Scanner SP Mode
3.11.2 SP2-XXX (SCANNING-IMAGE QUALITY)
[Compression Level (Gray-scale)]
2021
Selects the compression ratio for grayscale processing mode (JPEG) for the
three settings that can be selected at the operation panel.
2021 1 Level 3 (Middle Image Quality)
2021 2 Level 2 (High Image Quality)
2021 3 Level 4 (Low Image Quality)
2021 4 Level 1 (Highest Image Quality)
2021 5 Level 5 (Lowest Image Quality)
[Compression ratio of ClearLight PDF]
2024
Selects the compression ratio for clearlight PDF for the two settings that can be
selected at the operation panel.
2024 1 Compression Ratio (Normal image)
2024 2 Compression Ratio (High comp image)
D086/D087
[5 to 95 / 40 / 1 /step ]
[5 to 95 / 50 / 1 /step ]
*CTL [5 to 95 / 30 / 1 /step ]
[5 to 95 / 60 / 1 /step ]
[5 to 95 / 20 / 1 /step ]
[5 to 95 / 25 / 1 /step ]
*CTL
[5 to 95 / 20 / 1 /step ]
