Alarm Controller v1.0 Installation Guide

This installation guide provides the basic wiring, programming and troubleshooting information required to install the PowerSeries Neo alarm controller. Use this guide in conjunction

with the PowerSeries Neo Reference Manual available online from the DSC website at www.dsc.com. Available models: HS2016, HS2032, HS2064, HS2128.

Quick Setup

Plan

Plan the installation including all alarm detection

devices, zone expanders, keypads and other

required modules.

Mount

Decide on a location for the alarm panel and

secure it to the wall using suitable mounting

hardware.

Wire

Complete all wiring including modules, zones,

bells/sirens, telephone line connections and ground

connections. Record module serial numbers on

page 13.

Power

Connect the battery and power up the system. The

battery must be connected.

Enroll

Hardwired: Wire the keypad to the Corbus, power

up the alarm panel then press any button on the

First Key-

keypad.

pad

Wireless: Wire the HSM2Host to the Corbus, then

power up the alarm panel and a wireless keypad.

Press any button on the keypad to enroll it. The

HSM2Host is then enrolled on the alarm panel.

Alternately, enroll an RF keypad.

Enroll

[*][8][Installer Code][902] subsection [000]. Press

[*] to begin auto-enrollment.

modules

Module slots are automatically assigned. Use

scroll keys to view slots. Change slot by typing a

2-digit number.

Enroll

[*][8][Installer Code][804] subsection [000].

wireless

Note: An HSM2HOST or RF keypad must be

devices

enrolled first.

Program

Basic programming:

[*][8][installer code]

[001]/[002]> Zone Type/Zone Attribute

[005]>[001] Partition 1 Timers:

– Entry Delay 1

– Entry Delay 2

– Exit Delay

[301]>[001] Phone #1

[310]>[000] System Account Code

Test

Test the panel completely to ensure that all

features and functions operate as programmed.

– [901] Walk Test

– [904][000] Wireless Placement Test

WARNING: This manual contains information on limitations regarding product use and function and information on the

limitations as to liability of the manufacturer. The entire manual should be carefully read.

Compatible Devices

Throughout this document, x in the model number represents the operating frequency of the device

as follows: 9 (912-919 MHz), 8 (868MHz), 4 (433MHz).

NOTE: Only models operating in the band 912-919 MHz are UL/ULC listed where indicated. Only

approved devices are to be used with UL/ULC listed systems.

Table 1-1 Compatible Devices

Wireless keypads:

Hardwired keypads with 2-way wireless

integration module:

Hardwired keypads:

2-way wireless integration module:

8-zone expander:

8-output expander:

Power supply:

4 high current output expander:

Alternate communicator:

2-wire smoke detectors:

x= A, B, or C

A: ULC listed models

B: UL listed models

C: European and Australian models

4-wire smoke detectors:

x= A, B, or C

A: ULC listed models

B: UL listed models

C: European and Australian models

CO detectors:

Wireless PG smoke detectors:

Wireless PG CO detector:

Wireless PG PIR motion detectors:

Wireless PG glass break detector:

Wireless PG shock detector:

Wireless PG flood detector:

Wireless PG temperature detector (indoor use):

Outdoor temperature probe (requires PGx905)

Wireless PG keys:

Wireless PG sirens:

Wireless PG repeater:

Wireless PG door/window contacts:

SG-System I, II, III, IV

PC5003C, PC4050CR (ULC Fire Monitoring), PC4050CAR (UL Commercial Burg),

CMC-1(UL Commercial Burg)

Other enclosures are available to suit a variety of system configurations.

firealarmresources.com

Modules

HS2LCDWFx

HS2LCDWFPVx

HS2LCDWFPx

HS2LCDRFx

HS2ICNRFx

HS2LCDRFPx

HS2ICNRFPx

HS2LCD

HS2ICNP

HS2LCDP

HS2LED

HS2ICN

HSM2HOSTx

HSM2108

HSM2208

HSM2300

HSM2204

3G2080

TL2803G

3G2080R

TL2803GR

TL280

PCL-422

TL280R

Hardwired Devices

FSA-210x

FSA-210xR

FSA-210xT

FSA-210xRT

FSA-210xS

FSA-210xRS

FSA-210xST

FSA-210xRST

FSA-210xLST

FSA-210xLRST

FSA-410x

FSA-410xR

FSA-410xT

FSA-410xRT

FSA-410xS

FSA-410xRS

FSA-410xST

FSA-410xRST

FSA-410xLST

FSA-410xLRST

CO-12/24

FW-CO1224

12-24SIR

CO1224

FW-CO12

Wireless Devices

PGx926

PGx916

PGx913

PGx904(P)

PGx924

PGx984(P)

PGx934(P)

PGx994

PGx974(P)

PGx912

PGx935

PGx985

PGx905

PGTEMP-PROBE

PGx939

PGx938

PGx929

PGx949

PGx901

PGx911

PGx920

PGx975

PGx945

Central Station Receivers

Enclosures

Table of Contents

Summary of Contents for Tyco DSC PowerSeries neo

Page 1 Alarm Controller v1.0 Installation Guide This installation guide provides the basic wiring, programming and troubleshooting information required to install the PowerSeries Neo alarm controller. Use this guide in conjunction with the PowerSeries Neo Reference Manual available online from the DSC website at www.dsc.com. Available models: HS2016, HS2032, HS2064, HS2128. Quick Setup Compatible Devices Throughout this document, x in the model number represents the operating frequency of the device...
Page 2: Important Note
P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e Safety Instructions for Service Persons Terminal Descriptions The following terminals are available on the PowerSeries Neo alarm controller: Warning: When using equipment connected to the telephone network, always follow the basic safety instructions provided with this product.
Page 3 P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e Alarm Controller Current Calculation Maximum (Standby or Alarm) NOTE: If using a 12V, 14Ah battery, maximum AUX capacity for 24-hour standby is 470mA. PGM Wiring AUX (700mA max.
Page 4: Programming Methods
P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e Enrollment Use the keypad numbers to toggle options on or off. Sections requiring data input, such as phone numbers, display the full data in fields up to 32 characters long (LCD).
Page 5: Alternate Communicator Setup
P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e Assign Zone Types [*][2]Trouble Summary [001]>[001]-[128] > Every zone on the system must be assigned one of the following zone Trouble Detailed Trouble types:...
Page 6 P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e [02] Panel No Battery • Verify battery is connected. [02] Keypad 1-16 faults •...
Page 7: Specifications
P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e Power Supply Press [10] to determine specific trouble Trouble [10] Module Tamper Transformer: DSC PTD1640U Primary:120V, 60Hz Class II Trouble...
Page 8 Programming Directory This section provides a list of all available programming options in numerical order. To program, access Installer Programming mode by keying in [*][8][Installer Code]. Use the scroll keys to navigate through the menus or jump directly to a specific section by keying in a section number and pressing [*]. Programming consists of toggling on and off options in each section or by populating data fields.
Page 9 P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e 09 – Battery Low (✓) 3 – Not Used Holiday 3 021 –...
Page 10 P o w e r S e r i e s N e o I n s t a l l a t i o n G u i d e 06 – Module Battery Absent 04 – Periodic Test Transmission 381 Communicator Option 2 Keypads Restore (✓)
Page 11 Trademarks - This EULA does not grant You any rights in connection with any trademarks or service marks of DSC or its the Software and any related Hardware) and Digital Security Controls, a division of Tyco Safety Products Canada Ltd. (“DSC”), suppliers.
Page 12 Zone Record Zone Label Location Type Attribute Zone Label Location Type Attribute firealarmresources.com...
Page 13: System Account Code
P o w e r S e r i e s N e w I n s t a l l a t i o n G u i d e Module Record Module Type Slot Serial Number Module Type Slot Serial Number Wireless Device Record...
Page 14: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT on this product’s listings please also refer to the official listing guides published at the UL web site (www.ul.com) under Online Directions Section. CAUTION: Changes or modifications not expressly approved by Digital Security Controls could void your authority UL/ULC Residential Fire and Burglary Installations: to use this equipment.
Page 15: Limited Warranty
Aux Loading and Battery Selection HS2128/HS2064/HS2032/HS2016 UL Resi Burg UL Com Burg UL Resi Fire/ UL Home Health Care/ ULC Fire Monitoring Board current draw 50mA ULC Resi Burg ULC Resi Fire/ ULC Com Burg Max AUX (NSC) current loading 0.7A 0.7A 0.5A...
Page 16: Sia False Alarm Reduction Installations: Quick Reference
The trademarks, logos, and service marks displayed on this document are registered in the United States [or other countries]. Any misuse of the trademarks is strictly prohibited and Tyco International Ltd. will aggressively enforce its intellec- tual property rights to the fullest extent of the law, including pursuit of criminal prosecution wherever necessary. All trademarks not owned by Tyco International Ltd. are the property of their respective owners, and are used with permission or allowed under applicable laws.
