Electrical Components
1.2.3 PAPER FEED MOTOR
1.
Rear cover (
"Rear Cover")
2.
Paper feed motor [A] (
When installing the paper feed motor, make sure that the gear of the paper feed
motor holds the timing belt [B].
1.2.4 MAIN BOARD
1.
Rear cover (
"Rear Cover")
2.
Main board [A] (All
D537
x 1,
x 2)
s,
x 2, snap pin x 2)
4
SM
