Quick
guide
3300/410 - 3300/401
-
3300/500
MINICAMERA AHD DAY & NIGHT
1/2.7" CON LED IR
DAY&NIGHT AHD MINICAMERA
1/2.7" LENS WITH IR L
IT
EN
|
www.urmet.com
IF YOU LOVE YOUR BUILDING

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3300/410 and is the answer not in the manual?

Questions and answers

Summary of Contents for urmet domus 3300/410

  • Page 1 Quick guide 3300/410 - 3300/401 3300/500 MINICAMERA AHD DAY & NIGHT 1/2.7” CON LED IR DAY&NIGHT AHD MINICAMERA 1/2.7” LENS WITH IR L www.urmet.com IF YOU LOVE YOUR BUILDING...
  • Page 2 Quick Guide MINICAMERA AHD DAY & NIGHT 1/2.7” CON LED IR DAY&NIGHT AHD MINICAMERA 1/2.7” LENS WITH IR PRECAUZIONI D’USO •Assicurarsi dell’integrità dell’apparecchio dopo averlo tolto dall’imballo. • Prima di effettuare qualsiasi operazione di pulizia o di manutenzione disinserire l’apparecchio dalla rete di alimentazione elettrica. Non usare prodotti spray per la pulizia dell’apparecchio.
  • Page 3 Caratteristiche tecniche 3300/410 Tipo di sensore: 4.0 Megapixel 1/2.7” Color CMOS Elemento sensibile: 2704 pixel (orizzontale) x 1528 pixel (verticale) Ottica: f 3,6 mm Risoluzione AHD/TVI/CVI: (AHD)4MP@15/25/30fps selezionabile anche 1080P@25/30fps ; (CVI) 4MP@25/30fps selezionabile anche 1080P@25/30fps (TVI) 4MP@15/25/30fps selezionabile anche...
  • Page 4: Ir Cut Filter

    Caratteristiche tecniche 3300/401 Tipo di sensore: 4.0 ;Megapixel 1/2.7” Color CMOS Elemento sensibile: 2704 pixel (orizzontale) x 1528 pixel (verticale) Ottica: AF2.7-12 mm Risoluzione AHD/TVI/CVI: (AHD)4MP@15/25/30fps selezionabile anche 1080P@25/30fps ; CVI) 4MP@25/30fps selezionabile anche 1080P@25/30fps (TVI) 4MP@15/25/30fps selezionabile anche 1080P@25/30fps Commutabile CVBS Si PAL/NTSC IR CUT FILTER:...
  • Page 5 Caratteristiche tecniche 3300/500 Tipo di sensore: 4.0 Megapixel 1/2.7” Color CMOS Elemento sensibile: 2704 pixel (orizzontale) x 1528 pixel (verticale) Ottica: 3.6 mm Risoluzione AHD/TVI/CVI: (AHD)4MP@15/25/30fps selezionabile anche 1080P@25/30fps ; (CVI) 4MP@25/30fps selezionabile anche 1080P@25/30fps (TVI) 4MP@15/25/30fps selezionabile anche 1080P@25/30fps Commutabile CVBS Si PAL/NTSC IR CUT FILTER:...
  • Page 6: Norme D'installazione

    Norme d’installazione • Evitare di puntare direttamente l’obiettivo contro il sole o contro luci intense, anche se la telecamera è spenta; il soggetto da riprendere non deve essere in controluce. • Evitare di puntare la telecamera verso oggetti riflettenti. • La presenza di alcuni tipi di luce (ad esempio fluorescente colorata) può falsare i colori.
  • Page 7 TASTO DI ACCESSO AL MENU LUNGO IL LEFT RIGHT CAVO DELLA TELECAMERA DOWN UTILIZZO DEL MENU La telecamera utilizza un menù a più livelli che consente di abilitare/disabilitare o variare le impostazioni. Una volta impartito il comando di accesso al menu apparirà a monitor la finestra iniziale di accesso.
  • Page 8 è composta l’apparecchiatura. QR Code Guida rapida e manuale completo del dispositivo sono scaricabili puntando al seguente QR code. Guida rapida e manuale completo sono altresì disponibili per il DOWNLOAD dal sito URMET nella sezione LIBRETTI DI ISTRUZIONE. 3300/401 3300/410 3300/500 DS3300-002D...
  • Page 9 Quick Guide MINICAMERA AHD DAY & NIGHT 1/2.7” CON LED IR DAY&NIGHT AHD MINICAMERA 1/2.7” LENS WITH Precautions • Make sure that the device is intact after removing it from the package. • Disconnect the device from the mains before cleaning or maintenance. Do not use spray products to clean the device.
  • Page 10 Technical specifications 3300/410 Sensor type: 4.0 Megapixel 1/2.7” Color CMOS Sensitive elements: 2704 pixel (orizzontale) x 1528 pixel (verticale) Lens: f 3,6 mm Resolution AHD/TVI/CVI: (AHD)4MP@15/25/30fps add selection 1080P@25/30fps ; (CVI) 4MP@25/30fps add selection 1080P@25/30fps (TVI) 4MP@15/25/30fps add selection 1080P@25/30fps...
  • Page 11 Technical specifications 3300/401 Sensor type: 4.0 Megapixel 1/2.7” Color CMOS Sensitive elements: 2704 pixel (orizzontale) x 1528 pixel (verticale) Lens: AF2.7-12 mm Resolution AHD/TVI/CVI: (AHD)4MP@15/25/30fps add selection 1080P@25/30fps ; (CVI) 4MP@25/30fps add selection 1080P@25/30fps (TVI) 4MP@15/25/30fps add selection 1080P@25/30fps CVBS switch YES PAL/NTSC IR CUT FILTER: Synchronization:...
  • Page 12: Accessories Provided

    Technical specifications 3300/500 Sensor type: 4.0 Megapixel 1/2.7” Color CMOS Sensitive elements: 2704 pixel (orizzontale) x 1528 pixel (verticale) Lens: f 3,6 mm Resolution AHD/TVI/CVI: (AHD)4MP@15/25/30fps add selection 1080P@25/30fps ; (CVI) 4MP@25/30fps add selection 1080P@25/30fps (TVI) 4MP@15/25/30fps add selection 1080P@25/30fps CVBS switch YES PAL/NTSC IR CUT FILTER:...
  • Page 13: Installation Specifications

    Installation specifications • Avoid pointing the lens directly towards the sun or intense sources of light also when the camera is off. The subject must not be backlight. • Do not point the camera towards reflecting objects. • Some lighting systems (e.g. coloured fluorescent lights) may false the colours. •...
  • Page 14 MENU ACCESS BUTTON ON THE CAMERA CABLE RIGHT LEFT DOWN USING THE MENU The camera uses a multi-level menu that allows you to enable/disable or change settings. Once the menu access command is given, the OSD menu will appear on the monitor. Using the arrow keys, navigate through the menus and select your preferred options.
  • Page 15 Quick guide and complete user manual of the product are available at the following QR code. Quick guide and complete user manual of the product are also available for DOWNLOAD from the URMET website under the section USER MANUALS. 3300/401 3300/410 3300/500...
  • Page 16 Customer Care Italia: 011 23 39 810 Export Dept.: +39 011 24 00 250/256 URMET S.p.A. Via Bologna, 188/C | 10154 Torino (ITALY) www.urmet.com | info@urmet.com MADE IN CHINA IF YOU LOVE YOUR BUILDING DS3300-002D...
