GeoSlam ZEB Vision Firmware Update Manual

Hide thumbs Also See for ZEB Vision:
Table of Contents

Advertisement

Quick Links

Download this manual
Firmware Update Guide
Instructions for firmware upgrades

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZEB Vision and is the answer not in the manual?

Questions and answers

Related Manuals for GeoSlam ZEB Vision

Summary of Contents for GeoSlam ZEB Vision

  • Page 1 Firmware Update Guide Instructions for firmware upgrades...
  • Page 2 GeoSLAM Ltd. GeoSLAM Ltd. provides this manual “as is,” without warranty of any kind and reserves the right to make improvements and/or changes to the product described in this manual at any time and without notice.

  • Page 3: Table Of Contents

    ZEB Horizon Generation 2 Datalogger ................9 List of Figures Figure 1. Updating the camera calibration file..............3 Figure 2. GeoSLAM Control Tool..................5 Figure 3. Control Selection....................5 Figure 4. Enter the camera IP address................. 6 Figure 5.

  • Page 4: Part 1 - Overview

    Part 1 – Overview This document provides information on the latest ZEB Vision firmware as well as instructions for applying the firmware. Part 2 – Vision Firmware Release Notes details the new features, improvements and issues resolved in the firmware. on the update, whilst Part 3 – Update Procedure provides step by step instructions on updating the firmware using the GeoSLAM Control Tool.

  • Page 5: Part 2 - Vision Firmware Release Notes

    GeoSLAM Control Tool v3.3.0. To update the calibration file on the camera: 1. With the ZEB Vision connected to the ZEB Horizon datalogger, power on the datalogger if not already powered on. 2. Connect the camera directly to a PC using the supplied ethernet cable.

  • Page 6: Led Indicator Status

    Select -> OK, at the confirmation prompt to continue. 9. Power cycle the system. Figure 1. Updating the camera calibration file. LED Indicator Status The ZEB Vision camera now gives more feedback during capture, please see the LED table below: Camera Status Description...

  • Page 7: Part 3 - Update Procedure

    Part 3 – Update Procedure All files required for the update process are available to download from the GeoSLAM website: • https://geoslam.com/getting-started-zeb-vision Download the update pack file to your PC and extract the ZIP file to a temporary directory. Download Package The update package contains all files necessary to update both the ZEB Horizon and ZEB Vision plus a copy of the Control Tool software to apply the updates.

  • Page 8: Figure 2. Geoslam Control Tool

    1. Connect the ZEB Horizon scanner to the datalogger using the main cable and power on the system as normal. 2. Connect the camera to a PC as outlined in the ZEB Vision User Guide. 3. Open -> GeoSLAM Control Tool (Figure 2).

  • Page 9: Figure 4. Enter The Camera Ip Address

    Figure 4. Enter the camera IP address. 8. Select -> OK, to continue. The camera should now be connected (Figure 5). Figure 5. Camera successfully connected. 10. Select -> Software -> Update -> Software Update (Figure 6). Page 6...

  • Page 10: Figure 6. Software Update

    Figure 6. Software update. 11. Select -> Yes, at the dialog to select to update the firmware. 12. Browse -> user defined location of the update file. a. Select -> OK, to continue. 13. Select -> Yes, to confirm the update (Figure 7). Page 7...

  • Page 11: Updating Scan Head Firmware

    15. After the update has finished, restart the system, and the process is complete. Before using the camera, proceed to the scan head firmware update section. Only updating the camera firmware will result in neither the ZEB Vision or the ZEB Horizon functioning correctly. Updating Scan Head Firmware Any ZEB Horizon must be updated to firmware version 2.2 or later to function with Vision...

  • Page 12: Zeb Horizon Generation 2 Datalogger

    1. Connect the ZEB Horizon scanner to the datalogger using the main cable and power on the system as normal. 2. Connect the datalogger to a PC as outlined in the ZEB Horizon User Guide. 3. Open -> GeoSLAM Control Tool (Figure 8). Page 9...

  • Page 13: Figure 8. Geoslam Control Tool

    Figure 8. GeoSLAM Control Tool. 4. Select -> Connect, to open the Control Selection (Figure 9) Figure 9. Control Selection. 5. Select -> ZEB Datalogger. 6. Select -> OK, to continue. 7. Select -> ?, at the IP address popup to detect the datalogger.

  • Page 14: Figure 10. Datalogger Successfully Connected

    Figure 10. Datalogger successfully connected. 9. Select -> Software -> Update -> SHB software (Figure 11). Figure 11. SHB Software update. 10. Browse -> user defined location of the update file. b. Select -> OK, to continue. 11. Select -> Yes, to confirm the update (Figure 12). Page 11...

  • Page 15: Figure 12. Firmware Update Confirmation

    Figure 12. Firmware update confirmation. 12. Select -> OK, to continue at the information dialog (Figure 13) Figure 13. Update Information dialog. 13. After the update has finished, the Datalogger will shutdown and the connection to the Datalogger Control Tool will be lost. 14.

This manual is also suitable for:

Zeb horizon
