Summary of Contents for Ruijie Reyee NBS3100-24GT4SFP-P
- Page 1 Ruijie Reyee RG-NBS3100-24GT4SFP, NBS3100-24GT4SFP-P, NBS3100-8GT2SFP, NBS3100-8GT2SFP-P Series Switches Installation Guide Document Version: V1.3 Date: May 8, 2024 Copyright © 2024 Ruijie Networks...
- Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
- Page 3 This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support The official website of Ruijie Reyee: https://reyee.ruijie.com Technical Support Website: https://reyee.ruijie.com/en-global/support Case Portal: https://www.ruijienetworks.com/support/caseportal Community: https://community.ruijienetworks.com Technical Support Email: service_rj@ruijienetworks.com...
- Page 4 Note This manual provides installation steps, troubleshooting, technical specifications, and usage guidelines for cables and connectors. It is intended for users who want to understand the above and have extensive experience in network deployment and management, and assume that users are familiar with related terms and concepts.
- Page 5 Contents Preface ..............................I 1 Product Overview ..........................1 1.1 RG-NBS3100-24GT4SFP ......................1 1.1.1 Technical Specifications ....................1 1.1.2 Product Appearance ...................... 2 1.1.3 Heat Dissipation ......................4 1.1.4 LED ..........................4 1.2 RG-NBS3100-24GT4SFP-P ...................... 4 1.2.1 Technical Specifications ....................4 1.2.2 Product Appearance ......................
- Page 6 2.1 Safety Suggestions ........................17 2.1.1 Installation ........................17 2.1.2 Movement ........................17 2.1.3 Electricity ........................17 2.1.4 ESD ..........................18 2.1.5 Laser ..........................18 2.2 Installation Site Requirements ....................18 2.2.1 Ventilation ........................19 2.2.2 Temperature and Humidity ................... 19 2.2.3 Cleanness ........................
- Page 7 4 System Commissioning ........................29 4.1 Establishing the Configuration Environment ................29 4.2 Startup ............................29 5 Troubleshooting ..........................31 5.1 Troubleshooting Flowchart ...................... 31 5.2 Troubleshooting Common Faults .................... 31 6 Appendix A Connectors and Connection Media ................33 7 Appendix B Mini-GBIC and SPF Module ..................
- Page 8 Flash Memory 16 MB SDRAM DDRIII 256 MB The copper cable is not supported. See Appendix B. Note Optical Module The supported module type may change at any time. Consult Ruijie Networks for the latest information. 1000Base-X SFP Port 100Base-X...
- Page 9 Installation Guide Product Overview AC input Rated voltage range: 100 V to 240 V Power Supply Maximum voltage range: 90 V to 264 V Frequency: 50/60 Hz Rated current: 0.6 A Input Leakage ≤ 3.5 mA Current Supported Not supported Power 21 W Consumption...
- Page 10 Installation Guide Product Overview Figure 1-1 Appearance of the RG-NBS3100-24GT4SFP Front Panel Figure 1-2 Front Panel of the RG-NBS3100-24GT4SFP Note: 1. System status LED 3. 10/100/1000 Base-T Ethernet port 2. Reset button 4. 1000Base-X SFP port 5. Nameplate on the bottom of the device Note ...
- Page 11 Status Blinking green The switch is being upgraded or (10 Hz) initialized. Solid green The switch is connected to Ruijie Cloud. The port is not connected. 10/100/1000Base-T The port is connected at a rate of Solid green Ethernet port status 1–24...
- Page 12 16 MB SDRAM DDRIII 256 MB The copper cable is not supported. See Appendix B. Note Optical Module The supported module type may change at any time. Consult Ruijie Networks for the latest information. 1000Base-X SFP Port 100Base-X AC input...
- Page 13 Installation Guide Product Overview Net Weight 4.5 kg Warning Operation of this equipment in a residential environment could cause radio interference. This equipment is not suitable for use in locations where children are likely to be present. Note The high temperature label indicates that the devie must be installed in the restricted area when the ambient temperature exceeds 50°...
- Page 14 Installation Guide Product Overview Note: 1. System status LED 4. 10/100/1000 Base-T Ethernet port 2. PoE mode switch-over button 5. 1000Base-X SFP port 3. Reset button 6. Nameplate on the bottom of the device Note The switch restarts after the reset button is pressed for less than 2 seconds. ...
- Page 15 Status Blinking green The switch is being upgraded or (10 Hz) initialized. Solid green The switch is connected to Ruijie Cloud. The port is not connected. 10/100/1000Base-T The port is connected at a rate of Solid green Ethernet port status 1–24...
- Page 16 16 MB SDRAM DDRIII 256 MB The copper cable is not supported. See Appendix B. Note Optical Module The supported module type may change at any time. Consult Ruijie Networks for the latest information. 1000Base-X SFP Port 100Base-FX Adapter input...
- Page 17 Installation Guide Product Overview Information Certification Earth Leakage ≤ 0.25 mA Current Dimensions 260 mm x 120 mm x 43.6 mm (W x D x H) Net Weight 1.2 kg Warning Operation of this equipment in a residential environment could cause radio interference. ...
- Page 18 The switch is not receiving power. Blinking green The switch is running, but is not connected to Ruijie Cloud. (0.5 Hz) System status LED Status Blinking green The switch is being upgraded or (10 Hz) initialized. Solid green The switch is connected to Ruijie Cloud.
- Page 19 SDRAM DDRIII 256 MB See Appendix B. The copper cable is not supported. Optical Module Note The supported module type may change at any time. Consult Ruijie Networks for the latest information. 1000Base-X SFP Port 100Base-FX AC input Rated voltage range: 100 V to 240 V...
- Page 20 Installation Guide Product Overview does not support PoE. The overall maximum output power of PoE/PoE+ is 125 W. PoE Power Pins Mode A (1/2+, 3/6-) 11W with no PoE load; Power Consumption 145W with PoE full load Operating temperature: 0° C to 50° C (32° F to +122° F) Temperature Storage temperature: -40°...
- Page 21 Installation Guide Product Overview Figure 1-11 Appearance of the RG-NBS3100-8GT2SFP-P Front Panel Figure 1-12 Front Panel of the RG-NBS3100-8GT2SP-P Note: 1. System status LED 5. 10/100/1000 Base-T Ethernet port 2. Port mode LED 6. Copper port status LED 3. PoE mode switch-over button 7.
- Page 22 System status LED Status Blinking green The switch is being upgraded or (10 Hz) initialized. Solid green The switch is connected to Ruijie Cloud. Switching mode. Port mode LED LED Mode Solid green PoE mode. The port is not connected.
- Page 23 Installation Guide Product Overview Panel Identification State Meaning Blinking green The port has a PoE fault of overload. The port is not connected. The port is connected at a rate of SFP port status Solid green 9F–10F 100/1000 Mbps. The port is receiving or transmitting Blinking green traffic at a rate of 100/1000 Mbps.
- Page 24 Installation Guide Preparation before Installation Preparation before Installation Safety Suggestions To avoid personal injury and device damage, carefully read the safety suggestions before you install the RG-NBS3100 series. Caution The following safety suggestions do not cover all possible dangers. 2.1.1 Installation ...
- Page 25 Installation Guide Preparation before Installation supplies, the leakage current of each power supply is equal to or less than 1.5 mA, and the total leakage current of the system is 30 mA. A leakage protector with 30 mA rated action current supports less than ten power supplies (that is, action current of the leakage protector/2/maximum leakage current of each power supply = 30/2/1.5 = 10).
- Page 26 Installation Guide Preparation before Installation 2.2.1 Ventilation For the RG-NBS3100 series, a sufficient space (at least 10 cm distance from both sides and the back plane of the cabinet) should be reserved at the ventilation openings to ensure normal ventilation. After various cables have been connected, they should be arranged into bundles or placed on the cabling rack to avoid airflow blocking.
- Page 27 Installation Guide Preparation before Installation Particles/ Diameter ≥ 0.5 μm ≤ 3.5×10 Particles/ Diameter ≥ 5 μm ≤ 3×10 Apart from dust, the salt, acid, and sulfide in the air in the equipment room must also meet strict requirements. This is because such poisonous substances may accelerate the corrosion of the metal and the aging of some parts.
- Page 28 Installation Guide Preparation before Installation Caution Effective grounding of the switch guarantees surge protection and interference resistance. Therefore, connect the grounding line of the switch properly. Safety Grounding The device using AC power supply must be grounded by using the yellow/green safety grounding cable. Otherwise, when the insulating resistance decreases the power supply and the enclosure in the equipment, electric shock may occur.
- Page 29 Installation Guide Preparation before Installation Note The lightning line banks are not provided and should be purchased by customers as required. 2.2.7 Electro-Magnetic Interference (EMI), from either outside or inside the device or application system, affects the system in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation. There are two types of electromagnetic interference: radiated interference and conducted interference, depending on the type of the transmission path.
- Page 30 Installation Guide Product Installation Product Installation Installation Flowchart Confirmations Before Installation Before installation, confirm the following points: Check whether ventilation requirements are met for the switch. Check whether the requirements of temperature and humidity are met for the switch.
- Page 31 Installation Guide Product Installation Check whether power cables are already laid out and whether the requirements of electrical current are met. Check whether related network adaption lines are already laid out. Installing the RG-NBS3100 Precautions During installation, note the following points: ...
- Page 32 Installation Guide Product Installation Figure 3-2 Attaching the Mounting Bracket to the 24-Port Switch Step 2: Use the supplied M6 screws and cage nuts to securely attach the mounting brackets to the rack, as shown in Figure 3-3, Figure 3-4, Figure 3-5, and Figure 3-6. Figure 3-3 Attaching the Brackets to the Rack (8-Port Switch) Figure 3-4...
- Page 33 Installation Guide Product Installation Figure 3-6 Attaching the Brackets to the Rack (24-Port Switch) 3.3.2 Mounting the Switch on a Table Attach the four rubber pads to the recessed areas on the bottom of the switch, as shown in Figure 3-7 and Figure 3-8.
- Page 34 Installation Guide Product Installation Determine the sectional area of the grounding wire according to the possible maximum current, and use cables of the good conductor. Do not use bare wires. The grounding electric resistance should be less than 1 Ω. Caution ...
- Page 35 Installation Guide Product Installation Checking After Installation Caution Before checking the installation, switch off the power supply so as to avoid any personal injury or damage to the component due to connection errors. Check that the ground line is connected. ...
- Page 36 Installation Guide System Commissioning System Commissioning Establishing the Configuration Environment Establishing the Configuration Environment Use the network cable to connect a PC to the switch. Figure 4-1 Configuration Environment Connecting the Console Cable Connect the one end (RJ45 port) of the network cable to the network port of the PC. ...
- Page 37 Installation Guide System Commissioning The console cable is correctly connected; the PC is already started; parameters are configured. Checking After Power-on (Recommended) After power-on, you are advised to perform the following checks to ensure the normal operation of follow-up configurations.
- Page 38 Installation Guide Troubleshooting Troubleshooting Troubleshooting Flowchart Troubleshooting Common Faults Symptom Possible Causes Solution The management interface login A password is manually configured Press the reset button to restore the default password is but it is forgotten. settings. forgotten. Check whether the power socket is normal. The status LED is The power supply is not enabled, Check whether the power cable is correctly...
- Page 39 Installation Guide Troubleshooting frames. working mode of the connected switch. Switch the Rx and Tx ends of the optical The Rx and Tx ends are module. connected reversely. Replace the optical module with one of the The interconnected optical module The optical port matched type.
- Page 40 Installation Guide Appendix A Connectors and Connection Media Appendix A Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T supports adaptation of three rates and automatic MDI/MDIX crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m.
- Page 41 Installation Guide Appendix A Connectors and Connection Media For the optical fiber ports, select single-mode or multimode optical fibers for connection according to the fiber module connected. Figure 6-4 shows the connection schematic diagram. Figure 6-4 Optical Fiber Connections...
- Page 42 SFP modules (mini-GBIC module) and 10G SFP+ modules are available to cope with interface types of switch modules. You can select the mini-GBIC module to suit your specific needs. The models and technical specifications of some mini-GBIC and 10G SFP+ modules are listed below. For details, see Ruijie Transceiver Installation and Reference Guide.
- Page 43 Installation Guide Appendix B Mini-GBIC and SPF Module GE-SFP-LH40-S 1550TX/1310R M1550-BIDI MINI-GBIC-ZX50 1550 -SM1550 MINI-GBIC-ZX80 1550 -SM1550 MINI-GBIC-ZX10 1550 0-SM1550 GE-SFP-SX -9.5 GE-SFP-LX 1310 -9.5 SFP-MM850 -9.5 SFP-SM1310 1310 -9.5 Table 7-2 Models and Technical Specifications of the Mini-GBIC-GT Module Standard 1000Base-T SFP Type DDM (Yes/No)
- Page 44 Installation Guide Appendix B Mini-GBIC and SPF Module GE-SFP-SX-SM1550-BI 50/125 500 m GE-SFP-LX20-SM1310- 9/125 20 km BIDI GE-SFP-LX20-SM1550- 9/125 20 km BIDI GE-SFP-LH40-SM1310- 9/125 40 km BIDI GE-SFP-LH40-SM1550- 9/125 40 km BIDI MINI-GBIC-ZX50-SM155 9/125 50 km MINI-GBIC-ZX80-SM155 9/125 80 km MINI-GBIC-ZX100-SM15 9/125 100 km...
- Page 45 Installation Guide Appendix B Mini-GBIC and SPF Module GE-SFP-LH40-SM1550-BIDI Caution The BIDI modules must be used in pairs, for example, FE-SFP-LX20-SM1310-BIDI and FE-SFP-LX20-SM1550-BIDI are used together.
- Page 46 Installation Guide Appendix C Surge Protection Appendix C Surge Protection Installing the AC Power Arrester (Surge Protection Cable Row) The external surge protection cable row must be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch.
- Page 47 Installation Guide Appendix C Surge Protection Tools: cross or straight screwdriver, multimeter, and diagonal pliers Installation steps: (1) Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the framework of the Ethernet port arrester. Tear the other side of the protection paper for the double-sided adhesive tape and paste the Ethernet port arrester to the switch framework.
- Page 48 Installation Guide Appendix C Surge Protection the arresters on all connection ports for surge protection.
- Page 49 Installation Guide Appendix D Cabling Recommendations Appendix D Cabling Recommendations When RG-NBS3100 series switches are installed in standard 19-inch cabinets, cables are tied in the binding rack on the cabinet by the cabling rack, and top or bottom cabling is adopted according to the actual situation in the equipment room.
- Page 50 Installation Guide Appendix D Cabling Recommendations Route and bundle power, signal, ground cables separately. When the cables are close to each other, cross them. When power cables are parallel to signal cables, the distance between them must be 30 mm (1.18 in.).
- Page 51 Installation Guide Appendix D Cabling Recommendations Figure 9-3 Preventing Cable Ties from Being Tied within the Bend Wrap up unnecessary or excess cables and bind them to the appropriate rack position, where device operation is not affected and no damages occur to the device and cables during commissioning. ...
- Page 52 Installation Guide Appendix D Cabling Recommendations Bundle cables of the same type and running in the same direction into groups. Keep cables clean and straight. Cables should be tied according to the following table. Diameter of Cable Bundle (mm) Space Between Bundles (mm) 80 to 150 10 to 30...
- Page 53 Installation Guide Appendix E Site Selection Appendix E Site Selection The equipment room should be at least 5 km away from the heavy pollution source such as the smelter, coal mine, and thermal power plant, 3.7 km away from the medium pollution source such as the chemical industry, rubber industry, and electroplating industry, and 2 km away from the light pollution source such as the food manufacturer and leather plant.
