Summary of Contents for GeoSlam ZEB Vision
- Page 1 Hardware User Guide ZEB REVO RT User’s Manual v1.0.3 © 2018 GeoSLAM Ltd...
- Page 2 GeoSLAM Ltd. GeoSLAM Ltd. provides this guide “as is”, without warranty of any kind and reserves the right to make improvements and/or changes to the product described in this guide at any time and without notice.
-
Page 3: Table Of Contents
ZEB Horizon Generation 2 Datalogger....................4 Data Capture ......................7 4.1. Mounting and Installation ........................7 4.2. Collecting Data ............................9 4.3. Downloading Photos..........................9 4.3.1. Establishing a Connection ..........................9 4.3.2. Downloading Images ............................11 © 2022 GeoSLAM Ltd ZEB Vision User Guide v1.0... -
Page 4: Introduction
1. Introduction The ZEB Vision can be used with the ZEB Horizon system to capture 360° panoramic photography in 4K definition for point cloud visualisation and colourisation. Data is captured as the user walks through the area of interest. The ZEB Vision uses GeoSLAM’s leading SLAM algorithm to automatically and accurately position panoramic photos on a point... -
Page 5: Shb Firmware Update
3.2. ZEB Horizon Generation 2 Datalogger 1. Connect the computer to the datalogger with an Ethernet cable 2. Open The Datalogger Control Tool. (This can be obtained from support@geoslam.com, who will provide the software and the User Guide). The following screen will appear. - Page 6 3. Click “Connect”, and then click on the “?” icon. The Datalogger’s IP address will be detected. 4. Click “OK”. The Datalogger is now connected. 5. Click on “Software, Update, SHB” 6. Choose the relevant update file. © 2022 GeoSLAM Ltd ZEB Vision User Guide v1.0...
- Page 7 7. Click “Yes” to continue. 8. Click OK to begin the update process. After the update has finished, restart the Datalogger, and the process is complete. © 2022 GeoSLAM Ltd ZEB Vision User Guide v1.0...
-
Page 8: Data Capture
4.1. Mounting and Installation After unpacking your ZEB Vision kit, please follow these simple steps to ensure the system is set up correctly for use. Step 1. Remove the four rubber dampers from the back of the ZEB Horizon scanner. - Page 9 Step 4. Insert one end of the main cable into the port on the side of the ZEB Horizon scanner head. Insert the other end of the cable into the port on the ZEB Horizon datalogger. Ensure the red dots are aligned before inserting the cables into the ports. © 2022 GeoSLAM Ltd ZEB Vision User Guide v1.0...
-
Page 10: Collecting Data
4.3. Downloading Photos Insert one end of the ethernet cable into the back of the ZEB Vision camera and secure by tightening the screw. Insert the other end of the cable into a PC which has the GeoSLAM Connect software downloaded. - Page 11 Next, select Internet Protocol Version 4 (TCP/IPv4) and click on ‘Properties’. Set a fixed IP address of 192.168.0.100. © 2022 GeoSLAM Ltd ZEB Vision User Guide v1.0...
-
Page 12: Downloading Images
Confirm and exit the network manager. 4.3.2 Downloading Images Data from the ZEB Vision is stored on the internal data drive in the camera. Images are stored in the format - nnn_F_xxxxxx.jpg and nnn_R_xxxxxx.jpg, where: nnn is the image number... - Page 13 In the right-hand panel, select all of the images taken, right-click and choose to download and delete. The images will now be downloaded to your PC and removed from the camera. © 2022 GeoSLAM Ltd ZEB Vision User Guide v1.0...
