- Page 1 24 August 2022 INSTALLING AND REMOVING AC POWER SUPPLY UNITS IN CHECK POINT APPLIANCES...
- Page 2 Check Point. While every precaution has been taken in the preparation of this book, Check Point assumes no responsibility for errors or omissions. This publication and features described herein are subject to change without notice.
- Page 3 Web browser. Download the latest version of this document in PDF format. Feedback Check Point is engaged in a continuous effort to improve its documentation. Please help us by sending your comments. Revision History Date Description 24 August 2022...
-
Page 4: Table Of Contents
Installing a Power Supply Unit Installing the Power Supply Cable Restraint PSU Configuration and Monitoring TE250XN Removing a Power Supply Unit Installing a Power Supply Unit Using the Power Cable Restraint Clip Installing and Removing AC Power Supply Units in Check Point Appliances | 4... -
Page 5: Introduction
Appliance In This Document Quantum LightSpeed Appliance QLS250 QLS250 Quantum LightSpeed Appliance QLS450 QLS450 Quantum LightSpeed Appliance QLS650 QLS650 Quantum LightSpeed Appliance QLS800 QLS800 SandBlast Threat Emulation TE250XN TE250XN Installing and Removing AC Power Supply Units in Check Point Appliances | 5... -
Page 6: Qls250, Qls450, Qls650, And Qls800
Important - Make sure you are electromagnetically grounded before you install, uninstall, or replace a PSU. ESD (electrostatic discharge) can damage the appliance. QLS250 Rear Panel QLS450, QLS650, and QLS800 Rear Panel Installing and Removing AC Power Supply Units in Check Point Appliances | 6... - Page 7 Blinking fast green - PSU undergoing Firmware update Restraint strip slot Extractor handle ESD grounding point Alarm off button for PSUs Release lever QLS250 - Two AC PSUs QLS450, QLS650, and QLS800 - Three AC PSUs Installing and Removing AC Power Supply Units in Check Point Appliances | 7...
-
Page 8: Removing A Power Supply Unit
Before you remove a Power Supply Unit, we recommend that you make sure that: In QLS250 - A second AC power supply is installed and connected to a working power source. In QLS450, QLS650, and QLS800 - Two other AC power supplies are installed and connected to a working power source. -
Page 9: Installing A Power Supply Unit
2. Push in the PSU until the release lever clicks. 3. Insert the power supply cable into the power supply socket. 4. Make sure that the power LED is lit up. Installing and Removing AC Power Supply Units in Check Point Appliances | 9... -
Page 10: Installing The Power Supply Cable Restraint
Use the power supply cable restraint to prevent accidental removal of the power supply cable. Item Description Restraint anchor Cable loop Restraint strip tab Restraint strip Legend Item Description Restraint strip slot Power supply socket Installing and Removing AC Power Supply Units in Check Point Appliances | 10... - Page 11 9. Make sure the cable loop is secured and the power supply cable cannot be removed while the cable loop is in place (see the line drawing after the procedure). Restraint strip anchor inserted into the slot Cable loop secured around the power supply cable Installing and Removing AC Power Supply Units in Check Point Appliances | 11...
-
Page 12: Psu Configuration And Monitoring
QLS250, QLS450, QLS650, and QLS800 PSU Configuration and Monitoring See the Getting Started Guide for PSU configuration and monitoring options: Quantum LightSpeed Appliances Getting Started Guide Installing and Removing AC Power Supply Units in Check Point Appliances | 12... -
Page 13: Te250Xn
Alarm Off If a power supply cable is not connected to the outlet, an alarm sounds button continuously. Press this button to turn off the alarm for the PSU. Installing and Removing AC Power Supply Units in Check Point Appliances | 13... -
Page 14: Removing A Power Supply Unit
3. While holding the release lever, pull the extraction handle to remove the Power Supply Unit. Note - Remove the power supply unit only with the extraction handle to prevent any possible damage. Installing and Removing AC Power Supply Units in Check Point Appliances | 14... -
Page 15: Installing A Power Supply Unit
2. Push in the power supply unit until the release lever clicks. 3. Insert the power supply cable into the power supply socket. 4. Make sure that the power LED is lit up. Installing and Removing AC Power Supply Units in Check Point Appliances | 15... -
Page 16: Using The Power Cable Restraint Clip
To secure the restraint clip on the power supply cable: 1. Make sure the restraint clip is in the open position (facing upward) and connect the power supply cable to the power supply socket on the PSU. Installing and Removing AC Power Supply Units in Check Point Appliances | 16... - Page 17 2. Push down on the restraint clip to close it and secure the power supply cable. Legend Item Description Restraint clip in the open position (facing upward) Restraint clip in the closed position Installing and Removing AC Power Supply Units in Check Point Appliances | 17...
