- Page 1 Ultra G2 SE Controller Quick Start Guide May 2022 Document Number: 8200-1995-05 Revision: C www.swhouse.com...
- Page 2 © 2022 Johnson Controls. All rights reserved. JOHNSON CONTROLS, TYCO and SOFTWARE HOUSE are trademarks of Johnson Controls.
- Page 3 ■ Up to 4 Access Control Modules (ACM-SE), or up to 32 IP-ACM Ethernet Door Modules. The iSTAR Ultra G2 SE is supported on C•CURE 9000 v2.90 SP4, and later, with firmware version 6.8.6 and higher. The iSTAR Ultra G2 SE is supported on C•CURE 9000 v2.50, and later, for Ultra mode only.
-
Page 4: Specifications And Requirements
• A fail-safe mechanism override must be installed at each card reader exit to allow people to leave the secure area in case of electromechanical device failure. • Disconnect all power before modifying any jumper settings or the wiring to, or within, the iSTAR Ultra G2 SE. - Page 5 Grounding ■ Ensure that the iSTAR Ultra G2 SE controller is properly connected to an earth ground at any of the ground studs. ■ Ensure that the shield wires (including the ACM-SE and GCM) are grounded to the nearest ground connection at one end of the cable.
- Page 6 Wiring Specifications and Components Table 2: iSTAR Ultra G2 SE and Components Wiring Specifications Signal From Shield Max Length RS-485 Comm, Data iSTAR Ultra RM and I/O Modules 4000 ft (1212m) G2 SE two wire Power iSTAR Ultra RM and I/O Modules...
- Page 7 Ultra G2 SE Enclosure Figure 1: iSTAR Ultra G2 SE Enclosure...
-
Page 8: Installation
Installation You can install the iSTAR Ultra G2 SE enclosure on a wall or on a uni-strut system using suitable user-supplied hardware. Alternatively, you can install the iSTAR Ultra G2 SE GCM and ACM-SE in a standard 19-inch rack system. - Page 9 General Control Module The General Control Module (GCM) is a general-purpose module which operates using a Linux operating system. Figure 2 displays the GCM board components. For more information on GCM board components, see the iSTAR Ultra G2 Installation and Configuration Guide . Figure 2: General Control Module Components...
-
Page 10: Access Control Module
ACM-SE. For more information on ACM board components, see the iSTAR Ultra G2 Installation and Configuration Guide . The iSTAR Ultra G2 SE ACM does not communicate with legacy iSTAR Ultra controllers running in iSTAR Pro mode. NOTE... - Page 11 Figure 4: Left-hand side of the ACM-SE...
-
Page 12: Wiegand Readers
Readers The iSTAR Ultra G2 SE is compatible with Wiegand readers, RS485 readers, and TST-100 readers. Wiegand Readers Figure 5 shows direct Wiegand signaling read head connections. Figure 5: Wiegand Readers RS485 Readers Figure 6 shows RS485 full duplex and half duplex reader connections.
