TS200 Series Tripod Turnstile
4.2.2

Opening Mode

Card swiping means that you can open the door only after verification. Free means that you can pass the
door without verification. Prohibited means that you can't pass the door, whether you have permission or
not.
4.2.3

Opening Duration

This function refers to the period of time from opening to closing once the turnstile receives an opening
signal. In the DIP switch, number 3 is used for duration settings. It can be set two different values: 5s or 10s.
4.2.4

Continue Passing Function

With the "Continue Passing" function, the turnstile could remember at most 20 swipes of one card at one
time and allows up to 20 people to pass so they don't have to swipe card each time. This function can be
enabled or disabled with number 4 in the DIP switch.
5

Equipment Precautions and Maintenance

5.1

Precautions

It is recommended to purchase additional accessories to use the product outdoors.

1) You may install cooling fans for the equipment if the working temperature is often above 50 ºC.
2) The device is rated IP54 waterproof under proper installation. However, its ability to stand in
extreme weather conditions, such as typhoon, is not guaranteed.
3) If the temperature is around or below -30
the equipment. You might need to turn the power on multiple times to let the device
automatically heat up through the self-check program.
4) The service life of this equipment may be shortened if it works outdoors in coastal areas or a
region prone to acid rain.
If the power and signal cables are connected properly, this equipment can be immersed under water

at a depth of 250 mm, but it must not be powered on when it is immersed in water.
It is highly recommended to set a warning card-swiping line to remind passers-by to correctly swipe

cards at a reasonable distance from the device to prevent passers-by from being squeezed.
It is recommended to place a warning sign at a conspicuous position, and prompt: "Please swipe

your card outside the warning line and pass in order. Thank you! "
P a g e | 8
º C, you are recommended to install a heating plate for
