14. The update will start and should complete in less than 5 minutes.
15. After the update has finished, restart the system, and the process is complete.
Before using the camera, proceed to the scan head firmware update
section.
Only updating the camera firmware will result in neither the ZEB Vision or
the ZEB Horizon functioning correctly.

Updating Scan Head Firmware

Any ZEB Horizon must be updated to firmware version 2.2 or later to function with Vision
firmware 2.1. Once upgraded, the ZEB Horizon will now be ready for use with either a ZEB
Vision or ZEB Cam.
When updating this firmware, please ensure the scanner is connected to the datalogger
before the system is powered on.
Please follow the steps relating to the appropriate iteration your ZEB Horizon datalogger.
Information on how to distinguish which generation of datalogger you have, please consult
GeoSLAM Academy.

ZEB Horizon Generation 1 Datalogger

To update the ZEB Horizon 1
•
listener.zip.
•
settings.yaml.

Figure 7. Firmware update confirmation.

st
Generation Datalogger firmware the following files are required:
Page 8
