QLS250, QLS450, QLS650, and
QLS800

General Requirements for Racks

Check Point appliances are designed for a standard 19-inch (48.26 cm) rack (see specification EIA-310-D).
The telescopic rails are designed for racks with these specifications:
Minimum Depth
22 inches (55.9 cm)
24 inches (61 cm)
Front and rear rack doors must have equally distributed holes on at least 65% of the surface area to give
sufficient airflow. Make sure that the racks have sufficient clearance to service the Check Point appliances
that are mounted on telescopic rails.
Rack
Clearance Requirement
Side
Front 36 in (91.4 cm) plus additional clearance, if necessary, for the mechanical lift used to move
the appliance and rails equipment.
Rear 16 in (40.6 cm) from the rear of the rack or appliance without the rear cabinet door.
22 in (55.9 cm) from the rear of the rack or appliance with the rear cabinet door.
These are the physical specifications of the LightSpeed Appliances:
Security Appliance
QLS250
QLS450, QLS650, and QLS800

Telescopic Rails Hardware

Important - To prevent injury or damage, at least two people are required to install the
appliance in a rack.
Rack Mounting Tools
We recommend that you use a Phillips PH2 screwdriver with a magnetic head to hold and retrieve screws.
Maximum Depth
32 inches (81.3 cm)
36 inches (91.4 cm)
Width
442 mm
442 mm

QLS250, QLS450, QLS650, and QLS800

Depth Height
610 mm 88 mm
610 mm 132 mm
Rack Mounting for Check Point Appliances | 6
U
2U
3U
