RICOH Americas Corporation
Introduction
Model Type
Launch Date
S/N Configuration
Product Code
Brand/Model Name
Product Code
M022
M024
M026
M028
Product Concept
The MFP product lineup of Ricoh Group is being
focused in DLT MFPs at this moment, and Ricoh
Group has made a great success with this lineup,
as you know well. On the other hand, when seeing
the lineup from the viewpoint of LT MFP, we have
only one copier based BW MFP (D069) at this
moment and no color one. Regarding Printer-based
LT MFP, we have M018 series, but there is no
model in mid-high segment. From the viewpoint of
competition, we are facing the necessity of LT
MFPs which can compete in the market.
Ver.1.1
Product Support Guide
M022 / M024 / M026 / M028
Color MFP
12/01/2010
S72YMMXXXX
S73YMMXXXX
S74YMMXXXX
S75YMMXXXX
M022
M024
M026
M028
Lanier
LD130C
Aficio MP C300
LD130CSR
Aficio MP C300SR
LD140C
Aficio MP C400
LD140CSR
Aficio MP C400SR
Page 1 of 54
Subject to change without notice
Content ID# RFG46217
Ricoh
Savin
C230
C230SR
C240
C240SR
2/1/2011
