EN: 8. Locations of upper and rear
connection openings
(mm)
Linear 18 Compact
B
EN: 9. Connecting the stove to a masonry
flue via the rear connection opening
› 2.6.
EN: 10. Connecting the stove to a masonry
flue via the upper connection opening
› 2.6.
8
A
B
C
n./ca
670
120
850
DE: 8. Position der oberen und hinteren
Anschlussöffnungen
D
E
F
n./ca
n./ca
n./ca
980
1410
1540
~50
DE: 9. Anschluss des Ofens an einen
gemauerten Rauchfang über die
hintere Anschlussöffnung
DE: 10. Anschluss des Ofens an einen
gemauerten Rauchfang über die obere
Anschlussöffnung
VL22l
VL22l
~50
