Task Force Tips QuadraFog Series Maintenance And Service Instructions page 5

Always perform NFPA 1962 operational testing and the Operation and Inspection Checklist in the nozzle operator manual prior to
returning the nozzle to service.
6.5 QUADRACUP ASSEMBLY
1. Apply grease to the cam grooves in the GALLONAGE SLEEVE and to the I.D. of the HEAD.
2. Apply grease to the "V" FOLLOWERS and place each one into a CUP.
3. Slide HEAD over end of GALLONAGE SLEEVE.
4. Align the holes in the HEAD with cam grooves in the GALLONAGE SLEEVE.
5. Apply Loctite 271 to the cup assemblies and thread through the HEAD and into cam groove in the GALLONAGE SLEEVE.
6. Tighten until "V" FOLLOWERS make contact with cam groove in the GALLONAGE SLEEVE, then back out a 1/8 of a turn.
7. Rotate the head to make sure cup subassemblies are not threaded too tight. Loosen if needed.
8. Install greased O-RING in the groove on OD of the HEAD.
9. Apply grease to outside of the HEAD, then slide the CUP on the HEAD making sure that holes in CUP line up with slots in HEAD.
10. Place a SPRING and TORLON BALL into each DETENT SCREW.
11. Begin screwing the Detent assemblies into the CUP.
12. Apply Loctite #271 to the remaining thread and continue to tighten the screws until flush with the CUP.
18
19
©Copyright Task Force Tips LLC 2001-2022
FLOW RATE PRESSURE
30 GPM
30 GPM
110 L/min
100 L/min
13
14
12
10
17
9
11
6
7
8
GAP SIZE
75 PSI .018" - .020"
100 PSI .040"
7 bar 1.0 mm
6 bar 1.0 mm
50
48
6
7
5
49
6
8
7
6 44
43
42
41
38
5
47
13
14
46
4
3 2
1
39
40
LKF-050 February 21, 2022 Rev06
