- Page 1 ARCEUS ELECTRIC COMBI BOILER ARCEUS 6-9-12-15-18-24-27 kW MT / CH / ST USER AND INSTALLATION MANUAL...
- Page 2 Building Regulations and the Benchmark Commissioning Checklist Building Regulations (England & Wales) require notification of the installation of a heating appliance to the relevant Local Authority Building Control Department. This can be achieved via a Competent Persons Self Certification Scheme as an option to notifying the Local Authority directly.
-
Page 3: Table Of Contents
INDEX 1- INTRODUCTION......................2- DEFINITION of SYMBOLS.................... 3- SAFETY RULES AND WARNINGS................4- REGULATIONS......................5- USEFUL INFORMATION on PRODUCT............... 6- PRODUCT INFORM...................... 6.1- Packaging........................6.2- Main Components and Describtion................6.3- Boiler Features......................6.4- Technical Data......................6.5- ERP Technical Data....................6.6- Package Label Calculations..................7- INSTALLATION...................... -
Page 4: 1-Introduction
1-INTRODUCTION First of all, we would like to thank you for choosing E.C.A brand. E.C.A. Confeo Premix condensing boilers have been designed to meet for an efficient, safe and comfortable central heating and hot water requirement. MT Model (Boiler) : Both Central Heating (CH) and Domestic Hot Water (DHW). CH Model (Heat Only) : Only for Central Heating (CH). -
Page 5: 2-Definition Of Symbols
2-DEFINITION OF SYMBOLS SYMBOL DEFINITION SYMBOL DEFINITION Ø Domes�c Hot Water Diameter Flame Parameter Adjustment Reset Domes�c Hot Water Nega�ve Temperature Winter Mode Coefficient (sensor) Summer Mode Residual Current Device ECO Mode Emergency ControlValve Comfort Mode Table 2. Definition of Symbols and Abbreviation SYMBOL DEFINITION Indicates that the situation that can only be interfered by authorized... -
Page 6: 3-Safety Rules And Warnings
3-SAFETY RULES AND WARNINGS 3.1 Water Systems Before installation of the boiler and the water systems (CH & DHW circuit) must be completed in accordance with the relevant regulations and standards by installer. 3.2 Installation The boiler must be installed in accordance with national and local requirements, relevant standarts and this manual by authorized engineer. -
Page 7: 4-Regulations
CAUTION: If boiler is used incorrectly or for other than its intended use, it may present a life hazard and may cause material damage to the product and its surroundings. CAUTION: The boiler must be transported and lifted by at least 2 people due to heavy weight. -
Page 8: 5-Useful Information On Product
5-USEFUL INFORMATION ON PRODUCT 5.1 Efficient Use of the Combi Boiler in Terms of Safety and Energy Consumption Isolation of your building is extremely important. Energy saving is achieved at a considerable degree since the heat loss is lowest in houses with double-glazed windows and insulated walls. ... -
Page 9: 6- Product Inform
6-PRODUCT INFORMATION 6.1 Packaging CAUTION: Attention must be paid to warning on packaging regarding handling and storage. The boiler is delivered with a cartonboard with dimensions of 735 x 345 x 490 (HxWxD) mm, supporte d by upper and lower styrofoams. Figure 1. - Page 10 Figure 3. MT Isolating Valve Kit VALVE KIT PACKAGE LIST 1. Valve Fixing Bracket (1pc) 6. CH Return Manifold Valve (1pc) 2. CH Supply Manifold Valve (1pc) 7. Wras Approved Filling Loop (1 pc) 3. DHW Outlet Manifold Valve (Elbow) (1pc) 8.
- Page 11 Figure 4. Isolating Valve Kit VALVE KIT PACKAGE LIST 1. Valve Fixing Bracket (1pc) 5. CH Return Manifold Valve (1 pc) 2. CH Supply Manifold Valve (1pc) 6. Manometer (1pc) 3. 3 Bar Safety Valve Connection Pipe (1pc) 7. Cover Sheet (1 pc) 4.
-
Page 12: Main Components And Describtion
6.2 Main Components and Description 6.2.1 MT Model (Boiler) Resistors Overh eat Thermostat Air Purge Terminal Blocks Expansion Vessel Cir cuit Breaker Contactor Neutral Busbar Relay Boards Drain Valve Immersion Type NTC Pressure Sensor Flow Sensor 3 Way Valve Circula�on Pump Flow Manifold Pressure Relief Valve Figure 5. - Page 13 Wras Approved Filling Loop CH Return CH Supply BS Stop Valve Fixed spindle type Water main Figure 6. Installation for MT Boiler 6.2.2 ST Model (System Boiler) Resistors Overheat Thermostat Air Purge Terminal Blocks Circuit Breaker Contactor Relay Boards Drain Valve Pressure Sensor Pressure Relief Valve Flow Manifold...
- Page 14 Figure 8. Installation for ST Boiler **External WRAS appoved filling loop must be added during installation. 6.2.3 CH Model Resistors Overheat Thermostat Air Purge 22-Flue Gas Sensor Expansion Vessel Terminal Blocks Circuit Breaker Contactor Relay Boards Drain Valve Pressure Sensor Flow Manifold Pressure Relief Valve Circula�on Pump...
- Page 15 Expansion Vessel Figure 10. Installation for CH Boiler (Heat Only Type Installation) **External WRAS appoved filling loop must be added during installation. Expansion Vessel CH Return BS Stop Valve Wras Approved CH Supply Fixed spindle type Filling Loop** Water main Figure 11.
-
Page 16: Boiler Features
6.3 Boiler Features Control panel is ergonomic and easy to use. The Confeo Premix condensing boiler with elegant plastic control panel and advanced LCD screen provides ease of use and service. On a LCD display with black instrument panel; you can see the operating state icons, heating circuit and operating water adjustment values, the fault / failure codes and the heating water pressure. -
Page 17: Technical Data
6.4 Technical Data Table 7. Technical Table *It’s recommended to adjust CH temperature set value above 40°C if you don’t use room thermostat. **It’s not recommended to use DHW flow rate below 2,5 l/min for stable DHW usage. ****... -
Page 18: Erp Technical Data
6.5 ERP Technical Data ARCEUS Combi ERP Units MT Model Supplier's name or trademark E.C.A. Arceus 12 Arceus 15 Arceus 18 Arceus 24 Arceus 27 Supplier's model identifier Space Heating-Temperature application Medium Seasonal Space Efficiency heating Class Domestic Hot Water Heating Efficiency* Water Heating Load Profile* 11,9... -
Page 19: Package Label Calculations
6.6 PACKAGE LABEL CALCULATIONS Package fiche for boilers indicating the space heating energy efficiency of the package 6.6.1 Package Fiche-Boilers Seasonal space heating energy efficiency of boiler “T”: The value of the seasonal space heating energy efficiency of the preferential space heater, expressed in %. Class I = 1%, Class II = 2%, Class III = 1.5%, Temperature Control Class IV = 2%, Class V = 3%, Class VI = 4%,... - Page 20 Supplementary Heat Pump from fiche of heat pump ''II' : The factor for weighting the heat output of preferential and supplementary heaters of a package as set out in the following table. Seasonal space heating energy efficiency (in %) - 'T ') x 'II' = Solar Contribution and Supplementary Heat Pump select smaller value...
- Page 21 Solar Contribution Auxillary electricity from fiche of solar device ( 1.1 x 'I' - 10 % ) x 'II' - 'III' - 'I' = + Water Heating Energy Efficiency of Package under Average Climate Water Heating Energy Efficiency Class of Package under Average Climate Water Heating Energy Efficiency under Colder and Warmer Climate Conditions Colder: - 0.2 x...
-
Page 22: 7- Installation
7- INSTALLATION 7.1 Selection of Location of Boiler The boiler must be installed in accordance with relevant standards. Additionally, the clearance around the boiler should be as shown in fig 12. In order to make service, maintenance and usage easier. Figure 12: It shows the minimum distances required from the top and sides of the boiler (Dimensions given in mm). -
Page 23: Mounting The Boiler
7.2 Mounting The Boiler Having determined the boiler location, The points of lock screws of wall bracket and assembly bracket are marked by using the wall-mounting template provided with the boiler. After drilling the marked points, wall assembly bracket and assembly bracket are fixed on the wall by the dowel and lock screws, which are inside the packaging of the boiler. -
Page 24: 8-Connections
8-CONNECTIONS 8.1- Electrical Connection Your combi boiler must be connected to a grounded power line that can supply 230 VAC 50 Hz voltage for single-phase devices and 400 VAC 50 Hz voltage for 3-phase devices. Malfunctions caused by voltage fluctuations are not covered by the warranty DANGER: When making the electrical connection of the device, be sure that there is no voltage in the power line. -
Page 25: Water Connections
Supply Cord Nominal Supply Line Minimum Device Power Supply Current (A) Circuit Breaker Capacity Single-phase B32-1P ARCEUS 6 CH-ST Three-phase 5x2.5 B10-3P Single-phase 3x10 B40-1P ARCEUS 9 CH-ST Three-phase 5x2.5 B16-3P Single-phase 3x10 B63-1P ARCEUS 12 MT-CH-ST Three-phase B20-3P Single-phase 3x16 B80-1P ARCEUS 15... -
Page 26: Wiring Diagram
8.3 Wiring Diagram... -
Page 27: Room Thermostat
8.4 Room Thermostat Optional room thermostats compatible with your boiler can be used to control heating system and must be installed by a authorized engineer. E.C.A. On/Off Room E.C.A. On/Off Room E.C.A. Smart Combi Thermostat T6360 Thermostat T6360 Boiler Kit 7006901312 7006907804 7006907531... -
Page 28: Outdoor Sensor
8.5 Outdoor Sensor To connect the room thermostat or outdoor sensor to the boiler, the connections behind the control panel are used. For the room thermostat, the bridged cable connection on the back of the control panel is removed and the outer air sensor is connected to free sockets on the terminal. ... -
Page 29: Controller Connections
8.6 Controller Connections MAINBOARD MAINBOARD DETAIL B DETAIL A Timer cable connections are Boiler sensor cable connections The solar system connection The outdoor air sensors In order to connect the room connected to the corresponding are connected to the cables are connected to the cables are installed by thermostat, the bridge seen terminal points. -
Page 30: Electrical Connections With Zone Valves
8.7 Electrical Connections with Zone Valves Volt Free Contact Figure 16. 2 Port Zone Valve 1- Remove the front panel. 2- Hinge down the control box. 3- Remove the link between terminals 1 and 2. 4- Use volt free contacts (Room Thermostat contacts) to install a system with zone valves. CAUTION : Boiler has only volt free contact for switcing. -
Page 31: 9- Comissioning
9- COMISSIONING 9.1 Comissioning, Filling Water into Boiler and Heater Installation First of all, the electrical connection of the boiler is done. The electrical connection of the boiler must be Connected to a grounded power supply line that can supply enough voltage (230 VAC, 50 Hz) for the boiler. ... -
Page 32: 10-Using The Boiler
Call authorized engineer to start up the boiler after all these processes are completed. Commissioning must be strictly performed by authorized service. At the end of the commissioning of the boiler after installation, please ask for information of authorized engineer on operating the boiler and relevant safety devices on boiler. -
Page 33: Functions Of Buttons
11.1 Functions of Buttons The control panel consists of the relevant elements as shown in figure 24 below. Bu�on Bu�on Number Name Func�on - Increases central hea�ng set temperature - Increases password value at parameter menu entry CH Plus - Increases parameter value - Indicates informa�on value - Indicates error history value - Reduces central hea�ng set temperature... -
Page 34: Lcd Screen
11.2 – LCD Screen LCD screen display icons described here below. Temperature Flame Icon Domestic Water Parameter Setting Heating Indicator Centr al H eating Reset Pressure Display Figure 19. Description of Symbols 10.3- Operation Modes: 10.3.1- Standby Mode (Off Mode): It is the mode in which the device can be set to standby mode. In this mode, central heating and domestic water heating demands cannot be met. -
Page 35: 12-Error Codes And Description
The power supply of the device must be on. The radiator valves must be open. The system water pressure must be appropriate. The freeze protection function helps protect your device but does not protect your installation. If the device is not to be operated in places where there is a risk of freezing, it is necessary to drain the water or use an anti-freeze agent. -
Page 36: 13-Warranty And Service
The water pressure parameter FP11 is at a low level. This error is displayed if the water pressure is less than FP11/10 Low Water Pressure bar. When the water pressure is greater than (FP11/10+0.4 bar), the error is automatically cleared. This error is displayed if the outdoor temperature sensor is short or Outdoor Temperature open circuit, or damaged. - Page 37 TERMS AND CONDITIONS FOR WARRANTY of ECA Boiler: 1.The appliance has warranty period against product failures in condition that the instructions and precautions in the documents delivered with the product are obeyed. These documents are operating- installation manual and service (includes maintenance operation) manual. The warranty period will not be extended in case of repairing or replacing any product or part.
- Page 38 k.The boilers which are not installed and set up strictly in line with the installation instructions supplied with them (including the requirement to clean the system and add corrosion inhibitor in line with BS7593:1992). l.where spare parts other than E.C.A. parts have been used in any service or repair. In this case, the warranty for such products is not valid furthermore.
- Page 39 We reserve the right to update or amend these Terms and Conditions at any time and its decision in relation towarranty claims shall be final. Your guarantee is provided to you by ARD London (registered in England with company number +44 800 640 9988 or +44 20 3978 1212) of Guarantor –...
-
Page 40: 14-Annexes
14-ANNEXES 15.1 Characteristic Curve of Water Pressure Height of The Pump (Pump Head- Flow Rate) Graph 2... -
Page 41: 15- Spare Part List Comissioning
15-SPARE PART LIST EXPANSION VESSEL MOTORIZED VALVE PLATE HEAT EXCHANGER 6 KW HEATER RESISTOR 9 KW HEATER RESISTOR 7006907924 7006902880 7006991264 7006250004 7006250005 WATER PRESSURE SENSOR IMMERSION TYPE NTC SURFACE TYPE NTC SAFETY VALVE FLOW SENSOR GROUP 7006952680 7006995165 7006907505 7006990316 7006985271 18A CONTACTOR... -
Page 42: Checklist
ELECTRIC BOILER SYSTEM COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the boiler as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty. -
Page 43: Service Record
SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. SERVICE 01 SERVICE 01 Date:... - Page 44 Organ�ze Sanay� Bölges� 3. Kısım Mustafa Kemal Bulvarı No:13 45030 MANİSA + 90 236 213 00 21 + 90 236 213 08 59 SALES & TECHNICAL SUPPORT Call Center Tel:+44 800 640 9988 O ce Tel : +44 203 978 1212 QR code Act�vat�ng your quarantee �s qu�ck and s�mple , but really �mportant!
