Astra Wash19PixIP
IP65 moving wash light with 19x40W
RGBW LED and 4°-54° zoom
USER MANUAL
English version
REV.01-09/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Astra Wash19PixIP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ProLights Astra Wash19PixIP

  • Page 1 Astra Wash19PixIP IP65 moving wash light with 19x40W RGBW LED and 4°-54° zoom USER MANUAL English version REV.01-09/22...
  • Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
  • Page 3: Table Of Contents

    16 - ERROR MESSAGES 17 - PERIODICAL CLEANING 18 - TEST OF IP65 RATING 19 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............35 REPLACING THE FUSE ....................35 VISUAL CHECK OF PRODUCT HOUSING ..............35 TROUBLESHOOTING ..................... 36 PROLIGHTS - Astra Wash19PixIP...
  • Page 4: Safety Information

    • Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. Installation •...
  • Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
  • Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - Astra Wash19PixIP...
  • Page 7: Packaging

    • C6002: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt; • FCLASTRAW19PIX: flight case for 3 pcs of ASTRAWASH19PIXIP; • IPTESTBOX: portable vacuum and pressure tester for ProLights IP fixtures. • UPBOX2P5: firmware uploader kit, USB IN, 5-pin XLR DMX OUT.
  • Page 8: Pan And Tilt Lock

    3 - PAN AND TILT LOCK PAN Mechanism lock and release TILT Mechanism lock and release Fig. 02 PROLIGHTS - Astra Wash19PixIP...
  • Page 9: Installation

    Warning! When clamping the fixture to a truss or other structure at any angle, use clamps of half-cou- pler type. Do not use any type of clamp that does not completely encircle the structure when fastened. C6002 RSR0630A/B clamp Steel security cable OSIP 108 mm [4.3 in] Fig.03 PROLIGHTS - Astra Wash19PixIP...
  • Page 10: Connection To The Mains Supply

    • Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - Astra Wash19PixIP...
  • Page 11: Product Overview

    10. DMX IN (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C; 11. DMX OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C. 9 10 Fig 04 PROLIGHTS - Astra Wash19PixIP...
  • Page 12: Dmx Connection

    ... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 06 - Example 30 DMX channels configuration PROLIGHTS - Astra Wash19PixIP...
  • Page 13: Construction Of The Dmx Termination

    (Protocol, Net, Subnet, Universe, Start Channel and IP Address, Ethernet to DMX No/Yes). • IP addresses recommended: 002.xxx.xxx.xxx or 010.xxx.xxx.xxx. • The submask net is fixed at 255.0.0.0. PROLIGHTS - Astra Wash19PixIP...
  • Page 14: Ethernet To Dmx Operations

    NOTE: Artnet and sACN have higher priority on DMX if they are connected to transmitter. NOTE: Do not use IN TO WDMX and ETH TO DMX simultaneously, this will cause data conflict on DMX output signal. PROLIGHTS - Astra Wash19PixIP...
  • Page 15: Operation As A Wireless Receiver

    • The wireless icon on the receiver display indicates the received signal strength. WDMX TO DMX (RX) This function enable or disable the retransmission of the wireless DMX signal received throught the DMX port on the receiver side. PROLIGHTS - Astra Wash19PixIP...
  • Page 16: Control Panel

    • Switch on the display using backup battery. Hold for 5s. • Switch off display by pressing button 4 for 5s while on being on Home screen. • LED indicator for Ethernet network (color orange). PROLIGHTS - Astra Wash19PixIP...
  • Page 17: Menu Structure

    Set Universe for sACN protocol. OFF/HTP/ MERGE Set Merge Mode for sACN protocol. MODE ETHERNET TO DMX Enable / Disable DMX retrasmission from sACN/ArtNet signal to DMX out port. KLINGNET Enable / Disable Klingnet functionality for sACN / ArtNet protocols. PROLIGHTS - Astra Wash19PixIP...
  • Page 18 To transfer the same menu settings of CONFIGURATION ADDRESS one fixtures to all the other in the daisy chain, including or not the dmx address. WITH DMX ADDRESS ADVANC- RESET To reset these functions. PAN & TILT ZOOM PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 19: Shortcut

    DOWN Reset without Fixture will be powered on without reset on pan/tilt then power on pan/tilt movements movements. ENTER + UP Bootloader Force fi rmware upgrade. then power on PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 20: Rdm Functions

    0x0142 Dimmer DIMMER_INFO 0x0340 Settings MINIMUM_LEVEL 0x0341 MAXIMUM_LEVEL 0x0342 CURVE 0x0343 CURVE_DESCRIPTION 0x0344 OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_ DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_ DESCRIPTION 0x0348 Sensors SENSOR_DEFINITION 0x0200 SENSOR_VALUE 0x0201 RECORD_SENSORS 0x0202 BURN_IN 0x0440 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 21 FIX. ENGINE PROT. (0:W/DMX 1:sACN 0x8010 2:ArtNet) PIX. ENGINE PROT. (0:W/DMX 1:sACN 0x8020 2:ArtNet 3:sAK 4:ArtK 5:K 6:sAN) PIX. ENGINE ADDR. (1-512) 0x8030 PIX. ENGINE MODE (0:Off 1:Ring 2:Pixel) 0x8040 KLINGNET (0:Off 1:On) 0x8050 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 22: Dmx Charts

    Pattern Transition Ring Dimmer Ring Foreground Blue Foreground Intensity Ring Pattern Foreground Strobe Ring Pattern Speed Background Intensity Ring Pattern Fade Background Strobe Ring Pattern Transition Background Red Ring Foreground Intensity Background Green PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 23 Ring Foreground Intensity Ring Background Blue Ring Foreground Strobe Ring Foreground Red Ring Foreground Green Ring Foreground Blue Ring Background Intensity Ring Background Strobe Ring Background Red Ring Background Green Ring Background Blue PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 24 Blue 2 Blue 2 White 2 White 2 Red 3 Red 3 Green 3 Green 3 Blue 3 Blue 3 White 3 White 3 Red 19 Green 19 Blue 19 White 19 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 25 046 ÷ 047 Medium Blue 048 ÷ 049 Bright Pink 050 ÷ 051 Mauve 052 ÷ 053 Dark Green 054 ÷ 055 Lee Green 056 ÷ 057 Dark Blue 058 ÷ 059 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 26 Lineary from 0% to 100% 000 ÷ 255 ZOOM FINE Lineary from 0% to 100% 000 ÷ 255 CROSSFADE PIXEL ENGINE PROTOCOL Fades from 1 to 2 protocol according to the combination choosed 000 ÷ 255 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 27 IN TO WDMX ON (MAIN FIXTURE TO WDMX) 138 ÷ 139 IN TO WDMX ON (PIXEL ENGINE TO WDMX) 140 ÷ 141 Reserved 142 ÷ 253 FACTORY DEFAULT OF CONTROL FUNCTIONS 254 ÷ 255 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 28 065 ÷ 125 Open 126 ÷ 127 Pulse out from slow to fast 128 ÷ 188 Open 189 ÷ 190 Random from slow to fast 191 ÷ 251 Open 252 ÷ 255 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 29 000 ÷ 127 CW from fast to slow 128 ÷ 190 Stop 191 ÷ 192 CCW from slow to fast 193 ÷ 255 RING PATTERN FADE Lineary from 0% to 100% 000 ÷ 255 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 30 RING BACKGROUND RED Lineary from 0% to 100% 000 ÷ 255 RING BACKGROUND GREEN Lineary from 0% to 100% 000 ÷ 255 RING BACKGROUND BLUE Lineary from 0% to 100% 000 ÷ 255 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 31: Ring Layout

    14 - RING LAYOUT Fig. 09 15 - PIXEL LAYOUT Fig. 10 PROLIGHTS - Astra Wash19PixIP...
  • Page 32: Error Messages

    [LED FAN 1 ERROR] source failed, the source has been Blue switched OFF. One of the blowers for cooling the [LED FAN 2 ERROR] source failed, the source has been Blue switched OFF. PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 33 LED PCB 1 not detected during reset Yellow IDENTIFICATION OF ELECTRONIC BOARDS IDENTIFICATION OF ELECTRONIC BOARDS 3U PCB 3U PCB 2U PCB 2U PCB 1U PCB 1U PCB Fig. 11 Fig. 11 PROLIGHTS - Astra Wash19PixIP PROLIGHTS - Astra Wash19Pix...
  • Page 34: Periodical Cleaning

    17 - PERIODICAL CLEANING WARNING! Turn OFF power and allow approximately 20 minutes for the fixture to cool down. Use a soft cloth dampened with any detergent liquid for cleaning to remove the dirt from the optics. Fig. 13 PROLIGHTS - Astra Wash19PixIP...
  • Page 35: Test Of Ip65 Rating

    18 - TEST OF IP65 RATING After servicing to controll the correct sealing to use the IPTESTBOX. Remove the gore valve from the connections panel. Connect the air hose to the IPTESTBOX by inserting the quick-connect fitting into the coupler. PROLIGHTS - Astra Wash19PixIP...
  • Page 36 Loosen the four screws (4) and remove the rear cover. Remove the gore valve on the rear connec- tion heatsilk module (5) and insert the hex socket cap head included in the IPTESTBOX box (6). For the operating procedure using the instrument, refer to the IPTESTBOX user manual. Fig. 12 PROLIGHTS - Astra Wash19PixIP...
  • Page 37: Maintenance

    WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel.
  • Page 38: Troubleshooting

    • Check if the Fuse is intact and eventually replace it if fault necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in...
  • Page 39 Note...
  • Page 40 Note...
  • Page 41 Note...
  • Page 42 Note...
  • Page 44 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
