Extract the provided Vienna PFC model zip file to: C:\Plexim.
FIGURE 2-1:
The zip file contains two folders: Projects and Component Models. The Projects folder
contains a subfolder for the Vienna PFC reference design. Future reference designs
will be added to this folder. Within the Vienna-PFC folder are subfolders containing
support files, including source code for running Processor-In-the-Loop. The
Component Models folder contains the thermal descriptions for the Microchip SiC
Schottky barrier diode and SiC MOSFET used in the Vienna PFC reference design.
FIGURE 2-2:
2020 Microchip Technology Inc.
Chapter 2. Folder Structure
Extracting Compressed Folders.
Folder Structure.
PLECS MODEL
QUICK START GUIDE
FOR VIENNA PFC
DS50002997A-page 10
