GeoSlam ZEB VISION Hardware User's Manual

Hide thumbs Also See for ZEB VISION:
Table of Contents

Advertisement

Quick Links

Download this manual
Hardware User Guide
© 2018 GeoSLAM Ltd
0
ZEB REVO RT User's Manual v1.0.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZEB VISION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoSlam ZEB VISION

Summary of Contents for GeoSlam ZEB VISION

  • Page 1 Hardware User Guide © 2018 GeoSLAM Ltd ZEB REVO RT User’s Manual v1.0.3...
  • Page 2 GeoSLAM Ltd. GeoSLAM Ltd. provides this guide “as is”, without warranty of any kind and reserves the right to make improvements and/or changes to the product described in this guide at any time and without notice.

  • Page 3: Table Of Contents

    Appendix – Firmware Update Procedure ..............10 4.1. Download Package..........................10 4.2. Updating Camera Firmware .........................10 4.3. Updating Scan Head Firmware ......................13 ZEB Horizon Generation 1 Datalogger.........................14 ZEB Horizon Generation 2 Datalogger.........................14 © 2022 GeoSLAM Ltd Page 2 ZEB Vision User Guide...

  • Page 4: Introduction

    1. Introduction The ZEB Vision can be used with the ZEB Horizon system to capture 360° panoramic photography for point cloud visualisation and colourisation. Data is captured as the user walks through the area of interest. The ZEB Vision uses GeoSLAM’s leading SLAM algorithm to automatically and accurately position panoramic photos on a point cloud for an interactive viewing experience.

  • Page 5: Data Capture

    Step 1. Remove the four rubber dampers from the back of the ZEB Horizon scanner. Step 2. Attach the ZEB Vision camera to the back of the ZEB Horizon scanner using the captive screws provided in the camera casing. The 3mm HEX key found in the screw accessory kit can be used to tighten these screws and secure the camera in place.
  • Page 6 Step 3. Insert the CAM and AUX cables into the relevant ports on the sides of the ZEB Horizon scanner head. Ensure the red dots are aligned before insert the cables. © 2022 GeoSLAM Ltd Page 5 ZEB Vision User Guide...

  • Page 7: Collecting Data

    3.3. Collecting Data The ZEB Vision camera is powered by the ZEB Horizon system. Ensure the camera is fully connected before powering on the Horizon system, otherwise it will not be detected and no images will be captured.

  • Page 8: Downloading Images

    3.4. Downloading Images Insert one end of the ZEB Vision ethernet cable into the back of the ZEB Vision camera and secure by tightening the screw. Insert the other end of the cable into the ethernet port of a PC. If no ethernet port is on the PC then a USB-to-Ethernet adapter can be used.
  • Page 9 Figure 3.1 and click OK to close the Network Properties dialogue boxes. Figure 3-1. Network adapter settings. 3.4.2. Downloading Images Data from the ZEB Vision is stored on the internal data drive in the camera. Images are stored in the format - nnn_F_xxxxxx.jpg and nnn_R_xxxxxx.jpg, where: nnn is the image number.
  • Page 10 GeoSLAM Control Tool v3.3. To update the calibration file on the camera: 1. With the ZEB Vision connected to the ZEB Horizon datalogger, power on the datalogger if not already powered on. 2. Connect the camera directly to a PC using the supplied ethernet cable.

  • Page 11: Appendix - Firmware Update Procedure

    Download the update pack file to your PC and extract the ZIP file to a temporary directory. 4.1. Download Package The update package contains all files necessary to update both the ZEB Horizon and ZEB Vision plus a copy of the Control Tool software to apply the updates.
  • Page 12 4. Select -> Connect, to open the Control Selection (Figure 2) Figure 2. Control Selection. 5. Select -> ZEB Vision. 6. Select -> OK, to continue. 7. Input -> 169.254.0.206, at the IP address popup to detect the camera (Figure 3).
  • Page 13 Figure 4. Camera successfully connected. 1. Select -> Software -> Update -> Software Update (Figure 5). Figure 5. Software update. 2. Select -> Yes, at the dialog to select to update the firmware. © 2022 GeoSLAM Ltd Page 12 ZEB Vision User Guide...

  • Page 14: Updating Scan Head Firmware

    6. After the update has finished, restart the system, and the process is complete. Before using the camera, proceed to the scan head firmware update section. Only updating the camera firmware will result in neither the ZEB Vision or the ZEB Horizon functioning correctly.

  • Page 15: Zeb Horizon Generation 1 Datalogger

    4.3. Updating Scan Head Firmware Any ZEB Horizon must be updated to firmware version 2.2 or later to function with Vision firmware 2.1. Once upgraded, the ZEB Horizon will now be ready for use with either a ZEB Vision or ZEB Cam.
  • Page 16 Figure 8. GeoSLAM Control Tool. 4. Select -> Connect, to open the Control Selection (Figure 9) Figure 9. Control Selection. 5. Select -> ZEB Datalogger. 6. Select -> OK, to continue. 7. Select -> ?, at the IP address popup to detect the datalogger.
  • Page 17 Figure 11. SHB Software update. 10. Browse -> user defined location of the update file. b. Select -> OK, to continue. 11. Select -> Yes, to confirm the update (Figure 12). © 2022 GeoSLAM Ltd Page 16 ZEB Vision User Guide...
  • Page 18 Figure 13. Update Information dialog. 13. After the update has finished, the Datalogger will shutdown and the connection to the Datalogger Control Tool will be lost. 14. Restart the system. © 2022 GeoSLAM Ltd Page 17 ZEB Vision User Guide...
