Dual Monitor Desk Mount with VESA Adapter Bracket
Instruction Manual
SKU: STAND-V002VA
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002va
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V002VA
Summary of Contents for Vivo STAND-V002VA
- Page 1 Dual Monitor Desk Mount with VESA Adapter Bracket Instruction Manual SKU: STAND-V002VA Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002va GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED 17.6 lbs DO NOT EXCEED WEIGHT CAPACITY. Per Arm Failure to do so may result in serious injury. (8kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Unscrew the hand crank of Clamp (B) to create an opening for the clamp to placed on desktop. STEP 2 OPTION A: Desk Clamp Install Install the Clamp (B) to the Pole (A) using M6x16 Screws (S-A) and tighten using 3mm Allen...
- Page 4 STEP 2 - Continued OPTION B: Grommet Installation Separate the Hand Crank (B1) from Clamp (B) by removing the screw with a Phillips screwdriver. Install Grommet Plate (E) to the Pole (A) using M6x16 Screws (S-A) and 3mm Allen Wrench (T-B). Attach Soft Pad (F) to the Grommet Plate (E). If desk does not have an existing grommet hole, drill a 3/8”...
- Page 5 STEP 3 Slide Pole Cable Clip (K) and Swivel Arm (C) onto Pole (A). Tighten Swivel Arm (C) at desired height using 6mm Allen Wrench (T-D). Insert Pole Cap (H) into top of Pole (A). Place Cable Clips (L) onto Swivel Arm (C).
- Page 6 STEP 5 (Continued) STEP 6 With all “L” Shaped Holders (J) facing up, place monitor on lower two holders and fully tighten lower two screws with a Phillips screwdriver. Turn top Holders down and tighten top screws, then tighten nuts for the upper arms. Install Plastic Covers (M) to cover screws.
- Page 7 STEP 7 Slide monitor assembly onto Swivel Arm (C) and secure with M6 Security Screw (S-B). Route cables through Arm Cable Clips (L) and Pole Cable Clip (K). STEP 8 To level monitors, remove M6 Security Nuts (S-B) and tighten or loosen adjustment screws using 3mm Allen Wrench (T-B).
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
