1 The value of the menu field is displayed as the combination of hardware and software switches as shown below: Hardware SW Software SW Field value OFF (0) DIS(HW,SW) OFF (0) DIS(HW) ON (1) DIS(SW)
  • Page 39 Tyco Electronics Galaxy SC Controller J85501F-1 Installation Overview The Galaxy SC Controller can be installed as part of a new plant or can replace the controller of an existing plant. This chapter is broken down into four sections: • New Plant Installation •...
  • Page 40 Grounding Connect the Galaxy SC to frame ground through its mounting brackets. Tyco Electronics recommends that all powered units be grounded directly using 2-hole wiring termination. A terminal lug (WP91412 L-73, comcode 405356171) is provided that accepts 10-14 AWG and mounts in the upper right rear corner of the chassis.
  • Page 41 Tyco Electronics Galaxy SC Controller J85501F-1 L-31 to L-35 have eight ports each, one per assigned rectifier. Up to three of any of these modules may be utilized concurrently, for a maximum of 24 parallel interface rectifiers in the plant. L-36 has a single serial rectifier interface port for use with up to 64 serial interface rectifiers.

  • Page 42: Figure 3-1: Details Of Galaxy Sc's Circuit Board Positions

    To handle both types of rectifier, Galaxy SC must be equipped with both parallel (BJC1 and/or BJC2) and serial (BJC3) rectifier interface boards. Authorized ferro rectifiers include Tyco J85502B and C, all series, 200A; J85503A, B2, C2 and C3, 400A; RL200D50; RL400D50;...
  • Page 43 Tyco Electronics Galaxy SC Controller J85501F-1 Note: If these numbering instructions are not followed, the information from the mis-numbered serial rectifiers will overwrite the information from the ferros if they unintentionally share the same position. 2. When ferros and serial rectifiers are mixed, the rectifier alarms...

  • Page 44: Table 3-A: Standard Galaxy Sc Controller Circuit Packs

    2. Disengage all of the equipped packs by pulling down on the circuit pack latch and sliding the board away from the backplane. Do not remove the board completely from the guides. Table 3-A: Standard Galaxy SC Controller Circuit Packs Board Location...
  • Page 45 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-A: Standard Galaxy SC Controller Circuit Packs Board Location Function Code 8th From Right Intelligent Controller (if equipped) 9th From Right Modem Board (if equipped) Intelligent Power Board (if Far Left equipped) Any vacant...

  • Page 46: Table 3-B: Galaxy Sc High Voltage Shutdown Setting -48V

    Tyco Electronics Galaxy SC Controller J85501F-1 a feature that you wish to allow a user to enable from Galaxy SC’s front panel or by remote access. Table 3-B: Galaxy SC High Voltage Shutdown Setting -48V SW201 Bottom SW200 Top Voltage 50.00...
  • Page 47 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-B: Galaxy SC High Voltage Shutdown Setting -48V SW201 Bottom SW200 Top Voltage 53.50 *.60 (default) 54.00 54.50 55.00 55.50 56.00 56.50 57.00 Issue 13 February 2001 Installation 3 - 9...
  • Page 48 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-B: Galaxy SC High Voltage Shutdown Setting -48V SW201 Bottom SW200 Top Voltage 57.50 58.00 58.50 59.00 59.50 60.00 *Default setting = 53.60 1 = closed 0 = open 3 - 10 Installation...

  • Page 49: Table 3-C: Bja High Voltage Shutdown Setting +/-24V

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-C: BJA High Voltage Shutdown Setting +/-24V SW201 Bottom SW200 Top Voltage 24.80 25.00 25.25 25.50 25.75 26.00 26.25 26.50 Issue 13 February 2001 Installation 3 - 11...
  • Page 50 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-C: BJA High Voltage Shutdown Setting +/-24V SW201 Bottom SW200 Top Voltage 26.75 *.80 (default) 27.00 27.25 27.50 27.75 28.00 28.25 28.50 3 - 12 Installation Issue 13 February 2001...
  • Page 51 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-C: BJA High Voltage Shutdown Setting +/-24V SW201 Bottom SW200 Top Voltage 28.75 29.00 29.25 29.50 29.75 30.00 30.25 30.50 Issue 13 February 2001 Installation 3 - 13...

  • Page 52: Table 3-D: Switch Positions For Galaxy Controller Basic

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-C: BJA High Voltage Shutdown Setting +/-24V SW201 Bottom SW200 Top Voltage 30.75 31.00 *Default setting = 26.80 1 = closed 0 = open Table 3-D: Switch Positions for Galaxy Controller Basic and Intelligent Boards...
  • Page 53 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-D: Switch Positions for Galaxy Controller Basic and Intelligent Boards Circuit Pack Switch Pos Default Description Closed Is (1) Open Is (0) Remote rectifier in SW203-8 Enabled Disabled standby Remote rectifier turn SW203-7...

  • Page 54: Figure 3-2: Bjf Circuit Pack

    Tyco Electronics Galaxy SC Controller J85501F-1 Power Fuses Battery Thermal Protection Provides system voltage to TB3 position 45. Alarm Battery Supply Provides system voltage to TB3 positions 30, 31, 46, and 47. Provides system voltage to Tyco ferro rectifiers to...

  • Page 55: Figure 3-3: Shunt Diagram

    L-31, refer to Figure 3-4 for proper connector orientation information for the three varieties of connectors which may be encountered. The Galaxy SC can interface with up to 64 Tyco Electronics serial rectifiers, 32 bay interface cards, and 16 converters via a serial interface cable.

  • Page 56: Figure 3-4: Control Cable Connectors

    Tyco Electronics Galaxy SC Controller J85501F-1 Note: The modification of control cables for rectifier identification (cutting TP leads) is not required for use with Galaxy SC. Rectifier Interface Module Correct Orientation for Three Types of Control Cable Connectors (MCS Compatible L-31)

  • Page 57: Table 3-E: Galaxy Controller Rectifier And Cabling Information

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-E: Galaxy Controller Rectifier and Cabling Information For Any of These Rectifiers Used With Any of These Cables Order Rectifier Interface Module Rectifier Allowed Cable Codes Amps Volts Notes Codes (Length) J85501F-1 List...
  • Page 58 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-E: Galaxy Controller Rectifier and Cabling Information For Any of These Rectifiers Used With Any of These Cables Order Rectifier Interface Module Rectifier Allowed Cable Codes Amps Volts Notes Codes (Length) J85501F-1 List...

  • Page 59: Table 3-F: Galaxy Sc Controller Commercial Rectifier Cable

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-F: Galaxy SC Controller Commercial Rectifier Cable (H285-226 G62) Connection Information Cable Galaxy SC Wire Signal Description Signal Name Color (W-BL) Positive voltage polarity from point of regulation (BL-W) Negative voltage polarity from point of regulation...
  • Page 60 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-F: Galaxy SC Controller Commercial Rectifier Cable (H285-226 G62) Connection Information Cable Galaxy SC Wire Signal Description Signal Name Color Positive potential shunt voltage. Signal from the rectifier, used in conjunction with SH-, to provide a differential shunt voltage with the range of (0mVDC to 150mVDC) to the Galaxy SC.

  • Page 61: Table 3-G: J85501F-1 List Options

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-G: J85501F-1 List Options List Description Section 3 Heading Intelligent Controller Option Intelligent Controller With TL1 Interface Modem Modem Option Remote Peripheral Monitoring Peripheral Monitoring Option Data Switch Data Switch Option Battery Reserve Time Predictor...
  • Page 62 The accuracy of this circuit is essential for proper operation of Galaxy SC’s Energy Management feature and to eliminate nuisance “Rectifier/Plant Drain Inconsistency” alarms or warnings. Check and adjust the VI circuit of each Tyco Electronics ferroresonant rectifier in accordance with the appropriate Rectifier Product Manual.

  • Page 63: Figure 3-5: Bjt1 Terminal Block

    Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy SC Galaxy SC provides clean contact “Form-C” alarm indications for use External Alarms by the customer to transmit its alarms to an office or remote alarm sensing circuit. These contacts are rated for 60 VDC maximum, at 0.3 amperes.

  • Page 64: Table 3-H: Alarm Signal Outputs

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-H: Alarm Signal Outputs Asserted Asserted Signal Signal Description Contact Description Contact Name Name Condition Condition PCREC Closed Closed MJFC PCRER Return Power Critical External Return MJFR Major Fuse PCREO Open Open MJFO...
  • Page 65 Tyco Electronics Galaxy SC Controller J85501F-1 MCS Controller This section provides a method for changing the standard J85501A2 MCS Controller with the J85501F1 Galaxy Controller. Note that if this Retrofit procedure is adapted for retrofits of other types of controllers such as CCS, Galaxy compatable rectifier control cables and possibly different rectifier circuit packs will be necessary.
  • Page 66 Tyco Electronics Galaxy SC Controller J85501F-1 3. Locate the ED-83009 circuit pack in the right-hand side of the controller. Toggle the EFF/DIS switch to the upward (Disabled) position. Plant Eff Status and System Alarm LEDS in the MCS will activate. Verify that All rectifiers are turned on before proceeding.

  • Page 67: Figure 3-6: Mcs Tb1 Alarm Connections

    Tyco Electronics Galaxy SC Controller J85501F-1 Repeat this procedure for each additional rectifier. When complete, verify the plant charge bus is within tolerance and make final adjustments if necessary. Remove TB1 Warning: Verify that only one wire is terminated on TB2 pins 1 and 2 Alarm Wiring on the controller.

  • Page 68: Table 3-I: Mcs/Galaxy Alarm Connections

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-I: MCS/Galaxy Alarm Connections MCS Connections Equivalent Galaxy Connections Signal Wire Color MCS TB1 Pin #Galaxy TB & Pin # Connect to Signal TB3-2 CTLR UPFR TB3-18 CTLR TB3-40 TB3-24 TRTN S1(A) TB2-13...
  • Page 69 Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-I: MCS/Galaxy Alarm Connections MCS Connections Equivalent Galaxy Connections Signal Wire Color MCS TB1 Pin #Galaxy TB & Pin # Connect to Signal TB2-7 PMN-A (C) PMNR TB2-23 PMN-A (R) PMNV TB2-8 PMN-V(C)
  • Page 70 Tyco Electronics Galaxy SC Controller J85501F-1 Mount the Galaxy 1. Mount the Galaxy Controller into the space vacated by the MCS Controller Controller. 2. Tighten all mounting bolts. 3. The Galaxy controller is grounded to the framework. For customers that require a two hole ground lug termination for all powered units, connect the WP91412 L-73 (10-14 gauge wire) lug provided to the Galaxy’s external ground holes located on the top...
  • Page 71 Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy Circuit Warning: Observe the following ESD (Electrostatic Discharge) Packs precautions: • Wear grounded antistatic wrist straps when handling all circuit packs. • The wrist strap must contact the skin and is not to be worn over clothing.
  • Page 72 Tyco Electronics Galaxy SC Controller J85501F-1 Controller Fusing Remove the BASIC, INTEL and PER MON fuses from the BJF Fuse/Termination board located to the right of the Basic side circuit packs, using the fuse puller provided. Insure that all other fuses on this board are fully engaged.
  • Page 73 Tyco Electronics Galaxy SC Controller J85501F-1 2. Reinsert the BASIC, INTEL, and PER MON fuses into their positions in the BJF board. See Figure 3-2. 3. Reinsert the Galaxy BJA (and if equipped, BJJ) Power board(s) into the backplane of the Galaxy and lock into place by lifting the circuit pack locking lever to its full upright position.
  • Page 74 Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy Option The following Galaxy optional features require the addition of external equipment or wiring. Install them as described below. Features Intelligent The Intelligent Controller Option is required for any of the more Controller advanced Galaxy features to function.

  • Page 75: Figure 3-7: Rs485 And Rs232 Auxiliary Port Connections For Pad/Dsu (Top) And Pc Or Non-Pad/Dsu (Bottom)

    Tyco Electronics Galaxy SC Controller J85501F-1 Intelligent Board Cable Interface TXD3+ TXD3- RS485* RXD3+ Connections RXD3- TXD3 RXD3 RS232* Connections to PAD/DSU Intelligent Board Cable Interface TXD3+ TXD3- RS485* RXD3+ Connections RXD3- RXD3 TXD3 RS232* PC (DB9) (DTR) Connections (DSR)
  • Page 76 Tyco Electronics Galaxy SC Controller J85501F-1 Modem (J85501F1 The Modem option permits communication over the public network L-AE) analog lines at baud rates of up to 19200. This option is necessary for Call Out on Alarm and to enable the Data Switch option to access the public network.

  • Page 77: Figure 3-8: Data Switch Interface Card

    Tyco Electronics Galaxy SC Controller J85501F-1 slot chosen for the Data Switch BJK circuit pack and secure with the mounting screw provided on the card. Refer to Figure 2-2 for backplane mounting locations. 2. The Data Switch Interface card contains four DB9, 9-pin serial port plugs for wiring to the connecting devices.

  • Page 78: Table 3-J: Data Switch Cable Interface

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 3-J shows the signal descriptions, wire colors, etc. for the cable assembly used to interface external equipment to the Data Switch option of the Galaxy controller. The cable assembly comcode is 847540416. Table 3-J: Data Switch Cable Interface...
  • Page 79 Tyco Electronics Galaxy SC Controller J85501F-1 signal may not be required by the connected equipment, and a connection is not required by the controller. • Signal Ground is the normal ground or return signal on an RS232 type interface. It is roughly at earth ground potential.

  • Page 80: Figure 3-9: Connections From Galaxy Data Switch To Ecs Controller, Omnipulse, Or Another Galaxy

    Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy Controller ECS Controller, OMNIpulse, or Data Switch Port Secondary Galaxy Controller DB9 Connector Local Port Pin # Pin # Blue ALARM Orange Brown Slate Alarm Contacts White Black Yellow Violet ALARMR (GRD) Galaxy Controller...

  • Page 81: Figure 3-10: Connections From Galaxy Data Switch To Ras

    Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy Controller Data Switch Port DB9 Connector RAS P303 Pin # Pin # Blue ALARM Orange Brown Slate Alarm Contacts White Black Yellow Violet ALARMR (GRD) RAS SW301 1-Open 2-Open 3-Open 4-Closed 5-Open 6-Open...

  • Page 82: Figure 3-11: Connections From Galaxy Data Switch To Mcs Controller Remote Interface Pack

    Tyco Electronics Galaxy SC Controller J85501F-1 Figure 3-11: Connections from Galaxy Data Switch to MCS Controller Remote Interface Pack Figure 3-12: Connections from Galaxy Data Switch to XCS Controller 3 - 44 Installation Issue 13 February 2001...

  • Page 83: Figure 3-13: Connections From Galaxy Local Port To Pc/Printer (Top) And Pad/Dsu (Bottom)

    Tyco Electronics Galaxy SC Controller J85501F-1 Figure 3-13: Connections from Galaxy Local Port to PC/Printer (top) and PAD/DSU (bottom) Issue 13 February 2001 Installation 3 - 45...
  • Page 84 Tyco Electronics Galaxy SC Controller J85501F-1 Remote Peripheral The Remote Peripheral Monitoring Option of Galaxy provides data Monitoring acquisition capability far beyond that normally available in a power (J85501F1 L-AG, plant controller. Presently, the monitoring modules available from the J85501G1)

  • Page 85: Figure 3-14: Connecting Remote Peripheral Interface Bus Wiring To Galaxy Sc Controller

    Tyco Electronics Galaxy SC Controller J85501F-1 Secure to backplane Cable Assembly* using screw provided From first RPM module in Bus 1 chain - TB102 (In) Inductor Bead Bus 1 Bus 2 To Galaxy Backplane Shield Shield Wire Bus 3 RPM communication bus wire must be...
  • Page 86 Tyco Electronics Galaxy SC Controller J85501F-1 7. Once they have been energized, the modules will begin their initialization sequence. This will take some time, depending on the number of modules equipped in the system. During initialization, Galaxy automatically senses and adds module and channel objects to the system.
  • Page 87 Tyco Electronics Galaxy SC Controller J85501F-1 Battery Reserve This optional feature requires no additional circuit packs, but does Time Prediction require that a temperature probe be added to provide Galaxy with the (J85501F1 L-K1) temperature of one of the plant battery strings. Once this probe is in place and wired, the feature is enabled through software.

  • Page 88: Figure 3-15: Wiring For Rectifier Sequencing (Tflt=Tell To Float; Tbst=Tell To Boost)

    Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy BJT Alarm Board External Transfer Signals TB3 # Closure with Essential AC Bus Failure ETRR Open with AC Available to Rectifiers Closure with Reserve Generator On External Rectifier Sequencer Figure 3-15: Wiring for Rectifier Sequencing (TFLT=Tell to Float;...
  • Page 89 Tyco Electronics Galaxy SC Controller J85501F-1 Supplemental In addition to the 20 sets of “Form-C” alarm outputs available on the Alarm Input BJT TB2 and TB3 terminal blocks, the following additional related alarm wiring may be necessary. Which of these alarms are to be wired and how or where they terminate outside of the Galaxy is the responsibility of the party engineering the system.

  • Page 90: Figure 3-16: Wiring For External Boost Option

    In addition, BJB SW202-2 and SW202-3 must be enabled (see Table 3-D) and the connected rectifiers must be capable of accepting the boost signal from Galaxy. Tyco Electronics rectifiers which presently accept boost include J85502C1 (125A), J85503B2 (200A), J85503C2/3 (400A), J85603C2 (400A), J85702E1 (SR150A), SR50, and SR100 plus all serial interface rectifiers.

  • Page 91: Figure 3-17: Connections For Battery Thermal Protection

    Tyco Electronics Galaxy SC Controller J85501F-1 accepting a boost signal from Galaxy. Tyco Electronics rectifiers which presently accept boost include J85502C1 (125A), J85503B2 (200A), J85503C2/3 (400A), J85603C2 (400A), J85702E1 (SR150A), SR50, and SR100 plus all serial interface rectifiers. When setting up BTP, it is also necessary to properly set each rectifier boost volts adjustment potentiometer for the lower BTP voltage level desired.
  • Page 92 Tyco Electronics Galaxy SC Controller J85501F-1 with Step 2. If the pack is or will be located on the Basic side (first eight positions from the right) it may be “hot inserted”. Jump to Step 3. Warning: Failure to power down the Intelligent power board (BJJ) when installing or removing Intelligent side packs may result in permanent damage to the Galaxy controller.
  • Page 93 Tyco Electronics Galaxy SC Controller J85501F-1 Configuration Introduction At initial plant power-up, the Galaxy SC Controller is factory-set for almost all required alarm and control functions as depicted in Tables 4-A, 4-B. and 4-C. In addition to these parameters, the controller must be configured as follows: •...

  • Page 94: Table 4-A: Voltage Threshold Ranges And Default Values

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 4-A: Voltage Threshold Ranges and Default Values High Default Very Low Voltage (VLV) 20.00 25.00 23.00 40.00 51.00 46.00 Battery on Discharge (BD) 23.00 28.00 25.00 24V Float 23.00 28.00 25.00 24V Boost 46.00...
  • Page 95 Tyco Electronics Galaxy SC Controller J85501F-1 Table 4-B: Plant Alarm Severity, LED, and Relay Defaults Symbol Default (* denotes Latched Default Designation Default LED Default Relay Severity alarm event) ACO Active None None Alarm Battery Supply Fuse Major CTLR CTLR...
  • Page 96 Tyco Electronics Galaxy SC Controller J85501F-1 Table 4-B: Plant Alarm Severity, LED, and Relay Defaults Symbol Default (* denotes Latched Default Designation Default LED Default Relay Severity alarm event) CNF2 Contactor 2 Failed Major None None CNF3 Contactor 3 Failed...

  • Page 97: Table 4-B: Plant Alarm Severity, Led, And Relay Defaults

    Tyco Electronics Galaxy SC Controller J85501F-1 Table 4-B: Plant Alarm Severity, LED, and Relay Defaults Symbol Default (* denotes Latched Default Designation Default LED Default Relay Severity alarm event) Measurement Out Of Range Minor None Module Type Conflict Minor None...
  • Page 98 Tyco Electronics Galaxy SC Controller J85501F-1 Table 4-C: Rectifier Alarm Defaults Default Symbol Default Designation Default LED Default Relay Severity External Transfer Minor RECT None Shutdown Half Power Minor RECT None Low Current Alarm Minor RECT None Load Share Fuse...
  • Page 99 Tyco Electronics Galaxy SC Controller J85501F-1 for specific T1.317 commands which can perform each of Galaxy SC’s features. Refer to “Configuration From a Remote Terminal.” Basic Note: The section below shows examples of menu screens displayed on Galaxy’s front panel. These displays may differ slightly from Controller version to version of the Galaxy software.
  • Page 100 Tyco Electronics Galaxy SC Controller J85501F-1 CONFIGURATION YOU ARE AUTHORIZED TO CHANGE THE SYSTEM CONFIGURATION PRESS ENTER TO CONTINUE OR OTHER KEY TO ABORT Press <ENTER> to bring up the Configuration main screen. CONFIG PLANT.. THRESH.. ALARM.. RECT.. LVD.. RECT MNGR..
  • Page 101 Tyco Electronics Galaxy SC Controller J85501F-1 Note that this field must only be configured when the Shunt Type for the plant is LOAD or BATTERY. If Shunt Type is set to NONE, this field has no function. SHUNT I: To configure the Plant Current shunt, move the cursor to the SHUNT I field by using the <UP>/<DOWN>/<LEFT>/<RIGHT>...
  • Page 102 Tyco Electronics Galaxy SC Controller J85501F-1 change to the adjusted value. Instead, the actual voltage of the plant will adjust by the difference between the value inputted and the level set in Rectifier Manager. To verify that the adjustment has been made, make the voltage reading at the plant jacks or batteries once again with a VOM and compare to Galaxy’s displayed value.
  • Page 103 Tyco Electronics Galaxy SC Controller J85501F-1 battery shunt to monitor the currents of all the plant batteries. The load current displayed on the front panel is derived from the battery current and the total rectifier output current. A shunt type of NONE is selected for distributed architectures where no shunt is directly connected to the shunt terminations of TB1 on the BJF card of the Galaxy.
  • Page 104 Tyco Electronics Galaxy SC Controller J85501F-1 is on this field, pressing the <ENTER> key will zero out the delta for the plant current. The plant current value displayed now is the true value as computed by Galaxy SC from the shunt reading.
  • Page 105 Tyco Electronics Galaxy SC Controller J85501F-1 and activate the PMN contact closure (assuming there is no alarm with CRITICAL or MAJOR severity level active). The purpose of this alarm is to indicate that the plant voltage is high, probably due to an adjustment in the plant rather than due to a failure.
  • Page 106 Tyco Electronics Galaxy SC Controller J85501F-1 Alarm Menu From the CONFIGURATION menu, select ALARM to bring up the ALARM menu. This menu allows you to enable or disable various alarm operations. The following shows the ALARM menu. ALARM CR = MJ...
  • Page 107 Tyco Electronics Galaxy SC Controller J85501F-1 Alarm Cut Off for Major alarm (ACO MJ) enable/disable switch: This field controls the Alarm Cut Off operation for the Major severity level alarms. This field must be enabled for the ACO button field on the MAIN menu to have effect.
  • Page 108 Tyco Electronics Galaxy SC Controller J85501F-1 PLANT V: This setting controls the plant voltage for float and boost modes. Move the cursor to one of the fields and use the <+> or <-> key to adjust the voltage to the desired level. Press <ENTER> to save the change.
  • Page 109 Tyco Electronics Galaxy SC Controller J85501F-1 Slope Thermal This menu selection applies only to controllers used with serial interface Compensation rectifiers, connected with bus wiring through the L-36 Rectifier Menu Interface Module and L-23, BJC3 Rectifier Interface Board. From the CONFIGURATION menu select STC to bring up the SLOPE THERMAL COMPENSATION menu.
  • Page 110 Tyco Electronics Galaxy SC Controller J85501F-1 adjust the temperature to the desired level. Press <ENTER> to save the change. RAISE V: The configuration of this field enables or disables the increase in plant voltage due to decrease in battery temperature. Use the <+>...
  • Page 111 Tyco Electronics Galaxy SC Controller J85501F-1 As soon as any BIC card is connected to a serial rectifier bus, the user relays are released from their use for LVD contactor control and this function is transferred to the LVD control circuits of all BIC cards in the plant.
  • Page 112 Tyco Electronics Galaxy SC Controller J85501F-1 Converter This menu selection applies only to controllers used with serial interface Management converters, presently limited to the +24V to -48V converters used in a Menu 597-series converter carrier. These converters connect to the controller through the rectifier communication bus wiring through the L-36 Rectifier Interface Module and L-23 BJC3 Rectifier Interface Board.
  • Page 113 Tyco Electronics Galaxy SC Controller J85501F-1 and <ENTER> will remove the specified converter from the configuration. Removing a converter will cause all associated alarms generated by that converter to be filtered and ignored by the Galaxy SC. ADJ PL VOLT: This field allows you to calibrate the converter voltage that monitored on a separate VOM.
  • Page 114 Tyco Electronics Galaxy SC Controller J85501F-1 or <-> key to set the field value to FLOODED or SEALED. Press <ENTER> to save the change. Intelligent Note: The section below shows examples of menu screens displayed on Galaxy’s front panel. These displays may differ slightly from Controller version to version of the Galaxy software.
  • Page 115 Tyco Electronics Galaxy SC Controller J85501F-1 Press <ENTER> to continue with the configuration. CONFIGURATION PLANT.. THRESH.. ALARM.. BOOST.. RECT MNGR.. PORT.. BATT MNGR.. LOW V DISC.. CONV MNGR Make sure the cursor is at the PLANT CONFIGURATION.. field. Press <ENTER> to bring up the PLANT menu: PLANT CONFIGURATION DATE..
  • Page 116 Tyco Electronics Galaxy SC Controller J85501F-1 Note that this field must only be configured when the Shunt Type for the plant is LOAD or BATTERY. IF SHUNT TYPE is set to NONE, this field has no function. SHUNT I: To configure the Plant Current shunt, move the cursor to the SHUNT I field by using the <UP>/<DOWN>/<LEFT>/<RIGHT>...
  • Page 117 Tyco Electronics Galaxy SC Controller J85501F-1 Use the <+> or <-> keys to change the field values. Press <ENTER> to save the changes. ADJ PLV: The next field is the ADJ PLV which allows you to calibrate the plant voltage to the desired level. For example, if the Galaxy SC shows a plant voltage reading of 48.26V, and your meter reads 48.30V,...
  • Page 118 Tyco Electronics Galaxy SC Controller J85501F-1 shunt this results in 40 amps/mV. Then multiply this value by the measured mV drop of the load type shunt. RST PLI: The next field is the RST PLI which allows you to reset the display to factory calibration for plant current (using the ADJ PLI field).
  • Page 119 Tyco Electronics Galaxy SC Controller J85501F-1 TIME..: The sub menu to configure time. The TIME menu is on the PLANT menu. From the PLANT menu move the cursor to the TIME.. field and press <ENTER> key to bring up the TIME menu:...
  • Page 120 Tyco Electronics Galaxy SC Controller J85501F-1 High Voltage (HV) threshold: There are two values for this alarm, one for the FLOAT mode, the other for the BOOST/BTP mode. When the plant voltage exceeds this threshold, the plant High Voltage Alarm (HVA) is turned ON, and the rectifier interface will send a signal to the rectifiers to shut down in an orderly and timely fashion.
  • Page 121 Tyco Electronics Galaxy SC Controller J85501F-1 Alarm Menu From the CONFIGURATION menu select ALARM to bring up the ALARM menu. This menu will allow you to enable or disable various alarm operations. (The majority of these configurations are the same as for the basic controller.
  • Page 122 Tyco Electronics Galaxy SC Controller J85501F-1 to set the field value as ENABLE; press <ENTER> key to save the change. Alarm Cut Off for Major alarm (ACO MJ) enable/disable switch: This field controls the Alarm Cut Off operation for the Major severity level alarms.
  • Page 123 Tyco Electronics Galaxy SC Controller J85501F-1 to the RECT DEF item and press <+> or <-> key to choose rectifier number. RECTIFIER 01 TYPE 570A SHNT mV : 50.00 MAN SW : NONE For serialized plants, no changes will be necessary. For parallel interface plants, use the <+>...
  • Page 124 Tyco Electronics Galaxy SC Controller J85501F-1 a software switch associated with it. To set the field value to EN(able), the hardware switch must be set to ON (1 position) and software switch must be enabled; all other positions of the switches will result in a DIS(able) mode.
  • Page 125 Tyco Electronics Galaxy SC Controller J85501F-1 Configure the Efficiency Algorithm (EFFICIENCY): This field lets you Enable or Disable the Efficiency algorithm in the Galaxy SC. If the field is set to Disable, the efficiency algorithm will not be utilized. This field has a hardware switch (SW204-1 on BJH board).
  • Page 126 Tyco Electronics Galaxy SC Controller J85501F-1 Note: this value is based on rectifier output voltage and not measured plant voltage. Move the cursor to one of the fields and use the <+> or <-> key to adjust the voltage to the desired level. Press <ENTER> to save the change.
  • Page 127 BATTERY MANAGEMENT STC.. BAT CNTROL.. BAT DISCH.. Slope Thermal This menu selection applies only to controllers used with Tyco serial Compensation interface rectifiers, connected with serial bus wiring through the L-36 Menu Rectifier Interface Module and L-23, BJC3 Rectifier Interface Board.
  • Page 128 Tyco Electronics Galaxy SC Controller J85501F-1 STC: The configuration of this field enables or disables Slope Thermal Compensation feature. Use the <+> or <-> key to toggle between enable or disable. Press <ENTER> to save the change. LOW TEMP: The configuration of this field sets the temperature at which the plant voltage will have raised 0.1 volts x the number of cells.
  • Page 129 Tyco Electronics Galaxy SC Controller J85501F-1 BATTERY CONTROL STEP RCHG CURLIM RCL THRESH 1000A TEMP DISCON TEMP UNITS STEP: The configuration of this field sets the increment of current change for the for the RCL THRESH field, in increments of 1, 10, 50 and 100 amperes.
  • Page 130 Tyco Electronics Galaxy SC Controller J85501F-1 BATTERY DISCHARGE TEST BAT TEST: ENHANCED: EN BAT TYPE: CELL/STRNG: 24 NUM STRNG: 2 END V/CELL: 1.75 BAT CLASS: SEALED BAT TEST: This field enables or disables the Battery Discharge Test feature. If enabled here, the test can be initiated on the front display, MENU →...
  • Page 131 Tyco Electronics Galaxy SC Controller J85501F-1 END V/CELL: Used for the ENHANCED battery test only. Allows minimum voltage for the discharge prediction to be specified for the Reserve Time Prediction Algorithm. Move the cursor to this field and use the <+> or <-> key to set the field value to the desired end voltage.
  • Page 132 Tyco Electronics Galaxy SC Controller J85501F-1 The four possible values are: RD(HW), RD(HW,SW), RD(SW), RD_WR. The first three values are read-only permission, which means users can login through the modem and retrieve information. The fourth value (RD_WR) allow users who login through the modem to change the system configuration (Super-user or Administrator privileges).
  • Page 133 Tyco Electronics Galaxy SC Controller J85501F-1 function is transferred to the LVD control circuits of all BIC cards in the plant. Please note that in a standard GPS configuration using BIC cards, Contactor 1 is wired to and controls all BATTERY contactors in the plant, while Contactor 2 and Contactor 3 are wired to and control only LOAD contactors.
  • Page 134 Tyco Electronics Galaxy SC Controller J85501F-1 Converter This menu selection applies only to controllers used with serial interface Management converters, presently limited to the +24V to -48V converters used in a Menu 597-series converter carrier. These converters connect to the controller through the rectifier communication bus wiring through the L-36 Rectifier Interface Module and L-23, BJC3 Rectifier Interface Board.
  • Page 135 Tyco Electronics Galaxy SC Controller J85501F-1 RMOVE CONV: May be used to remove a converter from the configuration. The converter number is selected using <+> and <-> keys and <ENTER> will remove the specified converter from the configuration. Removing a converter will cause all associated alarms generated by that converter to be filtered and ignored by the Galaxy SC.

  • Page 136: Figure 4-1: Easyview Main Screen

    Tyco Electronics Galaxy SC Controller J85501F-1 EasyView File Connect Configure Control Status Reports Options Help Site Description Office 1 DC1 HFV 01/01/1994 01:04AM High Float Voltage PS1 PFD 01/01/1996 01:04AM Password At Default DC1 SNC 01/01/1996 01:04AM Shunt Not Configured BDFB 1 Load Current 118.00 A...

  • Page 137: Figure 4-2: Easyview Configure Menu

    Tyco Electronics Galaxy SC Controller J85501F-1 EasyView File Connect Configure Control Status Reports Options Help Alarm Cut-off (ACO) Alarms Site Description Alarm Test Office 1 Battery Management Boost Call-Back Security DC1 HFV 01/01/1994 01:04AM High Float V oltage Call-Out Change Passwords...
  • Page 138 Configure → Alarms → Standard example. Many customers will want to leave the USER (read-only) password at LINEAGE to allow universal read access to the controller, but Tyco Electronics strongly suggests that both the SUPER-USER and the ADMINISTRATOR passwords be changed by the customer after initial configuration is complete.
  • Page 139 Tyco Electronics Galaxy SC Controller J85501F-1 Configure → Alarm Cut-Off (ACO). Controls which relays are Alarm Cut-Off Feature allowed to be turned off by ACO, providing a time-out feature not configurable from the front panel. See Chapter 7 for additional information.
  • Page 140 Tyco Electronics Galaxy SC Controller J85501F-1 Nag On Occur: Enables or Disables the Nag feature which will consistently re-call the destination numbers if the alarm persists. Notify Delay: Provides a delay time of 0 to 540 seconds before calling out. If the alarm retires prior to the delay period ending, no call is made.
  • Page 141 Tyco Electronics Galaxy SC Controller J85501F-1 Configure → Alarms → User Defined. There are no User Defined User Defined Alarms alarms pre configured in the system. The user must first add a “User Event” (U0001 to U1500), and then modify it. The alarms are most often associated with setting a threshold for a Remote Peripheral Monitor channel, but may be used with system alarm events as well.
  • Page 142 Tyco Electronics Galaxy SC Controller J85501F-1 Configure → Alarms Test. Individually configures each of the Alarm Test controllers alarm relays for operation during an alarm test. Alarm Test and Remote Alarm Test are enabled in software at Configure → DC Plt →...
  • Page 143 Tyco Electronics Galaxy SC Controller J85501F-1 TYPE: This setting identifies the type of contactor, BAT, LOAD or NONE that has been installed in the plant. Please be sure that the wiring for the contactor being configured matches the type chosen here. For...
  • Page 144 Battery Test. This featured can be enabled if Tyco batteries, as outlined in Section 7, are installed. Additional parameters necessary for Enhanced Prediction are located on the DC Plant →...
  • Page 145 Prediction for the specific battery section. If not linked in the section, plant voltage will be used. Slope Thermal This menu selection applies only to controllers used with Tyco serial Compensation interface rectifiers, connected with serial bus wiring through the L-36 Rectifier Interface Module and L-23, BJC3 Rectifier Interface Board.
  • Page 146 4.08 volts (24 x 0.17 = 4.08). Configure → Boost: The Boost (increase plant voltage) or BTP Boost (decrease plant voltage) parameters are configured here. Tyco Electronics rectifiers which presently accept boost/BTP signals include J85502C1 (125A), J85503B2 (200A), J85503C2/3 (400A), J85603C2 (400A), J85702E1 (SR150A), SR50, and SR100 plus all serial interface rectifiers.
  • Page 147 Tyco Electronics Galaxy SC Controller J85501F-1 Current Term Vltg Thrhld: Sets the voltage trigger/switch used as a qualifier for QRCT Boost entrance. Current Term Current Thrld: Sets the total current value flowing into or out of the battery as a qualifier for the controller to activate QRCT Boost.
  • Page 148 Tyco Electronics Galaxy SC Controller J85501F-1 Configure → Call-out → Periodic Status Call-Out. Configures the Call-Out Periodic Call Out destination phone number and data parameters, baud rate etc., for having the controller call out to deliver the system status, histories and statistics.
  • Page 149 HV Shutdown Dur Alarm Test: Enables or disables the software switch for the feature that will fail the rectifiers during an alarm test. Do not enable this feature with Tyco serial rectifiers. The associated hardware switch is SW202-4 on the BJB pack.
  • Page 150 Tyco Electronics Galaxy SC Controller J85501F-1 Battery Type: Select from a list of Tyco or Exide battery types. Type selected is used in the Battery Reserve Time Prediction feature. Inst Cells per String: Number of cells in the battery string is used in the Slope Thermal Compensation feature.
  • Page 151 Tyco Electronics Galaxy SC Controller J85501F-1 PH1-2, PH2-3, PH3-1 Voltage: Voltage RPM channels, (transducers required) can be linked to monitor the phase to phase ac voltages. PH1, PH2, PH3 Fail: Binary RPM channels, can be linked to monitor the status of an external ac fail alarm device monitoring individual phases.
  • Page 152 Tyco Electronics Galaxy SC Controller J85501F-1 Configure → Inventory → Reserve. (Customer configured option.) Reserve Inventory Configure → Port Communication → Aux / Local / Modem. Communication Ports (Customer configured option.) Configure → Rectifier → Rectifier Bays. There are no Rectifier Bays Rectifier Bays configured in the system.
  • Page 153 “G400” with 40mV representing the rated 400A capacity of the rectifier. Rectifier Manager This menu selection applies only to controllers used with Tyco serial interface rectifiers, connected with serial bus wiring through the L-36 Rectifier Interface Module and L-23, BJC3 Rectifier Interface Board.
  • Page 154 Tyco Electronics Galaxy SC Controller J85501F-1 their rated value should the other rectifiers in the plant be adjusted to an output voltage that is below that set for the serial rectifiers in the Float Set Point field. Boost Current Limit: Sets the rectifier’s current limit value as a percentage of rectifier capacity while the system is in the Boost mode.
  • Page 155 Tyco Electronics Galaxy SC Controller J85501F-1 modem port. The Hardware switch associated with this feature is SW203-3 on the BJH pack. Remote Rect On: Sets the software switches for permission to remotely turn individual rectifiers On that are being held in Standby by the controller.
  • Page 156 Tyco Electronics Galaxy SC Controller J85501F-1 Configure → Timer Events. There are no Timer Events configured in Timer Events the system. Users can add Timer events (statements that become “true” or active at specific times) that can be used in conjunction with Control Relays in Peripheral Monitoring.
  • Page 157 Tyco Electronics Galaxy SC Controller J85501F-1 Aux Port The Aux port, located on terminal blocks TB4 and TB5 of the Front Access Board, may also be used for RS-232 direct access from a “dumb” terminal by wiring the transmit and receive leads to TB1 as indicated in Figure 3-7.
  • Page 159 Tyco Electronics Galaxy SC Controller J85501F-1 Acceptance Testing Introduction The Galaxy SC Controller is tested before it leaves the factory, but many users wish to add some test procedures as part of installation and turn-up. The tests described here will simulate various alarm conditions and verify that the controller functions properly as installed.
  • Page 160 Tyco Electronics Galaxy SC Controller J85501F-1 Alarm Test Alarm Test provides means of testing the operation of all or any of the plant alarm relays and their wiring to the connected alarm system. It cannot be done if any alarms are active. It may also be desirable to perform this test occasionally after the plant is in service to verify the integrity of the office alarm system for the power plant alarms.
  • Page 161 Tyco Electronics Galaxy SC Controller J85501F-1 Very Low Voltage - UR3 (VLV)** High Voltage - HV Controller - CTLR User Relay 1 - UR1** User Relay 2 - UR2** *RFAT is an alarm test intended for use with non-serial type rectifiers, connected to the "Enhanced Ferro"...
  • Page 162 Tyco Electronics Galaxy SC Controller J85501F-1 (Intelligent controllers) from the Configuration screen. Use the <ADJUST> keys to change the value of the plant voltage to a level above the HFV setting noted above but below the HV setting. Press ENTER to save the change.
  • Page 163 Tyco Electronics Galaxy SC Controller J85501F-1 2. The rectifier must be delivering a current exceeding 10% of its capacity. 3. The rectifier’s current output must be unbalanced by more than 10% from the average output currents of the other rectifiers.
  • Page 164 Tyco Electronics Galaxy SC Controller J85501F-1 • When the voltage increases to the HV (FLOAT) level the rectifier shuts down. • The Green ON LED on the rectifier blinks, the ALM LED on the rectifier is not lit. • After 5-6 seconds the rectifier initiates its own restart signal again, raising the plant voltage.
  • Page 165 Tyco Electronics Galaxy SC Controller J85501F-1 High Voltage HV tests can be completed by either raising the plant voltage above the thresholds set for HFV (High Float Voltage) and HV (High Voltage Shut Alarm/High Down) or by changing the thresholds for these conditions to make them Voltage active.
  • Page 166 Tyco Electronics Galaxy SC Controller J85501F-1 Note: Using this restart method rather than just toggling the rectifier on/off switch tests the restart circuitry and resets the HVSD timer so that the next rectifier can be tested immediately. 5. After the test rectifier restarts and walks in, adjust its output to the plant float voltage and verify that all controller alarms have retired.
  • Page 167 Tyco Electronics Galaxy SC Controller J85501F-1 Batteryless Plant 1. Turn off all but two rectifiers operating their power switches to HVSD Test (Serial STDBY. In one of the rectifiers unplug its serial cable link to the Rectifiers) controller. In some rectifiers, the air flow shield above the rectifier may need to be removed to access this plug.
  • Page 168 Tyco Electronics Galaxy SC Controller J85501F-1 • Upon the fourth shutdown, the rectifier’s ALM LED lights and the rectifier’s display indicates “HO.” • Any external RFA and BD office alarms have occurred. 6. The controller will wait 5-6 minutes and issue one final restart signal initiating the final sequence of shutdown and restart events before the rectifier locks out, requiring personnel intervention.
  • Page 169 SW100-5) anytime that rectifier voltage is adjusted in these rectifiers with the PMA Output CBs closed. In a similar manner, for Tyco Electronics 50A SMR-series rectifiers, a RFA may be generated by setting the Output CB switch of the rectifier...
  • Page 170 Tyco Electronics Galaxy SC Controller J85501F-1 Load share should be disabled (BGB1 SW100-5) anytime that rectifier voltage is adjusted in these rectifiers with the Output CBs closed. If an Intelligent controller is being tested, History for all tested alarms can be reviewed under the front panel path: Main → History.
  • Page 171 Tyco Electronics Galaxy SC Controller J85501F-1 also verify that this LED activates during these tests for the bay in which the alarm originates (and not in any other). For GPS cabinets, the alarm lamp of the cabinet containing the controller will always activate, in addition to the cabinet containing the alarm.
  • Page 172 Energy Management is enabled only if all connected rectifiers provide a load signal to Galaxy SC via the VI (Voltage proportional to output current) circuit within each Tyco J855-series or J874-series rectifier control circuitry. Controllers using the BJC2 rectifier interface packs, used with rectifiers that do not issue VI signals, instead monitor the mV signal directly off the rectifier load shunt.
  • Page 173 Tyco Electronics Galaxy SC Controller J85501F-1 <MENU> key, wait five seconds, and go back to the Config → DC Plt screen. Move to ADJ PLV on the menu and use the <ADJUST> keys to calibrate the plant voltage to match the reading of the DVM. Press <ENTER>...
  • Page 175 Tyco Electronics Galaxy SC Controller J85501F-1 Operation Introduction This section tells you in detail how to operate the Galaxy SC Controller. Topics include operation of both the Basic and Intelligent controllers from Galaxy SC’s front panel, operating Galaxy SC from a personal computer with the Windows-based EasyView software, and using the T1.317 interface from a remote terminal.
  • Page 176 Tyco Electronics Galaxy SC Controller J85501F-1 alarms. If new alarms of the same severity level occur, the associated contact relay will be engaged again; to cut these new alarms off, do the ACO operation again. Change Plant To switch the plant mode between FLOAT and BOOST, first bring the Mode MAIN menu up (press <MENU>...
  • Page 177 Tyco Electronics Galaxy SC Controller J85501F-1 screen of data. Press <ESC> key to return to the parent menu which is MAIN menu in this case. Performing To perform the rectifier restart from the front panel, press <MENU> key Rectifier Restart to bring up the MAIN menu, move the cursor to the MAINT OPER field, press <ENTER>, then move to the RECT RST field and press...
  • Page 178 Tyco Electronics Galaxy SC Controller J85501F-1 Change Plant To make adjustment to the plant voltage, first press the <MENU> key Voltage (Serial Bus to bring up the MAIN menu; move the cursor to the CONFIG field; Rectifiers Only) press <ENTER> to bring up the Configuration menu; move the cursor to RECT MNGR to bring up the Rectifier Management menu;...
  • Page 179 Tyco Electronics Galaxy SC Controller J85501F-1 <ENTER> again to perform the rectifier restart. The screen will display “REQUEST RECTIFIER RESTART.” Remove Rectifier Serial Rectifiers are automatically recognized by the system when Configuration plugged in and the ID number is configured at the rectifier. The system...
  • Page 180 Tyco Electronics Galaxy SC Controller J85501F-1 Move the cursor to the field for which you want to view the history and press the <ENTER> key to display data. If there is more than one screen of data (eight lines of text), use the <UP>, <DOWN> arrow key to display additional screens.
  • Page 181 Tyco Electronics Galaxy SC Controller J85501F-1 Move the cursor to the field that denotes the statistics to be viewed and press the <ENTER> key to display data. If there is more than one screen of data (eight lines of text), use the UP, DOWN arrow key to display additional screens.
  • Page 182 Tyco Electronics Galaxy SC Controller J85501F-1 menu; move the cursor to the VIEW NOTEPAD field; and press <ENTER> to bring up the Notepad menu. Then select the notepad to display. Clearing Statistics To access the CLEAR STATISTICS menu, press the <MENU> key to bring up the MAIN menu;...
  • Page 183 Tyco Electronics Galaxy SC Controller J85501F-1 Selecting UDO displays the values of any user-defined objects that have been optionally added to the system. Select the CONVERTER field to display the type, state, load and capacity of all converters in the system, in addition to the total converter drain (SUMMARY) and capacity.
  • Page 184 Tyco Electronics Galaxy SC Controller J85501F-1 Diagnostics You can view some diagnostic messages from the front panel. Press the MENU key to bring up the MAIN menu, move the cursor to DIAG field, press ENTER key to bring up the DIAG menu:...
  • Page 185 Tyco Electronics Galaxy SC Controller J85501F-1 The backup and restore feature allows the user to back up the system configuration to disk, in a series of T1.317 commands in the ASCII format. The user may edit the file and before restoring it.
  • Page 186 Tyco Electronics Galaxy SC Controller J85501F-1 EasyView path: Status → Alarm Test. Information on the success or Display Alarm Test failure of the last Alarm Test that was performed is provided. EasyView path: Status → Battery Sections. Displays the present values...
  • Page 187 Tyco Electronics Galaxy SC Controller J85501F-1 Manager / Log In / Periodic Status Call Out / Plant / Rectifiers / System / User Defined. Measurements Plant voltage and load values are constantly displayed and updated on the status bar at the bottom of the EasyView Main Menu. Rectifier current measurements are obtained through the path: Main →...
  • Page 188 Tyco Electronics Galaxy SC Controller J85501F-1 T1.317 Terminal Mode commands for performing the common access and control functions within Galaxy SC without the benefit of the EasyView Interface interface are provided in the following section. Please refer to Common Appendices A and B for a complete description of this interface Access and language if you employ this means of communicating with Galaxy SC.
  • Page 189 Tyco Electronics Galaxy SC Controller J85501F-1 CHA AT1, LTE=1 enable the alarm test enable software DIP switch CHA AT1,DUR=30 set the contact duration to 30 seconds CHA AT1,PCR=1 enable the power critical relay test Other attributes can be configured by replacing the attribute identifiers in the examples above with the proper attribute identifier.
  • Page 190 Tyco Electronics Galaxy SC Controller J85501F-1 configuring the attributes of each alarm object if necessary. These attributes and their range of values are described in detail in the T1.317 object tables in Appendix B of this manual. Listed below are examples...
  • Page 191 Tyco Electronics Galaxy SC Controller J85501F-1 Viewing Active The T1.317 interface allows 3 commands that allow viewing of active Alarms alarms. Which command is used depends on the programmed severity of the alarm. If the severity is record-only the REC command is used to retrieve the active alarms referred to as record-only events.
  • Page 192 Tyco Electronics Galaxy SC Controller J85501F-1 configuration depends on the remote peripheral monitors available in the system. For help in creating user defined events please see the section entitled “T1.317 User-Defined Event Management” in this manual. LIN B01 VDC,C101 link remote monitor C101 to the DC...
  • Page 193 Tyco Electronics Galaxy SC Controller J85501F-1 The T1.317 interface also allows the user to configure the battery slope thermal compensation feature. The follow commands demonstrate how to do this: CHA SC1,STT=1 Change the slope thermal compensation state to enabled CHA SC1,RVE=0...
  • Page 194 Tyco Electronics Galaxy SC Controller J85501F-1 contactor 1 or contactor 2 and to set the battery high temperature disconnect threshold. Clearing Active Some alarms are latched, meaning that once they occur they must be Alarms cleared manually. These alarms can be cleared individually using the CLE command.
  • Page 195 Tyco Electronics Galaxy SC Controller J85501F-1 1. Login as a super-user. 2. Enter the RESTORE command. 3. Select either Xmodem or ASCII transfer. 4. Start your terminal upload program. The restore session will terminate automatically with a message indicating that the configuration restore completed or not. The file being restored should be the one created during a configuration backup or one of a similar format.
  • Page 196 Tyco Electronics Galaxy SC Controller J85501F-1 configured to call-out. This section describes the steps to take to do this and gives examples using the T1.317 interface. Call-Out Phone From the T1.317 interface the call-out phone numbers can be viewed Number and configured.
  • Page 197 Tyco Electronics Galaxy SC Controller J85501F-1 The following example illustrates how to configure the connected equipment ID: CHA DS1,CID=“MCS” This command identifies the connected equipment on data switch port 1 (DS1) as an MCS controller. For the other data switch ports substitute DS2, DS3, or DS4 for DS1.
  • Page 198 Tyco Electronics Galaxy SC Controller J85501F-1 DC Distribution The T1.317 interface allows the user to configure the DC Distribution Management object so that DC Distribution parameters may be viewed from either the T1.317 interface or the front panel. Configuration involves configuring a user-defined event to become active when a DC distribution fuse is open and then linking that event to the DC Distribution object.
  • Page 199 Tyco Electronics Galaxy SC Controller J85501F-1 DC plant measurement. This can be done by linking DR01 to the DC plant. The example below illustrates how this is done: ADD DC1,ARLOAD add a linkable attribute called ARLOAD to the DC plant...
  • Page 200 Tyco Electronics Galaxy SC Controller J85501F-1 report all alarm history HIS DC1 report plant alarm history HIS PS1 report system alarm history HIS PS1 EXL report excessive logins system alarm history HIS DC1,G=1 report plant alarm history grouped by alarm...
  • Page 201 Tyco Electronics Galaxy SC Controller J85501F-1 HIS DC1,BOD CLH DC1,BOD Each line of the history report has the following format: date,time,load,duration,reserve_time Boost State History The boost state history can be viewed and cleared from the T1.317 Management interface. The following examples illustrate how to view and clear the...
  • Page 202 Tyco Electronics Galaxy SC Controller J85501F-1 ADD DBI,DI1 add distribution bay inventory 1 to the system ADD DI1,PIN add a linkable attribute called PIN to the bay inventory ADD PIN,PI01 add panel inventory called PI01 LIN DI1 PIN,PI01 link the panel inventory to the bay...
  • Page 203 Tyco Electronics Galaxy SC Controller J85501F-1 the warning description. To configure other maintenance reminders, replace MR01 with the proper identifier and change the date, time, and text accordingly. Warnings can also be configured to call out. See the object tables in Appendix B for a complete list of maintenance reminder mnemonics including those programmed for call out.
  • Page 204 Tyco Electronics Galaxy SC Controller J85501F-1 Periodic Status From the T1.317 interface the periodic status object, identified as PO1, Call-Out can be viewed and configured. See the T1.317 object tables in Appendix Configuration B for attribute mnemonics and other details. The following example illustrates how to configure periodic status call out: CHA PO1,PHN=“222-3333”...
  • Page 205 Tyco Electronics Galaxy SC Controller J85501F-1 To clear the rectifier state history, issue the following command: CLH REC,STT To review the incidents of rectifier and plant alarms, issue the following command: HIS DC1 To clear the rectifier and plant alarm history, issue the following...
  • Page 206 Tyco Electronics Galaxy SC Controller J85501F-1 The following commands are examples that illustrate how to configure the float mode thresholds for serial interface rectifiers and enables load sharing: CHA GM1,LSE=1 enable digital sharing state to enable CHA GM1,FSD=60 change the high voltage shutdown threshold to 60 V CHA GM1,FSP=52.08...
  • Page 207 Tyco Electronics Galaxy SC Controller J85501F-1 to use the channel type specifier with the LIS (list) command as in the examples below: LIS VTM list the voltage monitor channels LIS TPM list the temperature monitor channels The STA (status) command can also be used with the channel or module...
  • Page 208 Tyco Electronics Galaxy SC Controller J85501F-1 MET G01 MET G01,LOAD Reserve Time This section describes how to configure and view the parameters that are Prediction related to the reserve time prediction algorithm. The reserve time parameters are all attributes of the DC Plant object identified as DC1.
  • Page 209 Tyco Electronics Galaxy SC Controller J85501F-1 To force a login as a super-user or administrator precede the password with an exclamation mark (!). The current security level is reflected by the command prompt as follows: user security level super-user security level administrator security level To change a password requires the administrator security level.
  • Page 210 Tyco Electronics Galaxy SC Controller J85501F-1 enabled. Call-back security is disabled by default and the baudrates are set to 2400 by default. The examples below illustrate how to configure call-back security: CHA CB1,PH1=“123-4567” set the phone number for location 1 to 123-4567...
  • Page 211 Tyco Electronics Galaxy SC Controller J85501F-1 change the local port application to event logging STA LP1,APP check the status of the application attribute STA LP1,STT see if anyone is logged in to the local port When viewing the application attribute of the local port the application will be indicated as well as the reason for that application.
  • Page 212 Tyco Electronics Galaxy SC Controller J85501F-1 After the software upload has completed successfully the Galaxy SC will begin reprogramming the EEPROM chips. Once reprogramming is completed the user is disconnected and the Galaxy SC re-boots using the new software. Statistics Usage...
  • Page 213 Tyco Electronics Galaxy SC Controller J85501F-1 ADD TME,T01 add timer event 1 CHA T01,DAT=05/20/95 change the event date to 5/20/95 CHA T01,TIM=1:30am change the time to 1:30am CHA T01,DUR=60 change the duration to 60 minutes To add and configure other timer events replace T01 for the other timer event’s identifier.
  • Page 214 Tyco Electronics Galaxy SC Controller J85501F-1 ADD DC1,VDCHI add a linkable attribute called VDCHI to the DC plant LIN DC1 VDCHI,U0001 link U0001 to VDCHI on the DC plant The commands above will cause the active user-defined event U0001 to be reported as DC1 VDCHI.
  • Page 215 Part 2 Galaxy SC Controller J85501F-1 Product Manual Select Code 167-790-060 Comcode 107330946 Issue 13 February 2001...
  • Page 217 Every effort was made to ensure that the information in this document was complete and accurate at the time of printing. However, information is subject to change. © 2001 Tyco Electronics Corporation, Harrisburg, PA. All Rights Reserved Printed in U.S.A.
  • Page 219 2 - 2 Intelligent Controller 2 - 2 Backplane 2 - 3 Circuit Packs Used in the Galaxy SC Controller 2 - 4 BJA1 or BJA2 (Basic Controller Power Board) 2 - 4 BJB1 (Basic Controller Digital Board) 2 - 4...
  • Page 220 Tyco Electronics Galaxy SC Controller J85501F-1 Display Language 2 - 8 Display Conventions 2 - 9 Default Display 2 - 9 Menu Organization 2 - 10 Menu Operations 2 - 12 3 Installation Overview 3 - 1 Precautions 3 - 1...
  • Page 221 Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy SC Configuration 3 - 35 Rectifier VI Circuit Adjustment 3 - 35 Galaxy Option Features 3 - 36 Intelligent Controller (J85501F1 L- AB or AC) 3 - 36 Modem (J85501F1 L-AE) 3 - 38...
  • Page 222 Tyco Electronics Galaxy SC Controller J85501F-1 Battery Control Menu 4 - 36 Battery Discharge Test Menu 4 - 37 Communication Ports (PORT) Menu 4 - 39 Low Voltage Disconnect Menu 4 - 40 Converter Management Menu 4 - 42 EasyView Software Communication Mode...
  • Page 223 Tyco Electronics Galaxy SC Controller J85501F-1 System Time 4 - 63 Timer Events 4 - 64 Configuration From a Remote Terminal 4 - 64 T1.317 Command Language 4 - 64 Connecting a Terminal to Galaxy SC 4 - 64 5 Acceptance Testing...
  • Page 224 Tyco Electronics Galaxy SC Controller J85501F-1 Change Plant Voltage (Serial Bus Rectifiers Only) 6 - 2 Clear Latched Events 6 - 2 Display Alarm Data 6 - 2 Display Warning Data 6 - 2 Performing Rectifier Restart 6 - 3...
  • Page 225 Tyco Electronics Galaxy SC Controller J85501F-1 Rectifier Removal (Serial Bus Rectifiers Only) 6 - 13 Rectifier Restart 6 - 13 Statistics 6 - 13 T1.317 Interface Common Access and Control Functions 6 - 14 AC Distribution Management 6 - 14...
  • Page 226 Tyco Electronics Galaxy SC Controller J85501F-1 Statistics Usage 6 - 38 Timer Events Management 6 - 38 User-Defined Event Management 6 - 39 7 Feature Descriptions AC Distribution 7 - 2 Alarm Cut-Off (ACO) 7 - 2 Parameters 7 - 3...

  • Page 227: Effect Of Changing Date And Time

    Tyco Electronics Galaxy SC Controller J85501F-1 Low Voltage Load Disconnect (LVLD) 7 - 28 Low Voltage Battery Disconnect (LVBD) 7 - 29 Maintenance Reminder 7 - 31 Notepad 7 - 31 Periodic Status Call-Out 7 - 31 Rectifier Bays 7 - 32...

  • Page 228: Effect Of Changing Scale Factor, Range Or Channel Type

    Tyco Electronics Galaxy SC Controller J85501F-1 Effect of Changing Scale Factor, Range or Channel Type 7 - 56 Timer Events 7 - 56 Terminal Menu Interface 7 - 57 User Defined Events 7 - 57 Legal Operators for UDEs 7 - 58...
  • Page 229 Tyco Electronics Galaxy SC Controller J85501F-1 Reporting Commands A - 10 System Defined Aliases A - 14 Error Reporting A - 15 Appendix B T1.317 Objects and Attributes Appendix C T1.317 Error Messages Error Messages and Causes C - 1...
  • Page 230 Tyco Electronics Galaxy SC Controller J85501F-1 Commands from OSs D - 19 Autonomous Commands From Galaxy (NE) to OS D - 25 Bellcore Reference Documents D - 26 Appendix E Terminal Menu Interface Login E - 1 Menus E - 2...
  • Page 231 Tyco Electronics Galaxy SC Controller J85501F-1 List of Figures Figure 1-1: Galaxy SC Controller 1 - 1 Figure 2-1: Galaxy SC Controller With Door Open (Basic Circuit Packs At Right of Cabinet, Intelligent Circuit Packs At Left) 2 - 2...

  • Page 232: Figure D-4: Pad And Dsu Mounting Shelf D

    Tyco Electronics Galaxy SC Controller J85501F-1 Figure 3-13: Connections from Galaxy Local Port to PC/Printer (top) and PAD/DSU (bottom) 3 - 45 Figure 3-14: Connecting Remote Peripheral Interface Bus Wiring to Galaxy SC Controller 3 - 47 Figure 3-15: Wiring for Rectifier Sequencing (TFLT=Tell to Float;...

  • Page 233: Table 7-A: Remote Security Via Modem And Auxiliary Ports

    Tyco Electronics Galaxy SC Controller J85501F-1 List of Tables Table 3-A: Standard Galaxy SC Controller Circuit Packs 3 - 6 Table 3-B: Galaxy SC High Voltage Shutdown Setting -48V 3 - 8 Table 3-C: BJA High Voltage Shutdown Setting +/-24V...

  • Page 234: Table B-7: Rectifiers Objects And Attributes B

    Tyco Electronics Galaxy SC Controller J85501F-1 Table B-7: Rectifiers Objects and Attributes B - 9 Table B-8: Converter Management Objects and Attributes B - 10 Table B-9: Battery Management Objects and Attributes B - 11 Table B-10: Alarm And Events Objects and Attribute...

  • Page 235: Feature Descriptions

    Tyco Electronics Galaxy SC Controller J85501F-1 Feature Descriptions Overview This section contains detailed descriptions of the Galaxy SC Controller’s features. They appear in alphabetical order: AC Distribution Alarm Cut Off (ACO) Alarm test Backup and Restore Battery Discharge Test Battery Section...

  • Page 236: Ac Distribution

    Tyco Electronics Galaxy SC Controller J85501F-1 AC Distribution The Galaxy SC supports monitoring of several AC distribution parameters. The AC distribution feature may be configured through the T1.317 interface using Easy View and viewed from the T1.317 interface or front panel.
  • Page 237 Tyco Electronics Galaxy SC Controller J85501F-1 Every ACO activation and deactivation is logged in the system event log. Parameters The ACO feature parameters may be set via the T1.317 interface or the front panel. Power Critical enabled enabled/disabled for Power Critical Alarms...

  • Page 238: Parameters

    Tyco Electronics Galaxy SC Controller J85501F-1 Power Major, or Power Minor alarm other than RFA or HV (which may be generated by the alarm test feature) aborts the alarm test. Next, the user selectable list of alarm contacts is sequentially activated.

  • Page 239: Alarm Test

    Tyco Electronics Galaxy SC Controller J85501F-1 The following alarm test features may be configured or viewed only via the T1.317 interface: Description Description (default: Alarm Test n) State Active alarm test state (1 = active; 0 = inactive) Rectifier failure list List of rectifiers that have failed alarm test Remote alarm test enabledAllow T1.317 initiated alarm test...

  • Page 240: Backup And Restore

    Tyco Electronics Galaxy SC Controller J85501F-1 Backup and The backup and restore feature allows the user to backup the system configuration as a series of T1.317 commands in an ASCII format. The Restore ASCII format allows the user the flexibility to view and edit the configuration before restoring it.
  • Page 241 Tyco Electronics Galaxy SC Controller J85501F-1 • 100 minutes elapses and 20 percent capacity has not been removed. • Battery voltage declines to the highest of the following computed values: – 2A. (1.75 x No. of cells) + 1.2 [48V] or + .6 [24V] –...

  • Page 242: Battery Sections

    Tyco Electronics Galaxy SC Controller J85501F-1 be configured. Please refer to “Universal Reserve Time Prediction” later in this chapter. Configuration may be done locally at the front panel or remotely via EasyView interface. Basic: MENU → CONFIG.. → BAT TEST Intelligent: MENU →...
  • Page 243 Tyco Electronics Galaxy SC Controller J85501F-1 capacity Maximum capacity of battery section in Ampere Hours. This is based on the number of strings in the section and the name-plate capacity of the battery type selected. This calculated item is for information purposes only.

  • Page 244: Boost

    Tyco Electronics Galaxy SC Controller J85501F-1 would eliminate the need for two monitoring points, and the need to configure this item. This item and the discharge current link are used as the basis for the battery section current discharge current A built-in link point for the battery section discharge current.
  • Page 245 Tyco Electronics Galaxy SC Controller J85501F-1 voltage boost, or Battery Thermal Protection (BTP) may be used to prevent thermal runaway on valve regulated lead acid batteries. Circuitry external to the controller is necessary to provide this feature. Because the plant voltage is increased or decreased during boost (or BTP) modes, the Galaxy SC also provides two voltage thresholds for the float and boost modes.
  • Page 246 Tyco Electronics Galaxy SC Controller J85501F-1 Note: For timed manual boost, the method of entering boost from the EasyView software, the boost (or BTP) mode is initially disabled by RFA, HFV, and HV alarms. The only method of entering boost (or BTP) while these alarms are active is to enter boost via the front panel.

  • Page 247: Boost Modes

    Tyco Electronics Galaxy SC Controller J85501F-1 QRCT mode and Battery Thermal Protection Boost are incompatible, thus when BTP is enabled, QRCT is disabled. There is a software and hardware DIP switch for the boost (or BTP) modes that will disable all forms of entry into boost (or BTP) mode.

  • Page 248: Boost Parameters

    Tyco Electronics Galaxy SC Controller J85501F-1 FEATURE Boost BTP feature was disabled while active Boost Parameters The boost (or BTP) feature parameters may be set via the T1.317 interface or the front panel. Boost Enabled Parameter enabling and disabling any form of boost or BTP entry.

  • Page 249: Call-Out

    Tyco Electronics Galaxy SC Controller J85501F-1 To return to float mode, use the following command: OPE DCP,STT=FLOAT To view the boost or BTP history, issue the following command: HIS BST To clear the boost or BTP history, issue the following command:...
  • Page 250 Tyco Electronics Galaxy SC Controller J85501F-1 Notes On Calling-out To Pagers When the phone number type is configured as a pager number, any alarm may be configured to call-out to the pager number when the alarm occurs and/or retires. When the alarm call-out condition occurs, the Gal- axy SC will dial the configured phone number and wait 30 seconds for 10 consecutive seconds of silence.

  • Page 251: Alarms Generated By Call-Out

    Tyco Electronics Galaxy SC Controller J85501F-1 provided). If A1 is reached and the alarm has been reported, Galaxy SC will not call the primary number again. However, if the system cannot reach A1 or if A1 is not provided, the system will wait 12 minutes before it tries to call the first primary number again.

  • Page 252: Controller Failure

    Tyco Electronics Galaxy SC Controller J85501F-1 Controller The Galaxy SC has three distinct levels that allow isolated failures to reduce but not eliminate control and monitoring of the battery plant. The Failure three levels are the independent controller, the intelligent controller and the analog backup selective high voltage circuitry.

  • Page 253: Data Switch Configuration Parameters

    Tyco Electronics Galaxy SC Controller J85501F-1 In pass-through mode data is passed between a Galaxy SC access port and the assigned data switch port as if there were a direct link from the access port to the connected equipment. While in pass-through mode the Galaxy SC monitors the data stream for the RBYE command.

  • Page 254: Defaults

    Tyco Electronics Galaxy SC Controller J85501F-1 handshake None, hardware, or software (default: none) attention prompt A command string that will get the attention of the connected equipment. This is usually some newline character sequence. Up to 12 characters are supported.

  • Page 255: Data Switch Alarm Configuration Parameters

    Tyco Electronics Galaxy SC Controller J85501F-1 Data Switch Alarm In addition to the configuration parameters listed above, each data Configuration switch port has a connected equipment alarm associated with it with the Parameters following parameters: identifier CEA1 for data switch port 1...

  • Page 256: Dc Distribution

    Tyco Electronics Galaxy SC Controller J85501F-1 Alarm Reporting All of the configurable parameters for both the data switch port and Mode alarm should be configured be fore entering alarm reporting mode. After entering alarm reporting mode the Galaxy SC does the following: •...

  • Page 257: Derived Channels

    Tyco Electronics Galaxy SC Controller J85501F-1 Derived The Derived Channels feature is provided to group together a number of system measuring values through the use of an arithmetic program line Channels to derive meaningful data to the user’s application. The feature is only available on the Intelligent Galaxy SC.
  • Page 258 Tyco Electronics Galaxy SC Controller J85501F-1 Where, ΣC = sum of ampacities of all rectifiers turned on ΣI = sum of outputs of all rectifiers turned on The energy-management algorithm compares the plant load current ) with the sum of output currents being delivered by all rectifiers Load ).

  • Page 259: Parameters

    Tyco Electronics Galaxy SC Controller J85501F-1 Parameters The energy management feature may be enabled via the T1.317 interface or from the front panel. The energy management enabled parameter shows the state of the hardware and software DIP switches for energy management. The energy management state shows the state of the energy management algorithm (e.g., the algorithm could be enabled...

  • Page 260: Rectifier State History

    Tyco Electronics Galaxy SC Controller J85501F-1 Rectifier State The rectifier state history maintains a record of the date and time of History every rectifier state change. An entry is added to the history when any of the rectifiers change state. The latest 256 state entries are retained.

  • Page 261: Login State History

    Tyco Electronics Galaxy SC Controller J85501F-1 Battery thermal protection MANUAL Front panel TIMED MANUAL Timed boost started from an access port TIMED AUTO Automatic post battery discharge time based ALARM Aborted due to alarm condition REMOTE Aborted from access port...

  • Page 262: Low Voltage Disconnect (Lvd)

    Tyco Electronics Galaxy SC Controller J85501F-1 • Controller Option Inventory • Remote Peripheral Monitor Inventory • Reserve Battery Inventory • Battery String Inventory • Distribution Bay Inventory • Panel Inventory • Slot Inventory All inventory fields, except for identifiers and descriptions, default to empty.
  • Page 263 Tyco Electronics Galaxy SC Controller J85501F-1 threshold. The Galaxy SC can perform load shedding with two different voltage disconnect contacts. Low Voltage The low voltage battery disconnect feature disconnects the battery Battery Disconnect sections associated with a contactor, when the plant voltage drops below (LVBD) a user programmable disconnect threshold.
  • Page 264 Tyco Electronics Galaxy SC Controller J85501F-1 DISCONNECTED(LV) - The contactor is open because the plant voltage was lower than the disconnect threshold. DISCONNECTED(HT) - The contactor is open because the battery temperature was higher than the high temperature disconnect threshold.

  • Page 265: Maintenance Reminder

    Tyco Electronics Galaxy SC Controller J85501F-1 contactor failed alarm Each contactor has an alarm (C1F, C2F) that indicates that the contactor has failed to open or failed to close. user relay conflict If a user has selected contactor 1 or 2 to...

  • Page 266: Rectifier Bays

    Tyco Electronics Galaxy SC Controller J85501F-1 Phone Number May contain up to 25 characters. default: none valid characters: 0-9 ( ) - # * , (, translates to a 2 second delay) Connect Baudrate Range: 300, 1200, 2400, 4800, 9600, 14400 default: 2400...

  • Page 267: Rectifier Off Conditions

    TR: the rectifier is placed in standby by the external rectifier sequencer via TR1, TR2, TR3 or TR4 • CB: The rectifier is reporting a circuit breaker failure, however the rectifier does not turn itself off. This occurs on Tyco Electronics 7 - 33 Feature Descriptions Issue 13 February 2001...

  • Page 268: External Rectifier Sequencer

    Tyco Electronics Galaxy SC Controller J85501F-1 J874 series rectifiers. The Galaxy SC places the rectifier in standby mode until the rectifier is repaired, in order to protect the rectifier. There is no overriding condition for this standby mode. External Rectifier...

  • Page 269: Operator Rectifier Control

    Tyco Electronics Galaxy SC Controller J85501F-1 using the engine-alternator transfer retirement interval, to avoid inrush; the default engine-alternator transfer retirement interval is 1 second. In all cases, the battery subsystem is supplying power to the load when neither commercial AC or the engine-alternator is powering the rectifiers.

  • Page 270: Rectifier Restart

    Tyco Electronics Galaxy SC Controller J85501F-1 Rectifier Restart The operator at any security level and at any time can manually restart all rectifiers from the front panel or from the T1.317 interface. In addition to the operator manually restarting rectifiers, auto restart of rectifiers after an RFA can be enabled with a hardware and software DIP switch.
  • Page 271 ROD is 10 minutes. Thus, when the plant voltage drops below the ROT value for the ROD delay, all rectifiers in standby mode for any reason, except Tyco Electronics J874 series rectifiers with active Circuit Breaker Alarms, will turn on.
  • Page 272 Tyco Electronics Galaxy SC Controller J85501F-1 Rectifier on Delay Default 10 minutes, range 0 to 60 minutes (Coup De Fouet time) TR1-4 state View TR1, TR2, TR3 and TR4 statuses The following plant alarms are associated with any rectifier, and may be viewed from the front panel or via the T1.317 interface:...

  • Page 273: Rectifier Manager

    Tyco Electronics Galaxy SC Controller J85501F-1 TR1-4 placed rectifier in standby mode presence signal Rectifier type unconfigured presence signal for rectifier Rectifier Serial rectifiers have no manual controls other than a Power On / STDBY switch. The manual Voltage Adjust potentiometer and...

  • Page 274: Rectifier Monitoring And Control

    Tyco Electronics Galaxy SC Controller J85501F-1 SHVSD BOOST Controls the rectifier Internal high voltage shutdown threshold in the Boost Mode. Should be set higher than the plant HV BOOST. LDSH Forced Load Share between rectifier’s Enable/ Disable. RMOVE RECT Rectifier is configured when plugged to the controller and the ID is set in the rectifier.
  • Page 275 Tyco Electronics Galaxy SC Controller J85501F-1 • Each module has a circuit card mounted on a plastic case. Each module contains measuring channels used to measure the external devices. Each module has a green LED which is illuminated under normal operation, but rapidly blinks to indicate an error condition.
  • Page 276 Tyco Electronics Galaxy SC Controller J85501F-1 board is removed while system is up, the system performs a WARM BOOT. On booting up, the remote module process continuously checks for the board signature with sleep time about 10 seconds in between until the board present signal is detected.

  • Page 277: Voltage Modules

    Tyco Electronics Galaxy SC Controller J85501F-1 information from the new module, the warning signal will be cleared, the module status is set to attached. If the configuration locked is false, then: • Detection of error changes the status of a module (and channels) to failed.

  • Page 278: Shunt Modules And Channels

    Tyco Electronics Galaxy SC Controller J85501F-1 to program the U0003 state to TRUE if the reading of channel 1, module 2 is greater than 3.1 (the threshold); otherwise the state is FALSE. Remember that an UDE is an alarm, so user can program its severity, dial out, ...

  • Page 279: Security

    Tyco Electronics Galaxy SC Controller J85501F-1 Security The Galaxy SC supports a number of security features that provide control over access to the controller. These features include: • Hardware/software switches • Three levels of T1.317 passwords • A TL1 password •...

  • Page 280: Access Port Security Hardware/Software Switches

    Tyco Electronics Galaxy SC Controller J85501F-1 security level from the T1.317 interface. When changing passwords, the following guidelines must be followed: • Passwords must be between 6 and 15 characters long • User and TL1 passwords may contain alpha-numeric characters •...

  • Page 281: Security Events

    Tyco Electronics Galaxy SC Controller J85501F-1 location is entered, the Galaxy SC will hang-up, wait 5 seconds, and then call the phone number assigned to the selected location. Once the call is answered, the Galaxy SC will prompt for a password and start a T1.317 session.

  • Page 282: Auxiliary Port

    Tyco Electronics Galaxy SC Controller J85501F-1 login state Indicates whether a user is logged in on this port. The possible states are: LOGOUT - no one is logged in USER - T1.317 user security level session in progress SUPER-USER - T1.317 super-user security level session in progress ADMINISTRATOR - T1.317 administrator security level...

  • Page 283: Modem Port

    Tyco Electronics Galaxy SC Controller J85501F-1 login state Indicates whether a user is logged in on this port. The possible states are: LOGOUT - no one is logged in USER - T1.317 user security level session in progress SUPER-USER - T1.317 super-user security level session in progress ADMINISTRATOR - T1.317 administrator security level...

  • Page 284: Enhanced Remote Security Via Modem Port And Auxiliary Port

    Tyco Electronics Galaxy SC Controller J85501F-1 data bits Range of values: 7 or 8, default: 8 parity Range of values: odd, even, or none, default: none stop bits Range of values: 1 or 2, default: 1 time-out Defines idle time in minutes before T1.317 interface user is automatically logged off.
  • Page 285 Tyco Electronics Galaxy SC Controller J85501F-1 Table 7-A: Remote Security Via Modem and Auxiliary Ports Functions Change Boost Current Threshold Change Rectifier Status* Change Rectifier Shunt Voltage configuration Change Rectifier Float High Voltage Shutdown Threshold Change Rectifier Boost High Voltage Shutdown Threshold...

  • Page 286: Software Upgrade

    A NOM temp of 25° C and a HIGH TEMP of 53° C in a 24 cell plant provides a PV/D° equal to 72 mV/deg C. This slope is compatible with Tyco batteries. To obtain the per cell change voltage change per degree change in temperature, (CV/D°), divide PV/D° by the number of cells.

  • Page 287: Statistics

    Tyco Electronics Galaxy SC Controller J85501F-1 security level and is supported from the T1.317 interface and EasyView. The Galaxy SC supports a binary upgrade using the Xmodem protocol or an ASCII text upgrade. Generally the binary upgrade file will have a .bin extension and the S-record upgrade file will have a .abs extension.

  • Page 288: Basic Statistics

    Tyco Electronics Galaxy SC Controller J85501F-1 Basic Statistics Basic statistics are stored for every measured value, read at the instantaneous data rate. The items stored for basic statistics are: Highest Hourly Average Values: The three highest hourly averages are kept in memory and updated each hour. Collection of data begins when the first valid hourly average is available.

  • Page 289: Effect Of Power Failure

    Tyco Electronics Galaxy SC Controller J85501F-1 date, plant voltage, and battery current, will be added to the Discharge Statistics table. The frequency at which entries are added to the log depends on the rate of battery discharge. If a voltage reading differs by at least 250mV from the previous entry (125mV for 24-volt plants), it will be recorded.

  • Page 290: Terminal Menu Interface

    Tyco Electronics Galaxy SC Controller J85501F-1 Daily Statistics: Daily maximum and minimum values for the day of a power failure will be the high and low readings between the time power was restored and the next change of day. The daily maximum one-hour average will be the highest average recorded since power was restored.

  • Page 291: User Defined Events

    Tyco Electronics Galaxy SC Controller J85501F-1 will re-evaluate these parameters and change the event state to ON or OFF according to the following diagram: OT: Origin of system time ST: Timer Event start time System current time ET: End time = ST + duration +-------------------+----------+------------+---------->ET...
  • Page 292 Tyco Electronics Galaxy SC Controller J85501F-1 • Binary mathematical operators accepted: (+, -, *, /). • Unitary mathematical operators accepted: (+, -). • Comparator operators accepted (= EQ, < LT, > GT). • Parentheses accepted. • The expression has the following precedence (highest first):(), NOT, unary +, negation -, *, /, +,-,, <, >, EQ, AND, XOR, OR.
  • Page 293 Tyco Electronics Galaxy SC Controller J85501F-1 PHT1: Processor Halt LSF1: Load Share Fuse CLC1: Clock Changed MAN1: Manual Off STF1: Self Test Failed ETS1: External Transfer Shutdown PGI1: Program Line Invalid RIC1: Rectifier Incomplete Config CCH1: Configuration Changed COF1: Queue Overflow...

  • Page 294: Examples

    Tyco Electronics Galaxy SC Controller J85501F-1 The expression can contain system resources that can be added to or removed from the system dynamically (for example rectifier, remote peripheral monitoring modules). If the expression has operands that is no longer exist in the system, the expression is no longer valid and the system Invalid Expression alarm is set.
  • Page 295 Tyco Electronics Galaxy SC Controller J85501F-1 The above will generate a Minor Alarm if a Module Out of Range alarm (MOR1) exists or a Module Type Conflict alarm exists (MTC1) or a Module Failure alarm (MDF1) exists. 3. You may monitor if a fuse is blown using channel 1 of the Binary module address 03 and generate a Minor alarm.

  • Page 296: Universal Reserve Time Prediction

    Tyco Electronics Galaxy SC Controller J85501F-1 CHA U0005,SEV=MIN CHA U0006,SEV=MIN Note: For a Binary Channel: < 1.9V means the state is OFF or CLOSED or 0. > 3.1V means the state is ON or OPEN or 1. For a Control Relay Channel: A FALSE program line results in the relay in the OFF or CLOSED state.
  • Page 297 Fouet time period is calculated as approximately 5 percent of the projected discharge time, and is typically 1 minute to 15 minutes. After the Coup De Fouet, the prediction is based on a Tyco patented prediction algorithm. In essence, the algorithm “learns” the...

  • Page 298: Installation

    Tyco Electronics Galaxy SC Controller J85501F-1 is created. The alarm is retired after the batteries recharge. This alarm can also occur if the plant load increases so that the battery reserve time is less than two hours with a fully charged battery. A prediction is never made if the plant load in amperes is not in the range from C/2 to C/32, where C is the ampere-hour rating of the batteries.
  • Page 299 Tyco Electronics Galaxy SC Controller J85501F-1 The reserve time prediction algorithm monitors the following items for predicting reserve time and provides alarms as indicated: Temperature Probe Present: This input allows Galaxy SC to recognize that the battery temperature probe is present. If the temperature probe is present, then the prediction algorithm is active;...
  • Page 300 The reserve time prediction algorithm is based on a modeling technique that is adaptive for different types of batteries. The batteries currently supported are listed above. The default value is the Tyco Electronics KS-20472, L-1S battery. Number of Battery Strings: The reserve time is adjusted to reflect the number of battery strings and the actual plant load.
  • Page 301 Tyco Electronics Galaxy SC Controller J85501F-1 7 - 67 Feature Descriptions Issue 13 February 2001...

  • Page 302: Troubleshooting

    Tyco Electronics Galaxy SC Controller J85501F-1 Troubleshooting Introduction Many of the troubleshooting procedures described in this Section require removing or replacing circuit packs. Review “Circuit Pack Addition, Removal and Replacement” in Section 3 before proceeding. Basic Controller Circuit Packs After power up, or after a reset, the green and amber LEDs will both be...

  • Page 303: Other Basic Boards

    Tyco Electronics Galaxy SC Controller J85501F-1 the controller, and verify proper operation. If the problem remains put the original BJA power board back in the controller and go to the next step. 4. Insert all boards which were removed one at a time, while resetting the controller after each board is installed and looking for improper operation.

  • Page 304: Intelligent Controller Circuit Packs

    Tyco Electronics Galaxy SC Controller J85501F-1 Intelligent Controller Circuit Packs After power up, or after a reset, the green and amber LEDs will both be Microprocessor lit while self diagnostics are in progress (which will take about a 30 Board seconds).

  • Page 305: Intelligent Option Boards

    Tyco Electronics Galaxy SC Controller J85501F-1 • +5V: 4.75V-5.25V • +12V: 12.43V-12.85V (although it should not be necessary to field adjust, this is the only adjustable voltage on the BJJ power board. Its output level is controlled by potentiometer R101.) •...

  • Page 306: Replace Battery

    3. Remove the memory battery. Take care not to flex the battery holder clip excessively. 4. Insert the memory battery (Panasonic BR2032 or equivalent, Tyco Comcode 406526079) into the BJH (Intelligent Controller) circuit pack X201 battery holder. Observe proper polarity; the battery holder clip contacts the “+”...
  • Page 307 Tyco Electronics Galaxy SC Controller J85501F-1 Restore System 1. Log in and begin an EasyView session using the previously Configuration modified connection profile. 2. Open the File menu and click on Restore. Select the configuration file you saved when you performed the Backup operation. Click OK.

  • Page 308: Alarms

    Tyco Electronics Galaxy SC Controller J85501F-1 Alarms This Table lists alarms available on Galaxy SC, SCF and Millennium Controllers. Table 8-A: Galaxy Alarms Symbol Designation Explanation Alarm Cut-Off has been initiated to silence local audible alarms. Any subsequent Power Critical,...
  • Page 309 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation The intelligent controller memory battery, located on the front edge of the Galaxy BJH or Millennium BSJ Intelligent Control pack requires Memory Backup Battery BBL1 replacement. Do NOT power down the controller...
  • Page 310 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation A Battery Thermal Protection (BTP) module wired to the BTP inputs of Galaxy TB3 is BTJ1 Battery Thermal Major reporting a battery temperature above its major alarm threshold (varies with BTP type).
  • Page 311 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation A change has been made to Galaxy’s Time or CLC1 Clock Changed Date setting. This is a latched event, remaining active until cleared by a user. The rectifiers connected to the controller’s serial bus have reached their current limit setting.
  • Page 312 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation The contactors controlled by the controller’s LVD CN2 settings (usually used with some or all CNO2 Contactor 2 Open LVLD contactors of a plant) are open (disconnected).
  • Page 313 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation Plant load has been reported at greater than the EPD1 Excess Plant Drain plant shunt size. This is a latched event, remaining active until cleared by a user.
  • Page 314 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation A resistive battery potential is present on the FAN alarm input at TB3-6 or Millennium BSL-65, indicating a minor fuse alarm is active in the plant FAN1 External Fuse Minor circuit connected to this point.
  • Page 315 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation A connected rectifier has been manually turned MAN1 Manual Off off or has lost AC input power. The controller has lost communication with two or more devices that it had previously recognized on its rectifier/converter/BIC serial bus.
  • Page 316 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation One or more of the log-in passwords is at it’s default value. All passwords must be set to PFD1 Password At Default something other than their default before this event will clear.
  • Page 317 Tyco Electronics Galaxy SC Controller J85501F-1 Table 8-A: Galaxy Alarms Symbol Designation Explanation The plant load has exceeded the total rectifier drain by more than the factor programmed for this alarm, without causing plant voltage to fall. This RPI1 Rect/Plant Inconsistency is a latched event, remaining active until cleared by a user.

  • Page 318: Safety

    Safety Safety Please read and follow all safety instructions and warnings before installing, maintaining, or repairing the Galaxy SC Controller. Also Statements refer to the peripheral monitoring system product manual for safety statements related to the installation and use of these devices.
  • Page 319 Tyco Electronics Galaxy SC Controller J85501F-1 manufacturer using only the connector manufacturer’s recommended tooling or tooling approved for that connector. For electrical connections requiring crimp-on lugs, make sure the proper crimping tools and dies are used (information for these connections are provided in the product documentation).
  • Page 320 Tyco Electronics Galaxy SC Controller J85501F-1 inherently limited transformer rated 30 vac max. The typical operating current from each output is less than 0.5 amps (with a maximum of 85 modules attached). Connectors on the backplane contain communication circuits, current limited signals, and 19 to 30vdc or 36 to 60vdc control signals fused at 1-1/3 amp.

  • Page 321: Warning Statements And Safety Symbols

    Tyco Electronics Galaxy SC Controller J85501F-1 Warning The symbols may sometimes be accompanied by some type of statement; e.g., “Hazardous voltage/energy inside. Risk of injury. This Statements and unit must be accessed only by qualified personnel.” Safety Symbols This symbol identifies the need to refer to the equipment instructions for important information.
  • Page 322 Tyco Electronics Galaxy SC Controller J85501F-1 The symbols may sometimes be accompanied by some type of statement; e.g., “Hazardous voltage/energy inside. Risk of injury. This unit must be accessed only by qualified personnel.” This symbol is used to identify the presence of a hot surface.

  • Page 323: Precautions

    Tyco Electronics Galaxy SC Controller J85501F-1 Precautions Note the following precautions when working on or using this type of equipment: • This unit must be installed, serviced, and operated only by skilled and qualified personnel who have the necessary knowledge and practical experience with electrical equipment and who understand the hazards that can arise when working on this type of equipment.

  • Page 324: Product Warranty

    Tyco Electronics Galaxy SC Controller J85501F-1 Product Warranty A. Seller warrants to Customer only, that: 1. As of the date title to Products passes, Seller will have the right to sell, transfer, and assign such Products and the title conveyed by Seller shall be good;...
  • Page 325 Tyco Electronics Galaxy SC Controller J85501F-1 Warranty Period Repaired Product Product Type New Product or Part* Central Office 24 Months 6 Months Power Equipment** * The Warranty Period for a repaired Product or part thereof is as listed or, in the case of Products under Warranty, is the period listed or the unexpired term of the new Product Warranty Period, whichever is longer.
  • Page 326 Tyco Electronics Galaxy SC Controller J85501F-1 with returning such Product to Seller shall be borne by Customer. Seller shall pay the cost of transportation of the repair or replacing Product to the destination designated by Customer within the Territory. E. The defective or nonconforming Products or parts which are replaced shall become Seller’s property.

  • Page 328: Appendix A T1.317 Interface

    Overview The T1.317 interface is the primary source of access to all features of the Galaxy SC Controller. It is based on the principles outlined in the ANSI standard entitled, “Uniform Language for Accessing Power Plants - Human-Machine Language.” The T1.317 language is based on viewing the system as a set of objects with attributes.

  • Page 329: Login Header A

    Tyco Electronics Galaxy SC Controller J85501F-1 user prompt super-user prompt administrator Login Header At this point the user can enter T1.317 commands. The login header, which is described below, may be accessed at any time bye entering the HEADER alias.
  • Page 330 Tyco Electronics Galaxy SC Controller J85501F-1 Each system resource has settings that can be viewed or changed from the command line. These settings are called attributes. Each attribute can be referenced by an identifier. For example, the object DC1 has a DC voltage attribute identified as VDC and a DC current identified as ADC.
  • Page 331 Tyco Electronics Galaxy SC Controller J85501F-1 Syntax A T1.317 command line is terminated by a <CR> (ASCII 13) or <LF> (ASCII 10). Multiple commands can be concatenated on a single command line by separating the commands with the ; (semicolon) character.
  • Page 332 Tyco Electronics Galaxy SC Controller J85501F-1 Operation Operation commands change the state of the system. Listed below are Commands the commands, description, syntax, and the operations those commands perform. Add a user addable object to the system. Add a linkable attribute to an object.
  • Page 333 Tyco Electronics Galaxy SC Controller J85501F-1 When adding a linkable attribute to an object, the attribute name must not con- flict with any of the existing attribute names of the object. After adding the link- able attribute to an object the user may link an object to it using the LIN command.
  • Page 334 Tyco Electronics Galaxy SC Controller J85501F-1 syntax is used to clear attribute specific history. For example, CLH DC1 REC G01,STT will clear the rectifier state history of rectifier G01. The following ex- ample will clear the DC1 plant alarm history:...
  • Page 335 Tyco Electronics Galaxy SC Controller J85501F-1 from the list of objects being linked to it. The following example adds a user de- fined event to the power system manager object, PS1, and sets its severity to minor: ADD UDE,U0001 Add a user defined event identified as U0001...
  • Page 336 Tyco Electronics Galaxy SC Controller J85501F-1 Change a password Syntax:PAS x[,password,password] where x is U for user password S for super-user password A for administrator password T for TL1 password This command allows passwords to be changed at the administrator security level only.
  • Page 337 Tyco Electronics Galaxy SC Controller J85501F-1 RESTORE Restore the system configuration Syntax:RESTORE [X|A] X indicates XMODEM transfer A indicates ASCII transfer This command allows the administrator to restore a system configuration. If the optional arguments are not included, the controller responds to this command by prompting the user for either an ASCII or XMODEM file transfer or to cancel the restore operation.
  • Page 338 Tyco Electronics Galaxy SC Controller J85501F-1 error occurred while processing the command then a line preceded by the ! (exclamation) character will give an error code and short description of the error. Report active alarms Syntax:ALA [objpath] This command searches the objects that objpath leads to, and all objects linked to these objects, for active alarms.
  • Page 339 Tyco Electronics Galaxy SC Controller J85501F-1 n for newest datedate (default: current date) o for oldest datedate (default: oldest system date) f for report first “o”:oldest first “n”:newest first (default n) i for include “comma separated list of events” This command searches the objects that objpath leads to, and all objects linked to these objects, for events and reports any history for those events.
  • Page 340 Tyco Electronics Galaxy SC Controller J85501F-1 tributes. If linkable attributes are specified on the command line, those at- tributes must be linked to a remote peripheral monitor channel. For linkable attributes the measurement value of the remote peripheral monitor channel is reported.
  • Page 341 Tyco Electronics Galaxy SC Controller J85501F-1 active record-only events are reported. Each line in the report has the following format: event_path,date,time,severity,description The following examples will report all the active record-only events in the sys- tem and just the DC plant active record-only events:...
  • Page 342 Tyco Electronics Galaxy SC Controller J85501F-1 CLRLDST Clear plant load statistics. (CLS DC1, ADC) DATE Report the date and time. (STA PS1,DAT,TIM) HEADER Report the login header. (STA PS1, SDE, SID, DES, SWV, DOW, DAT,TIM; NAL; NWA; STA DCP,DES,VDC, ADC, STT; STA,...
  • Page 344 Tyco Electronics Galaxy SC Controller J85501F-1 Appendix T1.317 Objects and Attributes This appendix contains tables of all objects supported by the T1.317 interface. The objects are listed in categories with each object being described in terms of its attributes. Each attribute is identified by a description, mnemonic, type, related commands, and a range of values.
  • Page 345 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-1: System Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE System Identifier TEXT Description TEXT Galaxy Controller Site Id TEXT 20 chars (default: 1) Site Description TEXT 55 chars (default: “”)
  • Page 346 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-2: DC Distribution Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE DC Distribution Feeder Identifier TEXT Description TEXT DC Distribution Feeder Distribution Fuse ATTRL Issue 13 February 2001...
  • Page 347 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-3: AC Distribution Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE AC Distribution Identifier TEXT ACD1 Description TEXT AC Distribution Phase R Voltage ATTRL Phase S Voltage...
  • Page 348 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-4: Alarm Test Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Alarm Test Identifier TEXT Description TEXT Alarm Test 1 Alarm Test State NUMBER 0:inactive 1:active Rectifier Test Failure...
  • Page 349 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-5: DC Plant Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE DC Plant Identifier TEXT Description TEXT DC Plant 1 Plant Type NUMBER +48V/ +24V/ -48V/ -24V DC...
  • Page 350 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-5: DC Plant Objects and Attributes, continued Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Rectifier Incomplete Config ATTRL RIC1 Half Power ATTRL HPA1 ID Conflict ATTRL DID1 Rectifier Current Limit...
  • Page 351 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-6: Boost Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Boost Identifier TEXT Description TEXT Boost Control 1 State TEXT QRCT, MANUAL, BTP, TIMED AUTO, OFF Boost Enable...
  • Page 352 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-7: Rectifiers Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Rectifier Manager Identifier TEXT Description TEXT Rectifier Manager 1 Load Share Enable NUMBER 0:disable 1:enable Float High Voltage Shutdown NUMBER 25-30:27.75 or 50-60:55.50 volts...
  • Page 353 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-8: Converter Management Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Converter Plant Identifier TEXT Description TEXT Converter Plant 1 DC Voltage NUMBER number in volts DC Current...
  • Page 354 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-9: Battery Management Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Battery Reserve Identifier TEXT Description TEXT Battery Reserve 1 High Temperature Threshold TTH NUMBER 30°-90-:75°C or 86-194:167°F...
  • Page 355 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-9: Battery Management Objects and Attributes, continued Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Slope Thermal Compensation Identifier TEXT Description TEXT Slope Thermal Comp State NUMBER 0:disable 1:enable Raise Voltage Enable...
  • Page 356 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-10: Alarm And Events Objects and Attribute Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE System Alarms Standard Alarm Identifier TEXT see list below Description TEXT see below Alarm State...
  • Page 357 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-10: Alarm And Events Objects and Attribute, continued Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE DEFAULT DESCRIPTION DID1 ID Conflict CLM1 Rectifier Current Limit CFA1 Converter Fail CFN1 Converter Fan Minor...
  • Page 358 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-10: Alarm And Events Objects and Attribute, continued THRESHOLD VOLTAGE RANGES (default:min-max) DEFAULT DESCRIPTION FLOAT BOOST Notify Destination TEXT “”,P1,P2,P3,P4 BDA1 Battery On Discharge 23-28:25V or 46-55:51V 23-28:25V or 46-55:51V HVA1 High Voltage 24.75-29.75:26.8V...
  • Page 359 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-11: Data Switch Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Data Switch Identifier TEXT DS1,DS2,DS3,DS4 Description TEXT Data Switch n Connected Equipment ID TEXT GALAXY,OMNI, ECS, MCS,...
  • Page 360 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-12: Remote Peripheral Monitor Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Remote Peripheral Monitor Identifier TEXT Mxx (x=0-9,A-F, i.e. xx is 01 to FF) Description TEXT...
  • Page 361 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-13: Reporting Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Call-Out Manager Identifier TEXT Description TEXT 30 char (Call-Out Manager) NAG Interval NUMBER 15 to 60 minutes...
  • Page 362 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-14: Remote Communication Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Modem Identifier TEXT Description TEXT Modem Port 1 State TEXT USER,SUPER-USER, ADMINISTRATOR,TL1,LO GOUT Data Bits NUMBER...
  • Page 363 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-15: Configurable Statistics Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Trend Identifier TEXT TR1 to TR8,DCT1 Description TEXT (DC1) Trend Statistics n Source TEXT Any MET attribute path (default: “”)
  • Page 364 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-16: Inventory Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Plant Inventory Identifier TEXT PLI1 Description TEXT Plant Inventory 1 Plant Installation Date TEXT 8 char (default: “”)
  • Page 365 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-16: Inventory Objects and Attributes, continued Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Controller Option Inventory Identifier TEXT CI01 to CI45 Description TEXT Controller Option n Date Installed TEXT 8 char (default: “”)
  • Page 366 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-17: TL1 Management Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE TL1 Manager Identifier TEXT TLM1 Description TEXT 30 char (TL1 Manager) Activate-User Enable NUMBER 0:disable 1:enable...
  • Page 367 Tyco Electronics Galaxy SC Controller J85501F-1 Table B-18: Miscellaneous Objects and Attributes Related Commands ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE Call-Back Security Identifier TEXT Description TEXT Call-Back Security 1 State NUMBER 0:off 1:on Call-Back Phone Number PH1-5 TEXT digit ( ) * # - , space (default: “”)
  • Page 368 Tyco Electronics Galaxy SC Controller J85501F-1 Appendix T1.317 Error Messages Error Messages Listed below are the T1.317 interface error message and their possible causes. and Causes Syntax Related -100,TOO MANY CHARACTERS The command line is too long. Break the command up into separate commands and put them on separate lines.
  • Page 369 Tyco Electronics Galaxy SC Controller J85501F-1 Security Related -220,SECURITY ERROR Must be super-user or administrator to execute this command. Login at a higher security level using the LOGIN command and try again. -221,EXCESSIVE LOGIN ATTEMPTS The wrong password was entered too many times when trying to login or change security levels.
  • Page 370 Tyco Electronics Galaxy SC Controller J85501F-1 -303,ALIAS FAILED The aliases are nested too deeply. Redefine alias so that aliases are not as dependent on other aliases. -304,INVALID PARAMETER An attempt was made to change an attribute to an invalid value. Check that the value is in the proper range.
  • Page 371 Tyco Electronics Galaxy SC Controller J85501F-1 -315,LINK NOT FOUND An attempt was made to unlink an object from an attribute to which it is not linked. -316,COULD NOT UNLINK An attempt was made to unlink an object from an attribute that was not linked using the LIN command.
  • Page 372 Tyco Electronics Galaxy SC Controller J85501F-1 -328,FEATURE DISABLED An attempt was made to activate a feature that has been disabled. Check the feature’s software and hardware DIP switch settings. -329,INDEPENDENT CTLR NOT AVAILABLE An attempt was made to access a feature that requires the independent controller support.
  • Page 373 Tyco Electronics Galaxy SC Controller J85501F-1 Diagnostic Table C-1 lists various Galaxy diagnostic messages. Messages Table C-1: Galaxy Diagnostic Messages Number Message Rect cable module type is unknown Phase failure produced excess ripple causing output breaker to trip Short on output filter capacitor...
  • Page 374 Tyco Electronics Galaxy SC Controller J85501F-1 Table C-1: Galaxy Diagnostic Messages Number Message RFA present; fuses in rect blew or internal HV circuit was operated AC fail; if no loss of ac, check rectifier connections Excess RCT Drain: Possible rectifier board failure...
  • Page 375 Tyco Electronics Galaxy SC Controller J85501F-1 Table C-1: Galaxy Diagnostic Messages Number Message Battery is charging Recharge capacity fell below %1.of% average hourly load = 1.of% A average rectifier capacity = %1.of A Engine signals active too long, rectifiers turned back on...
  • Page 376 Tyco Electronics Galaxy SC Controller J85501F-1 Appendix TL1 (Transaction Language 1) and X.25 Interface Introduction The Transaction Language (TL1) command interface for the Galaxy SC Controller equipped with the BJH Intelligent Board enables direct communication with a central computerized monitoring system using TL1 commands as specified by Bellcore.

  • Page 377: Figure D-1: Tl1 Block Diagram

    Tyco Electronics Galaxy SC Controller J85501F-1 Network Connection RS232/530 Terminal User STP/X.25 Galaxy Intelligent RS232/485 T– Board Converter R– Interface P4/P5 Figure D-1: TL1 Block Diagram Tools and Parts Note: The following steps describe a typical installation. Depending on what optional equipment was ordered or is being reused, some of the following may not be present.

  • Page 378: Figure D-2: Pad Cpu Board

    Tyco Electronics Galaxy SC Controller J85501F-1 Following provided with DSU option: • 1 Data Service Unit (DSU) Following provided with mounting shelf option: • 1 mounting shelf and hardware for DSU and PAD units Customer provides: • 1 computer terminal for setup purposes •...

  • Page 379: Figure D-3: Pad Daughter Board

    Tyco Electronics Galaxy SC Controller J85501F-1 Table D-1: Pad Jumper Settings Jumper Location Jumper Setting* Function LK6 (CPU) Position 1 jumpered Port 2 +12V power LK3 (Daughter) Position 3 jumpered Port 3 +12V power LK6 (Daughter) Position 3 jumpered Port 4 +12V power...
  • Page 380 Tyco Electronics Galaxy SC Controller J85501F-1 Mount the PAD and DSU units in the shelf: 1. Set the units on the shelf in the positions shown in Figure D-4, making sure the feet on the bottom of the unit protrude through the holes in shelf.
  • Page 381 Tyco Electronics Galaxy SC Controller J85501F-1 Table D-2: RS-232/485 Converter DIP Switch Settings Switch Mode 6. Connect the RS-232/485 converter to the Galaxy RS-485 port, located on terminal block TB4 on the rear of the controller, using the configuration in Table D-3:...

  • Page 382: Figure D-5: Pad Power Cable Setup

    Tyco Electronics Galaxy SC Controller J85501F-1 Figure D-5: PAD Power Cable Setup PAD Setup The PAD is set up by typing a set of commands on the setup terminal, to define the logical connection. This setup is dependent upon the network administrator, and the existing PAD port usage.
  • Page 383 Tyco Electronics Galaxy SC Controller J85501F-1 Table D-4: PAD Messages PAD Message Description Command was entered and executed without CMD ACCEPTED errors Command rejected. Probably caused by CMD REJECTED incomplete command. Call connected Invalid command syntax, or missing or bad parameter.
  • Page 384 Tyco Electronics Galaxy SC Controller J85501F-1 1. On the terminal connected to the setup port STP, enter ...<RETURN> (3 periods and a carriage return). 2. By default, the PAD requires a password for each command entered. Turn this option off by typing the Set System command: S^S^PA:XYXYXY^OP:N<RETURN>.
  • Page 385 Tyco Electronics Galaxy SC Controller J85501F-1 Display System (Show required passwords) D^A^A^PO:<PN> Display Address Associations (Show SVC address) D^N^C Display Network Connection (Show DCE/DTE status of PAD) D^L^P^PO:<PN> Display Line Parameters (Show port communication characteristics) D^C^D^PO:<PN> Display Character Definitions (Show TL1 command termination characters) D^A^P^PO:<PN>...
  • Page 386 Tyco Electronics Galaxy SC Controller J85501F-1 The setup terminal and the connecting DB-25 to DB-25 cable can now be removed if necessary. Debugging TL1 The TL1 interface does not report any messages until an activate user command. Thus, it becomes extremely difficult to debug wiring or software setup problems.
  • Page 387 Tyco Electronics Galaxy SC Controller J85501F-1 6. If the OS does not receive the Galaxy’s response: Display the TL1 connection status, by typing the Display Networks Statistics command: D^N^S<RETURN>. The output of the command will look like: Statistics HDLC STATISTICS...
  • Page 388 Tyco Electronics Galaxy SC Controller J85501F-1 If either the frame statistics, or packet statistics channel 0 status is not UP then there is something wrong in the setup with the OS or the PAD. All channel 1 statuses should be ignored.
  • Page 389 Tyco Electronics Galaxy SC Controller J85501F-1 Test the OS to PAD 1. Disconnect the RS-232/485 converter from the PAD Port and connect the terminal and cable to the PAD port, where the RS-232/ 485 converter was plugged in. Messages can now be transmitted directly from the OS to the terminal and back.
  • Page 390 Tyco Electronics Galaxy SC Controller J85501F-1 Galaxy TL1 The TL1 interface is provided by the Intelligent Controller (BJH) board of the Galaxy SC. Configuration Auxiliary Port To initiate TL1, configure the application attribute of the auxiliary port as TL1, and set handshaking for this port for software. (See Section 4 and Table 3-D for software and hardware configuration information.)
  • Page 391 Tyco Electronics Galaxy SC Controller J85501F-1 For software enable, send the following command through the local port: cha au1, wre = 1 Command Format The format of an input command from OS to Galaxy is a command word followed by a variable number of fields of command-specific information separated by colons.
  • Page 392 Tyco Electronics Galaxy SC Controller J85501F-1 CTAG (Correlation The CTAG is a message identifier, assigned and sent by the OS with Tag) each command, which correlates an input command with its associated output response. Galaxy automatically copies this value into the appropriate field of its output response to the associated input command.
  • Page 393 Tyco Electronics Galaxy SC Controller J85501F-1 Login by OS: The OS should login to the Galaxy using the “ACTIVATE USER” TL1 command. After successful login by OS, the Galaxy is ready to respond to other TL1 commands and send autonomous TL1 messages to OS.
  • Page 394 Tyco Electronics Galaxy SC Controller J85501F-1 Error Response Format: The format of the error response is: response header M^^CTAG^DENY cr lf ^^^error code cr lf; where: CTAG number specified in the incoming request Error Codes: ICNV input command not valid...
  • Page 395 Tyco Electronics Galaxy SC Controller J85501F-1 Where: CTAG command identification number specified in request as specified by user via configuration screen Alarm level CR | MJ | MN (Critical [CR], Major [MJ] or Minor [MN] Condtype text specified by user via configuration screen...
  • Page 396 Tyco Electronics Galaxy SC Controller J85501F-1 The Galaxy generates the following error response for requests made for an AID not present in the system, or for channels with matching AIDs that are not enabled for TL1 reporting by the user’s configuration:...
  • Page 397 Tyco Electronics Galaxy SC Controller J85501F-1 IMED: <T>ACO is introduced automatically and immediately at the Galaxy. AID in the command should be specified as ALL since all alarms having specified severity in ACO object configuration will be affected. Refer to Appendix B for attributes of ACO1 object.
  • Page 398 Tyco Electronics Galaxy SC Controller J85501F-1 This response indicates that the controller is In Process (IP) of executing the command and it is followed by the configuration data. The Alarm Center needs to store all the incoming data in a file. When the backup is...
  • Page 399 Tyco Electronics Galaxy SC Controller J85501F-1 Activate User Before activating user, configure the auxiliary port for TL1 application. See “Auxiliary Port” on page 1 of this Appendix. The Galaxy accepts the following command to activate a session (i.e., login to the system): ACT-USER::uid:CTAG::passwd;...
  • Page 400 Tyco Electronics Galaxy SC Controller J85501F-1 response header M^^CTAG^COMPLD cr lf; Autonomous Report Alarm Commands From Galaxy (NE) to OS The Galaxy automatically sends the following message to report the occurrence or retirement of alarms on objects configured as Equipment...
  • Page 401 Tyco Electronics Galaxy SC Controller J85501F-1 response header A^^atag^REPT^RMV^EQPT cr lf ^^^"AID" cr lf ^^^"AID" cr lf; If the alarm state of the object is true, it will be reported as equipment removed. Report Restoration The Galaxy automatically sends the following message to report the...
  • Page 402 Tyco Electronics Galaxy SC Controller J85501F-1 Appendix Terminal Menu Interface Login A user can enter the text-based terminal menu interface on the local, auxiliary, or modem port by first logging in to the T1.317 interface. For the local and auxiliary ports the application attribute (APP) must be set to terminal, which is the default setting.
  • Page 403 Tyco Electronics Galaxy SC Controller J85501F-1 Menus 01/01/2001 01:36PM 0 Alarms 0 Warnings -52.08V 128A Main Menu 0 Bye Logoff 1 Plant Status Voltage, current, and operation mode 2 Alarms Active alarms 3 Warnings Active warnings 4 Alarm History Alarm history...
  • Page 404 Tyco Electronics Galaxy SC Controller J85501F-1 Menus, continued 01/01/2001 01:36PM 0 Alarms 0 Warnings -52.08V 128A Remote Peripheral Monitors 0 Main Menu Logoff 1 Shunt Channels Basic statistics for DC current 2 Voltage Channels Busy hour for maximum hourly average load current...

  • Page 406: Table F-1: Spare Parts

    Tyco Electronics Galaxy SC Controller J85501F-1 Appendix Spare Parts The following table lists the spare parts available for the Galaxy SC Controller Model J85501F-1. Table F-1: Spare Parts Ordering Associated Description Comcode List 107199374 Display board (CP BJG) 107172371 Alarm board (CP BJE1)
  • Page 407 Tyco Electronics Galaxy SC Controller J85501F-1 Table F-1: Spare Parts (Continued) Ordering Associated Description Comcode List L-AA 847473774 through EasyView software package L-AD 107330946 Product manual 167-790-060 Peripheral Monitoring product manual 107570517 L-AG 167-790-063 406530725 1-1/3A Fuse (GMT) 406204230 3A Fuse (GMT)
  • Page 408 Tyco Electronics Galaxy SC Controller J85501F-1 Appendix Glossary Alarm Severity he severity of any alarm or event can be configured as “critical,” “major,” “minor,” “warning,” or “record only.” Critical Alarms are used to indicate that a severe, service-affecting condition has occurred and that immediate corrective action is imperative, regardless of time of day or day of the week.
  • Page 409 Tyco Electronics Galaxy SC Controller J85501F-1 service. A failure can be service affecting according to one or both definitions. (See BellCore TR-TSY-000474.) Plant Voltage Float voltage is the continuous, long-term constant voltage of the plant that maintains battery cells in a fully charged condition. Refer to the battery product manual for the battery cell float voltage level.
  • Page 410 Tyco Electronics Galaxy SC Controller J85501F-1 since attention is required in a limited time, BD is considered a Power Major alarm, by default. It should be noted here that a BD alarm does not necessarily indicate that rectifier output current has been lost or reduced. A BD alarm can be caused by mis-adjusted rectifier output voltage during otherwise normal operation.
  • Page 411 Tyco Electronics Galaxy SC Controller J85501F-1 Coup de Fouet The initial portion of the battery discharge is known as the Coup de Fouet, or “the whip.” During the Coup de Fouet, the plant voltage rapidly decreases several volts, and then slowly rises. The depth of the dip in plant voltage is dependent upon the rate of discharge, the number of hours of battery reserve, the battery type, and battery health.
  • Page 412 Tyco Electronics Galaxy SC Controller J85501F-1 paralleled in the plant, their output voltages are forced to be the same. In a high voltage condition, it is important to discriminate between an individual rectifier failure and a lightning-induced transient which would affect all rectifiers in the plant. In the case of an individual failure, the other working rectifiers in the plant should not be shutdown.
