b. Select -> OK, to continue.
c. Select -> OK, at the confirmation prompt to continue.
9. Power cycle the system.

LED Indicator Status

The ZEB Vision camera now gives more feedback during capture, please see the LED table
below:
Camera Status
Start Up
Capture

Figure 1. Updating the camera calibration file.

LED
ZEB Vision connected successfully (illuminates
~3 seconds after power on)
ZEB Vision not connected successfully
(illuminates ~8 seconds after power on)
Flashing at 1 second intervals indicates images
are stored
Memory Low
Error with Capture
Page 3
