Panomera® Maintenance
Important Information for Inspection and Maintenance of Panomera® S4 and S8 Systems

1. General Information

Like any other item of daily use, the components of a video security system are subject to natural wear and tear due to environmental
influences. Regular inspection and maintenance of Panomera® systems is therefore required to ensure error-free operation and avoid
consequential damage. We recommend that inspection and maintenance be carried out as prescribed at least once a year during the
entire operating period.
The operator or owner of a video security system has a legally anchored duty to maintain the safety of the equipment.
This obligation includes in particular the inspection and maintenance and Panomera® systems.
If damage results from neglect of this obligation, the system operator or owner is liable.
The maintenance interval always depends on the prevailing environmental conditions and the current
conditions (storm, hail, etc.). The maintenance interval has to be determined individually on the basis of a risk analysis.
The standards and guidelines to be observed by the operator or owner of a video security system must
always be defined individually.

2. Strength Test

First, the Panomera® System system and all attached parts must be checked for mechanical strength. This serves to prevent personal injury
and damage to property caused by falling parts.
The test must be carried out by skilled personnel.
The test is to be performed at least on an annual basis.
The test shall include at least visible damage and wear, functionality, safe operating condition and legibility of markings.
The test has to be documented sufficiently and comprehensibly.
Please note that the operator of a video system is liable for personal injury and property damage caused by falling parts.
3
1
This simplified example shows the wall mounting of a Panomera®. Check alternative mounting methods (ceiling or pole mounting) accordingly.
If necessary, observe other attached parts and check in particular:
❶ the mounting of the Panomera® on the bracket.
❷ the mounting of the bracket on the wall.
❸ bonding / sealing of the front glass. Observe chapter 4 "Front Glass Check".
❹ the fastening of the earthing cable.
❺ the attachment of the safety cable to the Panomera® and to the anchor point.
❻ the correct positioning of the connectors for power supply and network connection.
Defective parts must be replaced immediately.
2
© 2018 Dallmeier electronic
6
4
V0.0.2
2018-10-01
1/5
5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panomera S4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for dallmeier Panomera S4

  • Page 1 ❺ the attachment of the safety cable to the Panomera® and to the anchor point. ❻ the correct positioning of the connectors for power supply and network connection. Defective parts must be replaced immediately. © 2018 Dallmeier electronic V0.0.2 2018-10-01...
  • Page 2 ❺ Clean the coated front glass of the Panomera® with a silicone-free cotton cloth. Do not use a household glass cleaner, but a special cleaner recommended by Dallmeier. Avoid strong rubbing and do not let residues of the cleaning agent dry on the front glass.
  • Page 3 A front glass with a damaged seal must be replaced immediately to avoid consequential damage. When mounting the front glass, the screws should always be tightened crosswise. Observe chapter 6 "Mounting the Front Glass". © 2018 Dallmeier electronic V0.0.2 2018-10-01...
  • Page 4 ❷ Clean the inside of the coated front glass of the Panomera® with a silicone-free cotton cloth. Do not use a household glass cleaner, but a special cleaner recommended by Dallmeier. Avoid strong rubbing and do not let residues of the cleaning agent dry on the front glass.
  • Page 5 Insert the plastic sleeve into the housing frame and retighten the screw. ❷ Proceed accordingly for the diagonally opposite screw ❸ and for the remaining two screws ❹. When mounting the front glass, the screws should always be tightened crosswise. © 2018 Dallmeier electronic V0.0.2 2018-10-01...
